OWNER'S GUIDE
Please read entire booklet before assembling KYDZ Suite
Keep this booklet for future reference and add-ons.
The KYDZ Suite line of products and all Jonti-Craft products are
The KYDZ Suite line of products and all Jonti-Craft products are
intended for use in caring for children of immature judgement; adult
intended for use in caring for children of immature judgement; adult
supervision is required at all times!
supervision is required at all times!
w w w.jonti- craf t.com/k ydzsuite
products.
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KYDZ Suite Panels and is the answer not in the manual?

Questions and answers

Summary of Contents for Jonti-Craft KYDZ Suite Panels

  • Page 1 ® Keep this booklet for future reference and add-ons. The KYDZ Suite line of products and all Jonti-Craft products are The KYDZ Suite line of products and all Jonti-Craft products are intended for use in caring for children of immature judgement; adult intended for use in caring for children of immature judgement;...

  • Page 2: Table Of Contents

    With an easy-to-use Tab Mounting Template and Hub Connector Tabs, KYDZ Suite easily connects to most Jonti-Craft products, letting you make the most of what you already have. KYDZ Suite is also GREENGUARD Gold Certified which means you can breathe easy knowing that these products contribute to healthier indoor air quality.
  • Page 3 THE ESSENTIALS OF KYDZ SUITE The KYDZ Suite line of products and all Jonti-Craft products are intended for use in caring for The KYDZ Suite line of products and all Jonti-Craft products are intended for use in caring for children of immature judgement; adult supervision is required at all times! children of immature judgement;...

  • Page 4: The Essentials Of Kydz Suite

    THE ESSENTIALS OF KYDZ SUITE KYDZ Suite Panels must always be connected at the ends, either to another Panel, a wall (via the KYDZ Suite Wall Adapter), a stationary Jonti-Craft furniture item or a pair of KYDZ Suite Stabilizer Wings.

  • Page 5: The Essentials Of Kydz Suite

    THE ESSENTIALS OF KYDZ SUITE Use KYDZ Suite Cascade Panels to connect from S-Height to A-Height, or A-Height to E-Height, or E-Height to T-Height items. Do not attempt to connect different height items together without the use of a Cascade Panel. T to E-Height Cascade Panel E to A-Height Cascade Panel A to S-Height Cascade Panel...
  • Page 6 THE ESSENTIALS OF KYDZ SUITE KYDZ Suite Welcome Gates and Welcome Arches must either be connected to KYDZ Suite Panels at an angle other than 180˚ (straight line) or be connected to a stationary Jonti-Craft furniture item. They can also be supported via a pair of KYDZ Suite Stabilizer Wings on each end. The Welcome Gates and Welcome Arches should be placed on a flat surface with the handle facing outwards, away from the space children primarily occupy.
  • Page 7 THE ESSENTIALS OF KYDZ SUITE When placing KYDZ Suite Panels above an item like a storage unit, (i.e., Upper Deck Divider) always use specifically assigned kits and follow assembly instructions. In these cases, the bottom unit or Panel must be secured at both sides by using KYDZ Suite Stabilizer Wings, 15” or 18” deep stationary Jonti- Craft furniture items, or connected to a structural wall.

  • Page 8: Assembling Hubs

    ASSEMBLING HUBS Top Cap Connector Block Post Bottom Connector Block To remove the connector To lock Hub, replace The Hub is now block, first unscrew the top connector block. Then ready to use. cap by twisting counter retighten top cap by clockwise with your hand.

  • Page 9: Assembling Panels To Hubs

    ASSEMBLING PANELS TO HUBS Top Cap Connector Block Hub Connector Bottom Connector Block 1. Unscrew the top cap of 2. Slide the Hub Connector Tab 3. Slide the Hub Connector the KYDZ Suite Hub on the bottom of the first Tab on the second Panel and remove plastic Panel into a groove in the...

  • Page 10: Installing Hub Connector Tabs

    INSTALLING HUB CONNECTOR TABS Tab Mounting Template 1. To apply Hub Connector Tabs to a Jonti-Craft furniture 2. Drill holes using the ” drill bit item, first place the Tab Mounting Template included in from the starter kit. NOTE: Drill no your starter kit on the side of the unit as shown.

  • Page 11: Connecting Items To Jonti-Craft Units

    CONNECTING ITEMS TO JONTI-CRAFT UNITS To connect a KYDZ Suite item to a Jonti-Craft furniture item, first follow the instructions on page 10 while using the included Tab Mounting Template. Once the Hub Connector Tabs are in place, slide the unit into a groove in the bottom connector block.

  • Page 12: Installing Wall Mounts

    INSTALLING WALL MOUNTS Top Cap Top Connector Block Wall Connector Hub Connector Bottom Connector Block 2. Next, replace the top 3. Find a stud in the wall. 1. First unscrew the top cap of connector block and NOTE: Wall Connector MUST the Hub and remove the top screw in the top cap.

  • Page 13: Installing Immobilizer Blocks

    Installing Immobilizer Blocks allows you to convert a mobile Jonti-Craft furniture item to a stationary unit. To insert Immobilizer Blocks under a mobile Jonti-Craft furniture item, slide one block under the base rail in each corner of the storage unit. The unit may need to be lifted slightly. The kickplate or bottom rail of the unit should rest in the groove of the Immobilizer Block.

  • Page 14: Adjusting Accordion Panels

    Follow instructions on page 9 to attach an Accordion Panel to other KYDZ Suite items and page 11 to attach to Jonti-Craft furniture items. CAUTION: To prevent children from playing with the knobs, face side of Panel with knobs outward, away from the space children primarily occupy.

  • Page 15: Assembling Filler Plates

    Place the Filler Plate over the top Filler Plate connector blocks. Reinsert the top caps and tighten. There should no longer be a space between your Jonti-Craft units. w w w.jonti- craf t.com / k ydz suite 8 0 0.543.4149...
  • Page 16 ASSEMBLING UPPER DECK DIVIDERS 1. First attach Hub Connector Tabs to rear of the Jonti-Craft furniture item on both sides by following directions on page 10. Then attach Hub (without top cap and top connector block) to the mounted Hub Connector Tabs at the rear of the unit.

  • Page 17: Assembling Upper Deck Dividers

    ASSEMBLING UPPER DECK DIVIDERS Wood Dowel Bottom Connector Block Threaded Rod Top Connector Block 4. Screw in the provided threaded rod so 1½” 5. Next, connect the Panel by aligning the Hub sticks out of the top connector block. Place Connector Tabs and the connector blocks.
  • Page 18 Wabasso, MN 56293 WARRANTY KYDZ Suite products feature Jonti-Craft’s Lifetime warranty. KYDZ Suite items are covered from material defect and quality of workmanship, absent any misuse, abuse or normal wear and tear. Any modification to the original KYDZ Suite product, any use not compliant with published KYDZ Suite guidelines or connecting KYDZ Suite products to non-Jonti-Craft brand products voids this warranty.
