Summary of Contents for roger schult W2393 TiltBaxxEQ
- Page 1 W2393 TiltBaxxEQ 3 Band Filter-Combination Baxandall / Niveau-Filter Operating Manual Quick Guide W2393 TiltBaxxEQ Operating Manual for api ® 500 system Version 08.2022 roger schult D 50374 Erftstadt Peter-May-Str. 104 -1 -...
-
Page 2: Table Of Contents
Table of Contents Introduction Safety Notices Product Details Function, functional components and their effect Functional components Options to expand some functions of the W2393 TiltBaxxEQ Installation Installing the W2393 module in an api ® 500 system Specifications Box contents and compatibility Recycling Manufacturer, contact and support api ®... - Page 3 Dear customer, we sincerely thank you for purchasing our product. Our W2393 TiltBaxxEQ module for the api®500 system was built to ensure and exceed the highest manufacturing standards possible. We are adhering to all European and national guidelines currently in effect.
-
Page 4: Function, Functional Components And Their Effect
Function, functional components and their effect The W2393 TiltBaxxEQ is a combination of a tilt filter (level filter) and a Baxandall tone control. The tilt filter (sound balance) determines the turning point (tilt frequency) of the low and high frequencies around a switchable center frequency (500 Hz, 700 Hz, 1100 Hz). -
Page 5: Options To Expand Some Functions Of The W2393 Tiltbaxxeq
Please note that electric potential differences and electrostatic discharges (ESD) can destroy your api ® 500 system and the W2393 TiltBaxxEQ module. Please make sure to discharge any potential electrostatic charges by touching a plumbing pipe, heating pipe or any other piece of metal connected to earth before installing the W2393 TiltBaxxEQ module. -
Page 6: Specifications
Specifications Tentative spec sheet, 08/2022 Low band EQ, adjustable frequency 80 Hz / filter bypass / 110 Hz via switch Gain, continously variable +/- 12 dB range via fader Ti-EQ / Niveau Filter Gain, continously variable +/- 5 dB range via rotary control Frequency, 3-position switch 500 Hz / 700 Hz / 1100 Hz High band EQ, adjustable frequency... -
Page 7: Box Contents And Compatibility
Compatibility The compatibility certification records for this product are available upon request from the manufacturer. As all Roger Schult products, the W2393 is hand-crafted and precision-engineered in Germany. Recycling Please stay eco-friendly and dispose of all defective and obsolete devices at a certified collection facility according to local laws and regulations. - Page 8 Manufacturer roger schult german audio lab D 50374 Erftstadt Peter-May-Strasse 104 www.rogerschult.com info@rogerschult.com W2393 TiltBaxxEQ -8 -...
