Summary of Contents for Sovereign AJ65A
-
Page 2: Table Of Contents
CONTENTS CONTENTS GENERAL SAFETY WARNINGS WARNING SYMBOLS IN THE BOX OPERATION MAINTENANCE AND STORAGE TECHNICAL DATA RECYCLING AND DISPOSAL UK PLUG GETTING HELP WARRANTY... -
Page 3: General Safety Warnings
GENERAL SAFETY WARNINGS WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term ‘power tool’ in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 4 surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
- Page 5 equipment such as a dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries. c) Prevent unintentional starting. Ensure the switch is in the 'off' position before connecting to a power source and/or battery pack, picking up or carrying the tool.
- Page 6 4) Power tool use and care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use the power tool if the switch does not turn it on and off.
- Page 7 etc., in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation. h) Keep handles and gripping surfaces dry, clean and free from oil and grease.
- Page 8 safety glasses. Following this rule will reduce the risk of serious personal injury. d. After long working periods, external metal parts and accessories could be hot. e. If possible, ensure the work-piece is firmly clamped to prevent movement. f. Your sander is a hand held tool; do not clamp your sander.
-
Page 9: Warning Symbols
WARNING SYMBOLS Warning Read the instructions Wear ear protection Wear eye protection Wear a dust mask Class II tool The product complies with the applicable European directives, and an evaluation method of conformity for these directives was done. Recycle unwanted materials instead of disposing of them as household waste. -
Page 10: In The Box
IN THE BOX Description 1. Speed selection 2. On/off switch 3. Dust outlet 4. Fasten clip 5. Sanding base 6. Dust collection box 7. Soft grip Accessories 1pc 80# sanding paper... -
Page 11: Operation
OPERATION NOTE: Before using your sander, be sure to read the instruction manual carefully. INTENDED USE This tool is intended for dry sanding of wood, plastic, filler and coated surfaces. 1. FITTING THE SANDING PAPER SANDING PAPER WITH CLIP SYSTEM (SEE FIG. A, B, C, D) FIT THE SANDING PAPER Fit the sanding paper over the base. - Page 14 B C2. USING THE DUST COLLECTION BOX (SEE FIG. E) A) ATTACH THE DUST BOX Your sander is equipped with a dust collection box (6), which is designed for collect dust. Insert the dust collection box into the rear dust outlet the sander. Then pull the dust collection box and make sure it is tightened securely on the dust outlet.
- Page 15 First, turn on the vacuum cleaner, and then turn on the sander. If you stop sanding, first turn off the sander and then turn off your vacuum cleaner. NOTE: Please pull the dust adaptor to make sure it is tightened securely to the dust outlet. 4.
- Page 16 5. USING THE SANDER The workpiece to be sanded must be secured. If it is small or it may move during sanding, it must be held in a vice or suitably clamped. Be sure to hold the sander firmly whilst it is on and apply it gently to the work, it may 'kick' on first contact.
- Page 17 If the surface is rough: Start with coarse grit (sold separately) and sand until the surface is uniform. Then use medium to remove any scratches left by the coarse grit. Then use finer grit (sold separately) for finishing the surface. NOTE: Always continue sanding with each grit until the surface is uniform.
-
Page 18: Maintenance And Storage
MAINTENANCE AND STORAGE IMPORTANT! Make sure that the tool has been thoroughly cleaned before storing it in a clean, dry and safe place, out of the reach of children. 1. Switch the product 'OFF' and disconnect it from the power supply before transporting it anywhere. -
Page 19: Technical Data
TECHNICAL DATA Model AJ65A Voltage/power 230-240V~ 50Hz/200W No-load speed 6000-12000/min Sanding pad size 90x187mm Protection class / II Weight 1.9kg NOISE AND VIBRATION DATA A weighted sound pressure (LpA) 80.6 dB(A), k=3dB(A) A weighted sound power (LwA) 91.6 dB(A), k=3dB(A) Vibrations ah=8.106 m/s... - Page 20 This tool may cause hand-arm vibration syndrome if its use is not adequately managed. WARNING! To be accurate, an estimation of exposure level in the actual conditions of use should also take account of all parts of the operating cycle, such as the times when the tool is switched off...
-
Page 21: Recycling And Disposal
RECYCLING AND DISPOSAL Waste electrical products should not be disposed with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice. UK PLUG If you need to replace the fitted plug then follow the instructions below. -
Page 22: Getting Help
GETTING HELP Our dedicated UK-based customer helpline is open 7 days a week to assist you with assembly, parts queries and technical support. We are open during office hours but you can always send an email via support@coreservice.co.uk. Our experts are here to get you back enjoying your garden in no time. -
Page 23: Warranty
WARRANTY This product is covered by a 1 year warranty. The warranty covers any manufacturing defect in materials, workmanship and finish. Any claim under this warranty must be made by going to your nearest Homebase store, taking your proof of purchase with you, and claims must be made within 12 months of the date of purchase.
