Summary of Contents for KLING & FREITAG Rotation Clamp 450
- Page 1 K&F Rotation Clamp 450 Version 1.4 User's Manual Released: 18.05.2018 Translation of the original instructions Important Information, Please Read Before Use! KLING & FREITAG GmbH Wohlenbergstrasse 5 D-30179 Hannover TEL +49 (0) 511 96 99 70 FAX +49 (0) 511 67 37 94...
-
Page 3: Table Of Contents
User's Manual K&F Rotation Clamp 450 Table of contents Introduction Icons Used About this Manual Product Description Intended Use Items Included Components ID plates and safety labels 2.4.1 ID Plates 2.4.2 Safety Labels Safety Instructions Maximum Load Mounting and Use Instructions... -
Page 4: Introduction
Thank you for purchasing a KLING & FREITAG product. To guarantee trouble-free operation and enable the KLING & FREITAG Rotation Clamp 450 to achieve its full potential, read this manual carefully before use. This item is a quality accessory. Combining it with a suitable K&F speaker system creates an extremely versatile pro-grade tool that meets all requirements in terms of safe installation. -
Page 5: Product Description
Always be sure to use the supplied couplers and screws only. Warning The rotation clamp 450 is suitable for use with K&F SPECTRA 212 Flybar, K&F SPECTRA 212 Singlebar, K&F VIDA L flying frames, K&F SEQUENZA 5 flying frames and K&F SEQUENZA 10 flying frames. -
Page 6: Components
User's Manual K&F Rotation Clamp 450 Components Half coupler sCustom screw Clamping jaws (with ID plate) Adjustable M10 clamping lever Recess scale Linchpin Load bolt Load fork KLING & FREITAG GMBH © 2018 Version 1.4 Page 6 of 20... -
Page 7: Id Plates And Safety Labels
Before you start mounting a rotation clamp, always make sure you are about to use the rotation-clamp type suitable for the application at hand (i.e. the pipe diameter). 2.4.1 ID Plates ID plate for K&F rotation clamp 450 ID plate for K&F rotation clamp 450 featuring 50-mm half coupler (HC823-B): featuring 60-mm half coupler (HC828): K&F Drehklemme 450... -
Page 8: Safety Instructions
Maximum Load Be sure to load the K&F rotation clamp 450 with the K&F SPECTRA 212 flybar, K&F VIDA L flying frame, K&F SEQUENZA 5 flying frame or K&F SEQUENZA 10 flying frame! The maximum load including the flying frame, all speakers, and all connecting cables must never exceed 450 kg (as required by DGUV regulation 17 (BGV C1)). -
Page 9: Mounting And Use Instructions
Next, pull the two components apart again and attach the flying frame to the rotation clamp as detailed below. The following illustrations show an exemplary assembly of the K&F Rotation Clamp 450. Insert the load adapter into the identified flying-frame bores. - Page 10 User's Manual K&F Rotation Clamp 450 Pull the load bolt out of the load fork. Place the rotation clamp with the load fork onto the mounted load adapter. KLING & FREITAG GMBH © 2018 Version 1.4 Page 10 of 20...
- Page 11 User's Manual K&F Rotation Clamp 450 Fasten the load adapter by sliding the load bolt through the load fork and the load adapter. Secure the load bolt by folding back the linchpin lock washer, inserting the linchpin into the load- bolt bore from above, and folding the lock washer back into position.
- Page 12 User's Manual K&F Rotation Clamp 450 Danger! Risk of injury from falling objects! Improperly assembled speaker Warning suspension kits s are not safe for speaker installation. Objects falling down impose a deadly risk for people standing near-by! Always check all connecting components for secure fit.
- Page 13 User's Manual K&F Rotation Clamp 450 Fasten the clamping lever finger- tight. For appearance, you can move the clamping lever into any direction without loosening the array- orientation lock. For this purpose, pull the lever out a bit, rotate as desired, and release it when you are finished.
-
Page 14: Application Examples
User's Manual K&F Rotation Clamp 450 Application Examples To prevent overloading the accessory, be sure to follow the maximum-load specifications (450 kg including the flying frame and cabling). Note that the suspension point must comply with the DGUV regulation 17 (BGV C1) or similar locally applicableaccident-control standards. -
Page 15: Examples
User's Manual K&F Rotation Clamp 450 Examples K&F VIDA L K&F SEQUENZA 10 K&F SPECTRA 212 K&F SEQUENZA 5 KLING & FREITAG GMBH © 2018 Version 1.4 Page 15 of 20... -
Page 16: Dimensions And Weight
User's Manual K&F Rotation Clamp 450 Dimensions and Weight Permanent weight: 2.9 kg (50-mm type), 3.1 kg (60-mm type) KLING & FREITAG GMBH © 2018 Version 1.4 Page 16 of 20... -
Page 17: Ec Declaration Of Conformity
User's Manual K&F Rotation Clamp 450 EC Declaration of Conformity KLING & FREITAG GMBH © 2018 Version 1.4 Page 17 of 20... -
Page 18: Care And Maintenance
User's Manual K&F Rotation Clamp 450 Care and Maintenance For the owner and user, it is mandatory to be aware that speaker accessories used to fly or mount the speakers are fundamentally safety-relevant. Note that the mains cable is supplied with either a connector appropriate for the place of delivery (see item number) or with open terminals (on the mains side). -
Page 19: Transportation And Storage
K&F Rotation Clamp 450 Transportation and Storage The K&F Rotation Clamp 450 is protected against the effects of unfavorable temporary weather conditions, etc.; Despite, be sure to store, transport, and use the accessories in dry environments only. Speaker accessories are not designed for prolonged use in corrosive environments. - Page 20 User's Manual K&F Rotation Clamp 450 INDEX • Application Examples........................14 • Care.............................. 18 • Components...........................6 • Dimensions...........................16 • Disposal............................19 • EC Declaration of Conformity....................17 • Example configuration........................15 • Intended Use..........................5 • Introduction........................... 4 • Items Included..........................5 •...
