Summary of Contents for Sport-thieme PROFI SOCCER DELUXE ST
- Page 1 Aufbau- und Bedienungsanleitung Artikel 1348789 Please read the operating instructions carefully before use and keep 1348789 Sport-Thieme...
- Page 2 Aufbau- und Bedienungsanleitung Artikel 1348789 1348789 Sport-Thieme...
- Page 3 Aufbau- und Bedienungsanleitung Artikel 1348789 25 mm 1348789 Sport-Thieme...
- Page 4 H6. Then attach Apron miter P8 between the side panel and the end panel, locked by screw H15. Note: Be sure that the Side panel and the End panel are square during this step. 1348789 Sport-Thieme...
- Page 5 4) Attach each Leg P4 into the table corner fixed by Bolt H8 acrossing washer H2 with Nut H12. Attach the Bars P12 between the Legs, using Rods P11 inserting bars and locked by Nut H5 outside legs. Locate Leg leveler H3 on the bottom of leg. 1348789 Sport-Thieme...
- Page 6 6) Lock Player C8, C9, Goalie rod stop ring C11 on player rods by screw C6 & Nut C7, then inserting two washer C5 on both sides of Rubber bushing C4 as FIGURE 6. Finally, put rod end caps P6 on another side of player rod. 1348789 Sport-Thieme...
- Page 7 Rods Configuration automatically screw driver with the lowest setting. To place the handles on the rods, please use a simple rubber hammer. Handleside with a hole 1348789 Sport-Thieme...
