Summary of Contents for Nexen RL15
- Page 1 USER MANUAL Spring-Engaged Rod/Shaft Lock RL15 FORM NO. L-21170-A-0803 FORM NO. L-21170-A-0803...
- Page 2 In accordance with Nexen’s established policy of constant product improvement, the specifications contained in this manual are subject to change without notice. Technical data listed in this manual are based on the latest information available at the time of printing and are also subject to change without notice.
-
Page 3: Installation
Support the load before disengaging the Rod Lock. Failure to support the load could result in serious bodily injury. 1. The Nexen rod lock is equipped with a 1/8 inch 2. The Nexen rod lock is equipped with a 1/16 inch NPT port for the air inlet. - Page 4 AIR PREPARATION For long life, Nexen’s Rod Lock requires clean and pressure regulated air (filtered to five mictrons or better). Nexen does not recommend lubricated air for this product. ROD LOCK ASSEMBLY Air Inlet Internal Vent ITEM DESCRIPTION ITEM DESCRIPTION...
-
Page 5: Warranty
Buyer shall be obligated to pay or which Buyer may incur based upon, related to or arising out of its contracts with its customers or other third parties. In no event shall Nexen be liable for any amount of damages in excess of amounts paid by Buyer for Products or services as to which a breach of contract has been determined to exist.
