Release date 01.09.2022
T3 Install & Operation
Manual
Safety
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
The unit should be isolated from the electricity supply before removal of any covers. Great care must be employed when
working with high pressure carbon dioxide, and in no cases should the maximum operating pressure of 0.4MPa (4 bar)
be exceeded.
The appliance is not suitable for installation in an area where a water jet could be used.
The appliance has to be placed in a horizontal position.
WARNING: Keep ventilation openings in the appliance enclosure or in the built-in structure clear of obstruction.
WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
This appliance is intended to be used in household and similar applications such as:-
Staff kitchen areas in shops, offices and other working environments
Farm houses and by clients in hotels, motels and other residential type environments
Bed and breakfast type environments
Catering and similar non-retail applications
A-weighted emission sound pressure level is below 70 dB(A)
R290 is a refrigerant-grade propane used on a wide range of commercial refrigeration and air
conditioning units. A highly pure propane, it has a low environmental impact and nominal global
warming potential (GWP), meaning it possesses no qualities that can destroy the ozone layer. R290
also is the preferred hydrocarbon alternative of the Environmental Protection Agency (EPA),
substituting more harmful fluorocarbon refrigerants like R22, R134a, R404a and R502.
Units with R290 can only be maintained and repaired by authorized technicians who are
properly trained and certified.
Advertisement
Related Manuals for Borg T3
Summary of Contents for Borg T3
- Page 1 Release date 01.09.2022 T3 Install & Operation Manual Safety This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 2 Always place the dispenser in its vertical position, on a surface which can capably support its weight. During use this machine must remain in its upright position. Adequate ventilation must be allowed for – we recommend using the supplied ventilation ducting kit. Keep the machine away from sunlight, heat and moisture.
-
Page 3: Specification
Specification COOLING SYSTEM Stainless steel direct chill coil encased in a solid-block system for instant response cool down action. Ultra efficiency compression system with capillary control. Environmentally friendly R290 refrigerant. COLD TEMPERATURE 2°C - 11°C. OUTPUT PER HOUR (ProCore+) 80 litres Chilled 80 litres Sparkling DISPENSE Quadra Neck Faucet with ergonomically designed and situated light... - Page 4 Model Overview Introduction The T3 & T3+ epitomises cutting-edge design and innovation with its contoured tap and compact ProCore unit. This is our most discreet range and will fit into any environment seamlessly. The ProCore dispenser is a cooler designed to provide chilled and carbonated water. All the materials and components...
- Page 5 Component/Feature Overview T3 Tap - Major Components Contents: 1 no Connector Cable 1 no T3 1 no Waste Drain Pipe 1 no Top Plate with Control Panel 1 no Fixings Set 1 no Drip Tray 1 no 1.0m x 6mm Insulated Water Pipe...
- Page 6 1. Faucet, 2. Main body, 3. Top Mounting Plate, 4. Drip tray, 5. Capacitive touch display, 6. Connector Cable...
- Page 7 ProCore Electronic - Major Components Contents: 1 no Co2 Regulator with Gauge & Connection tube* 1 no ProCore Simple-fit Ventilation Kit 1 no Undercounter Unit 1 no 2.0m Power Cord Set...
- Page 8 1. ProCore Simple-fit Chimney, 2. ProCore Simple-fit Base, 3. Front Panel, 4. Carry Handle, 5. Top Panel, 6. Water Outlet, 7. Water Inlet, 8. Hot Outlet, 9. On/Off Switch, 10. Power Connection, 11. Tap Connection, 12. CO2 Inlet*, 13. Side Panel Please Note: Mains Installation Kit &...
-
Page 10: Installation Requirements
Installation Installation Requirements Identify a suitable location for the ProCore unit. It should be positioned within 1.0m of the faucet, and within 2.0m of suitable services connections. Allow enough space to fit the ventilation ducting system. The ProCore unit must be installed in accordance with the relevant requirements of: The appropriate building regulations by application of either The Building Regulations (England and Wales), The Building Regulations (Scotland) or The Building Regulations (Northern Ireland). - Page 11 First, install the T3 tap to the Insert the tap so the fixing Using the M6 allthreads as When planning and top plate base. Line up the screws line up with the provided locate them into providing for the connection tap so it’s parallel to the...
- Page 12 Download or order the ProCore Vent Base Cutting Template here Tap & Driptray Cutting Template We recommend you check the dimensions of the tap and driptray using the cutting template prior to cutting the work surface. Download or order the T2/T3 cutting template here...
