FAMILIARIZING YOURSELF WITH YOUR 2.4GHZ RADIO SYSTEM
You car is equipped with a 2.4Ghz radio system that once bound with the ESC will provide you interference free use.

BATTERY INSTALLATION

1. Open the battery cover as shown and install 4 x AAA size batteries, positioning the polarity
as indicated on the battery box and make sure the batteries make good contact to the
contacts therein.
2. Close cover after batteries are installed.
Notes:
• Low battery alarm: When the battery is lower than 4.2V the G.LED on the panel will
flash slowly.
• When installing the battery, please pay attention to the positive and negative poles of the
battery to avoid installation errors. (As shown on the right).
FTXOBminiX6ixer.Man.indd 3 FTXOBminiX6ixer.Man.indd 3
Please read and understand the instructions and functions before operating.
