ALLSOP clingo universal vent mount Instructions

ASSEMBLY
Step 1: Attach the vent mounting clips to the back of the vent pedestal (diagram 1). The vent mounting clips can be
positioned with the flat sides facing up or down depending on the design of the vehicle vent.
Step 2: Insert the head of the vent beam into the socket on the back side of the cradle (diagram 2).
Step 3: Connect the T-slot on the vent beam to the T-tab on the pedestal (diagram 3).
INSTALLATION
Step 1: Find a safe location on the vehicle vent. Gently insert vent pedestal into vent louvres until mount clips are attached
to the fin/blade of the vent (diagram 4).
Step 2: Adjust the support leg vertically until it rest firmly along the bottom of the vent or dash surface below the vent.
Mobile Device Installation
Step 1: Remove protective film.
Step 2: Check Clingo pad for cleanliness and stickiness before each use. Product will fail if the pad is not cleaned properly.
See PROPER CARE & CLEANING for instructions. Cleaning frequency may vary by environment.
Step 3: Wipe dirt and dust from your mobile device and attach it to the Clingo pad. DO NOT attach your mobile device to
the Clingo pad if it is protected by a leather or silicone case. The Clingo pad WILL NOT stick to leather or silicone.
Make sure the device is placed on the pad so that the battery cover does not slide off.
Step 4: Adjust the angle of the cradle to find the optimal hands-free viewing position.
Removing Mobile Device
Gently peel (do not pull) your device off of the Clingo pad from the top edge (diagram 5).
Removal from Vent
Step 1: Remove the mounting clips from the pedestal by sliding the mounting clips to the center of the pedestal and
pulling them through (inset diagram 6).
Step 2: Push on the vent louver until the clip mounts clear the louver. Pull clip away from louver (diagram 6)
PROPER CARE & CLEANING
Proper care and use of the product is necessary to maintain optimal stickiness on Clingo pad.
For Best Results
Step 1: Always remove mobile device from Clingo product.
Step 2: Run warm water over Clingo pad and use fingers to remove dirt and dust. Hand oils and grease may require the use
of mild soap. DO NOT use solvents to clean the Clingo pad.
Step 3: Let Clingo pad air dry completely before using. The Clingo pad WILL NOT stick when wet.
For Quick Cleaning
Step 1: For quick cleaning, use a damp, lint-free wipe or cloth to remove dust, dirt and oil from Clingo pad (diagram 7).
DO NOT use any paper products.
CLINGO PAD
The Clingo pad is permanently bonded to the product. Do not attempt to remove the Clingo pad.
Safety Precautions
Do not install Clingo products over an air bag cover or within the air bag deployment zone. Allsop, Inc. and
its subsidiaries assumes no responsibility of liability for injury or death as a result of car crashes and/or air
bag deployment. Allsop, Inc. and its subsidiaries are not responsible for any damages caused to your car, your
device, or yourself due to installation or use of this product
Use caution when inserting or removing the pedestal or the mobile
device from the cradle. Make sure the vent lips are open wide enough to
prevent damage to the vent fins/blades.
Do not install Clingo products over an air bag cover
or within the air bag deployment zone
for more information, visit
diagram 1
CAUTION
!
WARNING
!
www.clingo.com
universal vent mount
securely holds mobile devices | tient solidement les dispositifs mobiles
diagram 2
Beam
Mounting
Cradle
Clips
An Family Brand
PO Box 23, Bellingham, WA 98227
PH 360-734-9090
www.allsop.com
ALLSOP Europe Limited,
Industrial Park, Waterford, Ireland
PH 353-51-355091
www.allsop.eu
™
Pedestal
contents
diagram 3
diagram 4
diagram 5
diagram 6
diagram 7
