PC4010 v3.0 • Installation Manual
DLS-2 v1.3
WARNING: This manual contains information on limitations
regarding product use and function and information on the
limitations as to liability of the manufacturer. The entire
manual should be carefully read.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC4010 and is the answer not in the manual?

Questions and answers

Summary of Contents for Maxsys PC4010

  • Page 1 PC4010 v3.0 • Installation Manual DLS-2 v1.3 WARNING: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read.
  • Page 2 WARNING AVIS: L’étiquette de l’Industrie Canada identifie le matériel homo- Please Read Carefully logué. Cette étiquette certifie que le matériel est conforme à certaines N o te t o I n s t al le r s This warning contains vital information. As the only individual in contact with system users, it is your normes de protection, d’exploitation et de sécurité...
  • Page 3: Table Of Contents

    Tab le o f C o nt e nt s Section 1: Introduction 8.2 Automatic Arming ............24 1.1 Out Of The Box ..............1 Section 9: Entry and Exit Delay 1.2 Specifications and Features ..........1 9.1 Entry and Exit Delay Times ..........25 Section 2: Installation and Wiring 9.2 Entry and Exit Delay Options .........
  • Page 4 PC401 0 Wiri ng D i ag ra m NOTE: Do not remove the foam from the back of the circuit board.
  • Page 5: Section 1: Introduction

    1.1 Out Of The Box Expansion Capabilities • Up to 64zones total using Please verify that the following components are included in the PC4010 package. • PC4108A 8 zone input modules • PC4116 16 zone input modules PC4050C or PC4001C cabinet •...
  • Page 6: Section 2: Installation And Wiring

    S e ction 2: Installa t i o n an d Wi r i ng 2.1 Planning the System 2.2 Terminal Descriptions The following terminals appear on the PC4010 Alarm NOTE: This system should be installed and serviced by Control Panel: qualified security professionals.
  • Page 7: Current Ratings - Alarm Control Panel And Modules

    ** See “Combus Current Calculation Chart” at right. NOTE: For UL, ULC and Fire applications, the total standby AND alarm current cannot exceed 900mA. PC4010 Module Ratings The current draw of compatible PC4010 modules is listed below: Device ..........Current Draw (mA) Keypad (LCD45XX)............50 PC4108A Zone Expander ..........
  • Page 8: Zone Wiring

    the wire to calculate the maximum distance (see PC4204 Current Requirement “Capacitance Limits” below). AUX - 1.5A available for devices connected to the AUX 4. The total capacitance of the Combus wiring must not terminal, including devices connected to relay outputs exceed 80nF (see “Capacitance Limits”...
  • Page 9: Specialized Zone Wiring

    S e c t i o n I n s t a l l a t i o n a n d W i r i n g Single End of Line (EOL) All Single EOL zones have a 5600Ω resistor across them. If the zone is shorted or open, it will be violated.
  • Page 10: Programmable Output Wiring

    • input debounce time • addressable reporting and confirmation time • processing time required by the panel to activate the output These response times are worst case and typical response will be faster. 1 to 32 devices on the loop ........ up to 2.5s 33 to 56 devices on the loop ......
  • Page 11: Wiring Powered Devices (Aux, Saux+)

    S e c t i o n I n s t a l l a t i o n a n d W i r i n g 2.11 Bell Output Wiring (BELL and BELL For longer wire runs, you can These terminals are used for powering split bells, sirens or other devices requiring...
  • Page 12: Applying Power (Ac And Battery)

    There is a danger of explosion if the bat- is controlled by a switch. tery is incorrectly replaced. The PC4010 monitors the presence of AC. Upon the loss If the lithium battery stops working, return the circuit of AC power a trouble condition will be generated. The board to DSC Ltd.
  • Page 13: Section 3: How To Program

    Press [#] to return to the previous menus and to exit the installer programming mode. The PC4010 is programmed via a menu system. Use the arrow keys (<>) to scroll through different menu options The arrow keys (<>) will appear in the top right-hand and press the [*] key to select the menu option displayed.
  • Page 14: Programming Hexadecimal Data

    Hex letter (A = 1, B = 2, C = 3, up to F = 6). Once the digit is entered, the control panel will automatically return to the decimal programming mode. For example, to enter data ‘ABCD’ on a PC4010 you would enter: [*], [1], [*], [2], [*], [3], [*], [4]...
  • Page 15: Section 4: Module Enrollment

    S ec t ion 4 : M o du l e E nro l l me nt 4.1 Enrolling Keypads and Modules Zone Expanders Once the wiring of all keypads and modules is complete, NOTE: Enroll all zone expanders before assigning zones to PC4820 and AML devices.
  • Page 16: Confirming Modules

    Any zone from zone 009 to 064 on the PC4010 can be used as an AML zone. If the detector is not connected to the PGM terminal, the zone will not be enrolled.
  • Page 17: Section 5: Partitions And Zones

    S e c t io n 5 : Par ti t i o ns and Z o n e s 5.1 Zone Supervision [F] Enabled (Y)..........see Section 6.5 Ref # [000204] “Zone Supervision” [A] Enabled (Y)..........see Section 6.5 The control panel must be instructed to supervise either [P] Enabled (Y) ..........see Section 6.5 No End of Line, Single EOL or Double EOL zone loops.
  • Page 18: Adding Zones To Partitions

    Scroll to the partition to be deleted, then press [*]. When • When a global zone is manually bypassed, as soon as a partition is deleted, the programming assigned to it any partition the zone is assigned to is disarmed, the will not be erased.
  • Page 19 S e c t i o n P a r t i t i o n s a n d Z o n e s Standard Fire (07) [0] Clear Display will clear the entire label. [1] Clear to End will clear the display from the character When a Standard Fire zone goes into alarm, the panel above the cursor to the end of the display.
  • Page 20 Each zone type has different attributes enabled by • 24 Hr Freeze (21): This zone is audible. default. For a list of these default settings, see the PC4010 • 24 Hr Holdup (22): This zone is silent. It does not acti- Programming Worksheets.
