Summary of Contents for Matec V12
- Page 1 Digital Voice Recorder Watch User's Manual - V12 *Please read this user manual carefully before use* *Please use the original data cable when connecting to computer*...
- Page 2 Important Note Before Use ★ Check Video Instruction at device disk on computer or Youtube https://youtu.be/UayzGsHmmYA link before use. ★ For Most mal-function problem, format or reboot(check software and instruction at device drive on computer) works. ★ For any problem, please contact us for help before return or refund. Gurantee 100% fast satisfaying customer service.
-
Page 3: Product Illustration
Product Illustration Device: Horn OFF-Save Recording Volume Up/ Next ON-Recording Volume Down/ Previous Earphone/Charge /USB Port Power on/Off Play/Pause/Confirm/Return ★ Note: ► Press: after pressing button, release it immediately. ► Long press: after pressing button, hold it on for 3-5 second. ►... - Page 4 Recording Operation 1. Turn On/Off ① Turn On: at screen “off” state, long press the “ ” button. ② Turn Off: long press the “ ” button until the number ①②③ light up in sequence, then device will be power off. 2.
- Page 5 ③ Save Voice Activated Recording File: push recording button to the “OFF” position to save recordings. ④ Turn Off Voice Activated Recording Mode: long press the “ ” button to return to main menu interface, choose "Recordings-- >AVR mode-->Off" . ★Note: The display screen will show “VOX ON”...
- Page 6 5. Recording While Charging Step 1: connect the device to computer/charger through original USB cable. Step 2: long press “ ”button, push recording button to “ON”position. Step 3: push recording button to “OFF” position to save recordings. 6. Timing Recording- Timer Step 1: Set Timer Start Time: choose "Recordings-->Timer-->Start".
- Page 7 Other Recording Set Manage all recording files, including playback, deletion, Recording library selection, etc. Files are named by Year/Month/Day/Hour/Minute/Second. Record Format Supports MP3 and WAV format. Note: Please choose a format supported by media player on your computer /phone. 6 bitrates(256kbps-3072kbps) to choose , the higher the Set rec bitrate bitrate, the clearer the sound quality and the larger disk space.
- Page 8 Playback Operation 1. Playback / Pause ① Choose Recording Files: in the main menu interface, choose "Recordings-->Recording library". ② Playback Recording Files: press the “ ” button to play recording. ③ Pause Recording Files: press the “ ” button to pause. ④...
- Page 9 ① Delete Current Playing File: long press ''+'' and choose “Delete”, then will delete current file. ② Delete All File: Step 1 - Long press the “ ” button to return to main menu interface. Step 2 - Choose the "Recordings-- >Recordings library-->Delete All".
- Page 10 Displaying Settings Set Brightness/Backlight Time/Screen Saver Date and Time Set Time and Date Password Set Password Power Off Set Automatic shutdown after no operation (min) Sleeper Time Set automatic shutdown time Volume Limit Set the maximum volume for playback Language Language Setup Tools Calendar,Stopwatch...
- Page 11 1. Displaying Settings ① Brightness setting: adjust the brightness of the device's display. ② Backlight Time setting: set the time for the device to enter the screen saver or the screen to turn off when there is no operation. ③ Screen Saver setting: 3 digital clock screensavers to choose, press''+'' /''-'' to select , and press “...
- Page 12 3. Set Password ★ Note: After the password function is turned on, you will need to enter password every time you turn on the machine to unlock the machine. ① Turn on Password: in the main menu interface,choose "Set-- >Password-->Swith-->On". ②...
- Page 13 5. Sleeper Time ★ Set automatic shutdown time. e.g : If set 30 minutes, the device will shut down automatically after 30 minutes. 6. Language Setup The device has 28 language to choose.You can select the language that you like. ★...
