Summary of Contents for Ger Detect UIG GROUND scanner

Page 2 Definition of the main unit buttons & leds • Section The device features and specifications • Section UIG GROUND SCANNER parts assembly • Section UIG GROUND SCANNER device operation steps • Section 7 The device parts and accessories • Section 8 The technical specifications...
Page 3 - Please be sure that all precautions are taken against risks. - Do not use your device while it is raining. - Turn on the device after you make sure that all parts are in place and connected. - Make sure that the device battery is fully charged before you start searching.
Page 4 ✓ UIG GROUND SCANNER is the first device of its kind in the world that functions with three professional scanning and imaging techniques with a...
Page 5 Definition of the main unit buttons & leds Tablet The arm of the imaging sensor The imaging sensor Tablet’s stand The device’s handle...
Page 6 The device features and specifications The UIG GROUND SCANNER device has multiple features to search for gold, buried treasures, precious metals and diamonds in the ground: -Three professional scanning and imaging techniques with a multi-tasking imaging sensor. -Super speed in capturing targets and locating them accurately.
Page 7 UIG GROUND SCANNER device parts connection Install the imaging sensor on the holder arm Install the handle on the arm Install the tablet base...
Page 8 Install the tablet on its own base Extend the arm by releasing the lock in the middle Plug the battery into the socket on the arm...
Page 9 UIG GROUND SCANNER device operation steps Turn on the battery by Turn on the tablet pressing the ON/OFF button for two seconds Launch the Ground Scanner application The following icons will appear within the application: Search systems: - Ground live scan system...
Page 10 Settings icon which contains: - A list of several languages supported by the application: (English - Arabic - Spanish - French - German - Portuguese) - Sound icon: to mute and activate the sound. - Vibration icon: to activate and cancel the vibration.
Page 11 Connection icon: to establish a Bluetooth connection between the tablet and the imaging sensor. Tap the connection icon to set up pairing between the tablet and the imaging sensor. Note: When establishing a connection for the first time, a window will appear to enter the password, which is the number 1000.
Page 12 Ground live scan system When you start using the live land scan system, a short video will appear simulating how to scan using this system. Click on the Start icon and wait for the calibration process to finish automatically. Note: The balance of the device must be maintained during the search by installing the blue dot in the middle of the circle icon.
Page 13 Calibration: To re-calibrate the device in case of switching to a different soil type during the search process. Mute and activate the device's sound. Back: To return to the main menu. Walk to start the land scan process - When the device detects a metal target, the area turns from green to red gradient and the red indicator rises in the chart...
Page 14 Wall live scan system When you start using the live wall scanning system, a short video will appear simulating how to scan with this system. Click on the Start icon and wait for the calibration process to finish automatically. Note: The device's balance must be maintained during the search by fixing the blue dot in the center of the circle icon.
Page 15 Calibration: To re-calibrate the device, move to a different type of wall or change the scanning direction during the search process Mute and activate the device's sound. Back: To return to the main menu. Shorten the arm's length and start the wall sweep.
Page 16 - When the device detects a metal target, the area turns from a green to red gradient and the height of the red indicator in the chart with a sound indicating the presence of metal. - When the device detects a void, the area turns from green to blue gradient, and the blue indicator decreases in the graph...
Page 17 3D imaging system - Choose the 3D imaging system, a screen will appear containing: A number of columns: It is to specify the number of vertical lines to be searched within. (The minimum possible number is 3 columns; the maximum possible number is 12 columns).
Page 18 - After selecting the soil type and pressing the Next button, a screen will appear to choose the scanning direction: Either scanning in a parallel direction or wipe in a zigzag direction, that is, in opposite directions, back and forth. Choose the scanning method, then click on the Start icon and wait for the calibration process to finish...
Page 19 The search screen will appear, which contains: - Mute and activate the sound icon. - Hide and show the spreadsheet. -Back to the main menu icon. A spreadsheet containing: Number of Steps Captured - Number of Columns Scanned - Value: which denotes the value of each captured image.
Page 20 Start the scanning process by pressing the photo button on the grip of the device or pressing the photo button on the tablet screen. Take a step not exceeding 30 cm, then walk, and follow the same steps until the completion of the photography process. The distance between the lines also must be 30 cm.
Page 21 After finishing the shooting process, an image of the target being photographed will appear on the screen of the tablet. Where the image is composed of a grid of squares, which expresses the number of steps and columns that have been scanned.
Page 22 2D Option 2D View Show the final result in the form of a 2D image with several icons for analyzing the image: Icon to show and hide the borders of the image, which are in the form of squares. Depth icon for potential targets (this icon appears only when there are confirmed targets and disappears when there is no target).
Page 23 1- Icon to show and hide the borders of the image, which are in the form of squares. 2- Depth icon for potential targets (this icon appears only when there are confirmed targets and disappears when there is no target). If there are two targets of metal in the same picture, the depth will appear for the stronger target only.
Page 24 Layers display option Layers display option Show the final result in a three-dimensional image consisting of layers (a layer indicating the presence of minerals - a layer indicating the presence of voids - a layer indicating soil - a layer showing salts).
Page 25 Increasing the distance of the height of the layers: to increase the clarity of the sizes of small targets. Reducing the height distance of layers: to reduce the height of large target sizes. 3- Switch between layers: separate the metal layer from the void layer and show them separately.
Page 26 3D option 3D View Show the final result in the form of a 3D image with several icons to control the image: Streamlined gradient: to show a streamlined color gradation of the targets. Sharp Gradient: To show a sharp color gradation of the targets. Cubic gradient: to show the color gradation of the targets in a geometric way.
Page 27 1- Streamlined gradient: to show a streamlined color gradation of the targets. 2- Sharp Gradient: To show a sharp color gradation of the targets. 3- Cubic gradient: to show the color gradation of the targets in a geometric way. (These icons are used to control the recognition of the image in order to be closer to the shape of the target in reality).
Page 28 The device parts and accessories A Carrying bag for the device protection Tablet Tablet’s stand The arm of the imaging sensor Imaging sensor Device’s handle 2500 mAh battery Battery charger Car charger...
Page 29 The technical specifications UIG Ground scanner Technical Specifications Device without sensor (Closed) 575 mm Dimensions Device with sensor (Closed) 600 mm Device with sensor (opened) 880 mm Bluetooth 2.4 GHz Radio Data processing speed 72 MHz Operating Temperature 0 C° to 70 C°...
