Summary of Contents for Pytes ECOX 6
- Page 1 PORTABLE POWER STATION USER MANUAL...
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFETY INFORMATION Please read and understand all safety instructions carefully to ensure safe operation and application of the power station. Severe injury or property damage may be caused by failure to follow instructions. The loss caused by misuse of POWER STATION is not covered by our Warranty CHARGE NOW Please FULLY charge the POWER STATION as soon as possible once you receive it. -
Page 4: Feature Details
FEATURE DETAILS 1. LCD Display 2. AC Outlets 3. USB QC3.0 4. USB-TYPE-C 60W 5. Cigarette Lighter Output 6. DC Input 7. Flashlight 8. Wireless Charger 9. Handle 10. LED Light 11. Protective Cover 12. Power ON/OFF Button 13. LED Light & Flashlight ON/OFF Button 14. - Page 5 OPERATION GUIDE FUNCTION Power ON/OFF Button ECO Mode ON/OFF Button AC Output ON/OFF Button LED Lighting & Flashlight ON/OFF Button DC/USB Output ON/OFF Button 12: POWER ON/OFF POWER ON/OFF BUTTON is the Master Switch. Press POWER ON/OFF BUTTON to activate the DC/AC/ECO BUTTONS.
- Page 6 OPERATION GUIDE A: Battery Level B: Remaining Charging Time C: Input Power D: Remaining Usage Time E: Output Power F: Low Voltage Warning G: Temperature Warning H: Low Battery Alarm DETAILS DISPLAYED ON LCD Battery Level: The percentage figures and the number of battery bars represent remaining capacity.
- Page 7 GENERAL SPECIFICATIONS Model ECOX 6 Battery Lithium Battery Capacity 520Wh (22.2V, 23.4Ah) Dimensions L11.4*W7.9*H7.9 in Weight 14.3 lbs (6.49kg) Charging Temperature 32 to 104°F (0 to 40°C) Discharging Temperature 14 to 104°F (-10 to 40°C) DC Input 12-28V, 100W Max...
-
Page 8: General Specifications
GENERAL SPECIFICATIONS NOTICE: Available in multiple AC outlet types. Country Voltage/Frequency Country Voltage/Frequency Universal Israel 220V, 50Hz China 220V, 50Hz Australia 240V, 50Hz Japan 100V, 50Hz/60Hz 230V, 50Hz Philippines 220V, 60Hz Germany 230V, 50Hz Korea 220V, 50Hz France 230V, 50Hz South 120V, 60Hz 220V, 50Hz... - Page 9 OPERATION GUIDE From Solar Charger depend on the solar conditions From Car Port 12V From Wall Charger 100 - 240V RECOMMEND TO UNPLUG THE POWER STATION WHEN IT’S FULLY CHARGED. POWERING / CHARGING DEVICES Select the required output port by pressing the corresponding switch button (DC (DC/USB output), AC or ECO).
- Page 10 OPERATION GUIDE APPLICANCE WATTS REFERENCE Laptops 32" TV CPAP without heated (41.4Wh) (60W) humidifier (15W) DJ Drone Mini Fridge Smartphone (89.2Wh) (40W) (10Wh) Switch Floodlight Air Blower (16Wh) (4W) (600W) Please power/charge the appliances within the rated power of power station.
-
Page 11: Maintenance
MAINTENANCE Recharge as you need. There are no pre-designated intervals at which to recharge as long as the POWER STATION is used regularly. Avoid fully depleting the battery to 0%, it will impact the quality and lifespan of the battery. Periodically inspect all ports and wall chargers for any debris, dirt, damage, and corrosion. -
Page 12: Troubleshooting
TROUBLESHOOTING Indicator Phenomenon Solutions Please charge/power the devices within the rated AC Output power. Otherwise, the AC ON/OFF button will Overload Warning automatically turn off. Please charge/power the devices within the rated AC Output Off power. And then push the AC button to restart. Please charge/power the devices within the rated DC Output Voltage of DC and then press the ON/OFF... - Page 13 TROUBLESHOOTING Problem Solutions Remark Check if the AC adapter plug is fully Confirm whether it is a connecting plugged into the DC Input and Wall issue. Outlet. Unable to Charge Check if the adapter indicator is on if If the light is still off, please contact connected well.
- Page 14 WARNINGS The warnings in this manual cannot cover all possible conditions or situations that may occur. Please use the POWER STATION with common sense and caution. Always be aware of the environment around you while using it and ensure safe and responsible use of POWER STATION.
- Page 15 Please dispose of batteries and electronic Avoid extreme temperature. items according to local regulations. PYTES (USA) Energy, INC provides a limited warranty for the original consumer’s purchase, which covers the products due to defective workmanship and materials for 12 months from the date of purchase.
- Page 16 920 S Holgate St STE 107,Seattle,WA 98134 pytesusa@pytesgroup.com (+206) 407 4974 www.pytesusa.com Scan to follow us...
