Summary of Contents for OVERDIGIT IEC-line SC143-C1
- Page 1 User manual PLC board SC143-C1 series IEC-line update: 16-06-2017 IEC-line by OVERDIGIT overdigit.com...
- Page 2 M4 screws. The main mechanical dimensions and the positions of the holes, for the open and closed version, are as follows: OVERDIGIT SC143-C1 RESET 24Vac/dc RS485 ETHERNET RS232 IEC-line by OVERDIGIT Page 2...
- Page 3 Hardware reset push button Forced STOP jumper STOP USB power jumper RTC BATTERY RESET LEDS Ethernet exchanges data Ethernet connected LEDS LINK PLC program is in STOP state STOP PLC program is in RUN state USB POWER IEC-line by OVERDIGIT Page 3...
- Page 4 The RS485 interface, galvanically isolated, also has an additional 0V wire to be connected to the reference terminal of the expansion interfaces in order to constrain the references of the respective hardware drivers. IEC-line by OVERDIGIT Page 4...
- Page 5 A. NOTE: To connect the USB port directly to a PC it is recommended to remove the power jumper to disconnect the +5V power supply of the CPU from the USB connector. IEC-line by OVERDIGIT Page 5...
