BAAG009GY
12 X 15 SOLARIUM
ASSEMBLY INSTRUCTIO
NS
DO NOT DESTROY THE BOXES UNTIL COMPLETELY ASSEMBLED
PLEASE VERIFY THE CONTENT OF EACH BOX AGAINST THE LIST OF PARTS
Three adults required for assembly
Base Dimensions 12' ½"x15'6",
Largest Dimensions 13'6"x16'11"
APPROX.
Overall Height 110''
(see pg.16)
BAAG009GY.EN
PAGE -
1
Advertisement
Summary of Contents for Erommy BAAG009GY
- Page 1 BAAG009GY 12 X 15 SOLARIUM ASSEMBLY INSTRUCTIO DO NOT DESTROY THE BOXES UNTIL COMPLETELY ASSEMBLED PLEASE VERIFY THE CONTENT OF EACH BOX AGAINST THE LIST OF PARTS Three adults required for assembly Base Dimensions 12’ ½”x15’6”, Largest Dimensions 13’6”x16’11” APPROX.
- Page 2 Consult with your local governing authority / local municipal codes regarding installation of temporary structures before purchase or assembly. Some jurisdictions may require permits for, or otherwise regulate, installation and use. For assistance with assembly, installation, parts, or customer service, contact EROMMY Customer WARNING: ・...
- Page 3 The product is not warranted in the event it has been improperly anchored. We reserve the right to replace or repair any defective product or parts at our discretion. No change to the unit is allowed. This will void your warranty. BAAG009GY.EN PAGE -...
- Page 4 12” piece of wood Based on the location, decide where you would like to posi�on the two (2) doors panels which can slide open to the le� or the right, your choice. Slide le� to open Slide right to open BAAG009GY.EN PAGE -...
- Page 5 (E) to affix the panel and door frame. When assembling angled panels (A, D), you should put the two panels at 135 degree angle then use the angled connecting pieces (I) and (J) to affix the panels together. BAAG009GY.EN PAGE -...
- Page 6 2. Secure the bo�om door rail (G), using a bolt (Cc) with a washer (Gg). 3. Paying careful a�en�on to whether it is the le� (Dd-L) or right (Dd-R) latch, use bolt (Bb) to affix the door latch onto the frame. Repeat steps 2 and 3 for the second door. BAAG009GY.EN PAGE -...
- Page 7 Note: Do not �ghten the bolts right away as you may have to adjust the angle when inser�ng the PC roof panels. BAAG009GY.EN PAGE -...
- Page 8 First remove the protec�ve layer from the PC roof panels, then insert them (Y, Aa, Ll, Qq) into the roof ra�ers according to the below drawing instruc�ons. Note: the side that had the protec�ve layer should be face down. BAAG009GY.EN PAGE -...
- Page 9 A�er the installa�on on the middle roof joints complete, insert the bottom PC roof panels (Jj, Kk, Mm, Rr) according to below drawing. They should overlap about two inches under the upper PC roof panels and into the aluminum middle roof joints. Before A�er BAAG009GY.EN PAGE -...
- Page 10 (Bb) and roof joint (R), �ghten securely. Step 11: Once the installa�on of the edging complete, start affixing the roof cross bars (T, V, X, Tt) using bolt (Ff). Affix the top cross bars (Uu) onto the roof ra�er (L) using bolt (Ff). BAAG009GY.EN PAGE -...
- Page 11 3. Note that this unit is not waterproof. For best protec�on against rain, close the windows of each frame with the outside window in the center, and the inside window at the top. BAAG009GY.EN PAGE -...
- Page 12 Suggestions The below mentioned are only suggestions in order to permit drainage, these will vary depending on your flooring – material, flatness and slope. BAAG009GY.EN PAGE -...
- Page 13 08-140-32 135° ANGLED 135° ANGLED OUTSIDE INSIDE CONNECTOR CONNECTOR Length 200.6 Length 200.6 08-141-32 08-142-32 ROOF ROOF RAFTER RAFTER Length 239.7 Length 211 cm 08-178-32 08-179-32 CENTRAL TOP CAP 08-145 08-146 MIDDLE MIDDLE ROOF JOINT ROOF JOINT BAAG009GY.EN PAGE -...
- Page 14 Length 120.6 cm 08-155 (24 ¼”X42 ¼”) 08-156-32 TOP ROOF SCREW LEFT PANEL 08-157 (24 ½”x46 ½”) 08-158-32 TOP ROOF BOLT CORNER PANEL 08-165-32 08-161-32 RIGHT DOOR BOLT LATCH Dd-R 08-169-32 08-167-32 LEFT DOOR SCREW LATCH (M6x63.5mm) Dd-L BAAG009GY.EN PAGE -...
- Page 15 RAIL END SCREW 08-172 08-170 (41 ¼”x42 ¼”) MIDDLE TOP ROOF ROOF JOINT CENTER PANEL 08-171 (41 ¼”x43”) 08-173 BOTTOM ROOF EDGING CENTER PANEL 08-174 08-175 ROOF CROSS TOP ROOF CROSS BAR 12-037 12-047 FEMALE BOLT BOLT Cc-2 BAAG009GY.EN PAGE -...
- Page 16 Note: The dimensions are approximate. BAAG009GY.EN PAGE -...