-
Page 13: Operation
Operation Tap Control Panel 1. Unlock Button, 2. Chilled Dispense, 3. Sparkling Dispense, 4. Ambient Dispense, 5. Hot Dispense 6. ‘eco’ Mode Symbol 7. Warning Symbol. Basic Functions... -
Page 14: Warning Symbol
Ventilation System Installation When Borg & Overström undercounter units are installed of heat generated by the cooling cycle depends directly inside a cabinet or housing, adequate ventilation is upon the amount of usage – the higher the usage, the recommended to ensure that they operate satisfactorily. - Page 15 Situate the ProCore Simple-fit Insert 4 screws into the holes located. Using the template provided, carefully ventilation base in place centrally over Do not overtighten at this stage. mark and cut the aperture to the edge the aperture. Ensuring that there is a of the cabinet.
- Page 16 NOTE: Any obstructions will adversely affect the airflow to the appliance causing potential for poor performance, over heating or fridge failure. ProCore Installation & Water Connection Connect the T3 tap to the water Locate the ProCore in a suitable Connect the T3 Tap USB to the outlets.
- Page 17 Allow the machine to stand for 8 - 12 The carbonator should be purged of Turn on the water supply to fill the tank. minutes for the initial chilling process to air by activating the sparkling water complete. dispense for approximately 10 seconds.
- Page 18 Stand the cylinder in a suitable place. We recommend between 3.5 - 4 bar (58 PSI) (max). Do not exceed 4 bar pressure. Sparkling Water Flow Rate - Sparkling Versions Only NOTE: Sparkling water flow rate factory setting = 2.4L per minute MAX. This may need adjusting depending on inlet pressure.
- Page 19 Maintenance & Cleaning Sanitisation Guide NOTE: Failure to use sanitising products and processes approved by Borg & Overström will invalidate your warranty. This operation must only A sanitisation procedure is Turn off incoming mains Briefly press chilled be carried out by trained...
- Page 20 Turn on incoming water, Dispense water using the Leave the solution inside Pay particular attention to allow the service filter chilled button until the machine for sanitisation to the dispense faucet and cartridge to fill water appears pink. take effect (minimum 5 the push button controls.
- Page 21 Turn off water and briefly Remove the service filter. Fit new filter and turn on Pre-flush the new filter to press chilled dispense Retain service filter for incoming water supply. waste using the chilled button to release internal reuse. button until the water water pressure from the appears clear and is free machine.
- Page 22 To drain the hot tank proceed with the following steps: Remove the 2 screws holding the front Locate the drain pipe just behind the Remove the 2 screws holding the unit panel in place and lift off and set inlet expansion tank towards the front lid down and slide the lid off.
- Page 23 Advanced Troubleshooting Fault Diagnostics...
- Page 24 Problem/Report Possible Cause Suggested Action No Water Power supply turned Check the power supply has been fitted properly and turned on. Dispensing Water Pressure Check water flow through the regulator. Regulator Replace if necessary. Check Tap HMI Check fault codes. Control Water isolated from Check water inlet supply.
-
Page 25: Fault Codes
Problem/Report Possible Cause Suggested Action Temperature Mid heating cycle If the hot icon is pulsing then unit is not at correct temperature. Wait for solid not hot enough light. Temperature probe Ensure temperature probe is correctly installed or request replacement. not installed correctly or damaged... - Page 26 Technical Information T3/T3+ Chilled, Ambient & Hot Circuit Schematic T3/T3+ Chilled, Ambient, Sparkling & Hot Circuit Schematic...
- Page 27 Water Pathway - Chilled, Ambient & Hot...
- Page 28 Water Pathway - Chilled, Ambient, Sparkling & Hot...
- Page 30 Spares ProCore/ProCore+ Exploded Parts Diagram...
- Page 31 T3/T3+ Exploded Parts Diagram...
-
Page 33: Spares List
Spares List Part No. Description CSAH 720130 Main Control PCBA • • 701938 Top Panel Asm • • 720258 Right Panel Asm • • 720255 Left Panel Asm • • 720045 Front Panel Asm • • 701537 Pump • • 700085 Cooling Fan •... - Page 34 Tap Outlet Plated Silver • • 702369 Tap Outlet Plated Black • • 702381 Cup Stand Plated Black • • 702379 Cup Stand Plated Silver • • 720365 T3 CHA HMI Lens Asm • 720372 T3 CSAH HMI Lens Asm •...