-
Page 14: Extended Function
8. Format at device When the device has disk-related problems like messy file name, wrong file memory size or wants to clear data, you can try to format the device. ★ Note: This action will delete all files, please back up your files to computer before do it. - Page 15 Displays the internal files of the machine in the form of folders. All recording files in “RECORD” folder. All music files in “Sounds” folder. You can play/delete recording/music files in the menu. Delete file: Select a file, long press “+” to delete the file, and then press “...
-
Page 16: Connecting To Computer
Connecting to Computer ● Turn off device first.Connect the device to computer through original White USB cable included. Recording File path “My PC(Window)/Finder(Mac) - VOICE-RECORD” Files can be transferred quickly between the device and computer. ★ Note: WindowME/2K/XP 7,8,10 1. Support system are Vista,Mac OS10 or above. - Page 17 OTG Connection with Phone ► Connect with Android Phone: Turn off device first.Connect original usb cable & 2-in-1 OTG cable. Plug original USB cable to recorder first, then plug 2-in-1 OTG cable into Andriod phone. Open “Record disk- Huashen USB drive” at Android phone and then manage files.
-
Page 18: Specification
Precautions ● When charging or connecting to computer, turn off the device first. Please use“Safely Remove Hardware”(in Windows) or “Eject”(in Mac os) when disconnect device from computer. ● After finish recording, push recording button to “OFF” to save the recordings,otherwise the recordings might be lost or damage. ●... - Page 19 Voice Recorder Product Product 1.63oz Watch Weight Play MP3/WAV/W Product Size 0.59x1.65x9.52 in Format Recording WAV/MP3 Distortion <0.008% Format Frequency Sampling 20Hz-20KHz 48KHz Response Rate Signal to noise Headphon >90db 3.5mm ratio e Interface Charging 256-1536 kbps Bit Rate 2-3 Hour Time Support Window...
-
Page 20: Troubleshooting
Troubleshooting 1. How to format or reboot device? ✱For most malfunction problem, Reset, Format or Reboot the device can solve these problem. ① Reset: Press the " " button for 15 seconds, the device will reset and restart. If this doesn't work, please try method 2 or 3. ②... - Page 21 Troubleshooting 2. It doesn't work like do not record or can’t turn on? · No power or no memory/ · Far distance or low Root causes: voice that can’t detect sound/ · Wrong operation/ Product software crash/ · Product damage for non-quality related problem. ·...
- Page 22 Troubleshooting 4. The battery is running out too fast, how to extend the usage time? If you just use it as a watch, you can choose a screen saver, turn off the device, and press the ''+'' /''-'' to check the time. Turn down the brightness of the screen.
- Page 23 Troubleshooting 6. I connect this device to computer but nothing shows up at computer? ﹡ Not original USB cable/ ﹡ Damaged original USB Root Causes: cable/ ﹡ Damaged USB port/ ﹡ Not compatible operaion system/ ﹡ Mac book Series/ ﹡ Other unknown reason. Follow video instruciton - Resolution: to solve the problem/ ﹡...
- Page 24 Troubleshooting 7. Voice activated recording does not work? · Not set up function in a right way/ · Far distance Root causes: or low sound that device`arefully and set up correctly/ · Record at certain distance and sound level(over 50db)/ · Reboot the device/ ·...
- Page 25 Troubleshooting 9. The recording quality is poor? · The recording environment has some static Root causes: when recording/ · Recorder is not placed in stable place and has friction when recording/ · The earphone problem · Try to record at Resolution: quite occasions avoid friction...
- Page 26 Troubleshooting · Use cable charge/ · Use original Resolution: original white usb usb cable to charge other device and contact us for replacement if damaged/ · Contact us for free replacement for quality-related problem/ · Charge with suggest current 500mA-1000mA voltage 5V if charged by charger/ Suggest charging over...
- Page 27 Troubleshooting ● If need digital manual or any tools or reboot software, please contact us freely at matechcsd@gmail.com for download link and step-by-step instruction. 12. For any problem, please contact us freely at matechcsd@gmail.com with your problem detail before return or leave comment, we'll offer you satisfying resolution.
