- Page 1 DET-6C/12C INSTALLATION OPERATION MANUAL Digitize, Inc. 158 Edison Road Lake Hopatcong, NJ 07849 Tel: (973) 663-1011 Part Number 700174-0000 Fax: (973) 663-4333 Issue Revision: D E-mail: <info>@digitize-inc.com Issue Date: 02/16 Website: http://www.digitize-inc.com...
- Page 2 The DIGITIZE logo is registered trademark of Digitize, Inc.
- Page 3 E-Mail: info@digitize-inc.com Website: http://www.digitize-inc.com This manual has been prepared by DIGITIZE, INC. for use by its licensees, distributors and customers. The information contained herein is the property of DIGITIZE, INC. and may not be copied, disclosed or reproduced, in whole or in part, without the prior written approval of DIGITIZE, INC.
-
Page 5: Table Of Contents
INDICATORS LEDS SPECIFICATIONS 1.9.1 CURRENT CONSUMPTION 1.9.2 DEMENSIONS 1.10 APPLICABLE PUBLICATIONS SECTION 2 PROGRAMMING THE DET-6C/12C EPROM DIGITIZE, INC. DET-6C/12C PROGRAM DATA LOCATIONS PROCEDURE FOR USING THE DET-PROG PROGRAMMER 2.2.1 TIMING AND OPTIONS 2.2.2 SET TELEGRAPH CODES SECTION 3 INSTALLATION... -
Page 7: Section 1 General Information
The unit is housed in a cast aluminum cottage shell and is suitable for mounting on any wall. The DET-6C can be used on the same loop with mechanical Fire Alarm Boxes. The DET-12C has twelve EOL resistors and a pull handle for zone 1. -
Page 8: Activation Of Inputs
The DET-12C uses 2 of the 6 zone boards. When a zone input goes into Alarm, the DET-6C/12C will send the code number for the unit followed by the code that was selected for the zone that went into Alarm. -
Page 9: Number Of Rounds
EPROM. The standard value on the master EPROM is 1/4 second, with a value of 06, which represents approximately 6/24. See Section 2.2.1, Step 2 for calculation. EPROM 27C512 A blank 27C512 EPROM is supplied with each DET-6C. The 27C512 EPROM is programmed using Digitize DET-PROG programmer. The DET-12C is supplied with 2 EPROMS. -
Page 10: 1.10 Applicable Publications
DET-6C/12C INSTALLATION AND OPERATION MANUAL 1.10 APPLICABLE PUBLICATIONS National Fire Protection Association (NFPA) standards 72 proprietary, 1221. DIGITIZE, INC. 700174-0000 REV.D 02/16... -
Page 11: Section 2 Programming The Det-6C/12C Eprom
SECTION 2 PROGRAMMING THE DET-6C/12 EPROM One 27C512 EPROM is factory supplied with each DET-6C. The EPROM stores the data that is transmitted when any input is activated. The DET-12C is supplied with 2 EPROMS. In order to program the DET-6C/12C EPROM for operation, the information can either be sent to DIGITIZE, INC with the purchase order for the DET-6C/12C or programmed using the DET-PROG EPROM programmer for the PC. - Page 12 DET-6C/12C INSTALLATION AND OPERATION MANUAL ALARM CODES TROUBLE CODES ADDRESS USER ADDRESS USER 789 Zone 1 78F Zone 1 78A Zone 2 790 Zone 2 78B Zone 3 791 Zone 3 78C Zone 4 792 Zone 4 78D Zone 5...
- Page 13 DET-6C/12C INSTALLATION AND OPERATION MANUAL ADDRESS DESCRIPTION USER Choice of Bulldog option 01 = YES (transmits over any unit on the line) (No PNIS) 00 = NO (has PNIS) Buzzer activation time. 00 to 9.9 in tenths. (40 = 4.0 minutes, standard)
- Page 14 DET-6C/12C INSTALLATION AND OPERATION MANUAL The following code number locations contain five digits followed by 00. If a box contains less than five digits, fill the balance of the box number with 00’s. The sixth digit is always 00. For example, Box 123 is represented by 1, 2, 3, 00, 00, 00.
-
Page 15: Procedure For Using The Det-Prog Programmer
If DIGITIZE, INC makes an error, our only responsibility will be to program another chip This information may be loaded by someone other than DIGITIZE, INC by using the DET-6 EPROM Programmer for the PC. The programmer software is easily installed on your PC with the instructions supplied. -
Page 16: Timing And Options
DET-6C/12C INSTALLATION AND OPERATION MANUAL When you first load the program, the following screen will appear: DET-PROM A DIGITIZE DET-6B UTILITY DIGITIZE, INC. LAKE HOPATCONG, NJ PHONE: (973) 663-1011 © 1990-1994 All Rights Reserved Version: XXX XX, XXXX Written by: Tom Walsh, WN3L... - Page 17 Load Old Site Data – Permits the user to recall a complete setting, by name, that was previously saved. Many of the settings for the DET-6C/12C will be the same for each city or jobsite. The most common change in the programming is the box number that will be transmitted.
- Page 18 DET-6C/12C INSTALLATION AND OPERATION MANUAL 3. duAl line? _____________ LOC 7F2 Dual line option available for DET-6D only. 4. Index type: _____________LOC 7B8 OPEN or CLOSED (municipal is open) 5. busy Line: Waiting time for a busy line. _____________LOC 788 (20 = 2.0 minutes, standard).
- Page 19 2.2.2 Set Telegraph Codes When Set Telegraph Codes is selected, the screen display corresponds to the data provided in Section 2.1. DIGITIZE DET-6C/12C Program Data Locations, but not in the same order. All default values are already entered in the address locations.
- Page 20 DET-6C/12C INSTALLATION AND OPERATION MANUAL 3. Box number for zone 3: ____________________ LOC 7D4 – 7D9 (Up to five digits may be entered). 4. Box number for zone 4: ____________________ LOC 7DA – 7DF (Up to five digits may be entered).
- Page 21 DET-6C/12C INSTALLATION AND OPERATION MANUAL 11. If a zone goes into trouble condition, how many rounds of the code should be transmitted? (3 rounds is standard) Trouble is an open to the EOL resistor. Enter zero if no rounds are to be sent.
- Page 22 For zone 5 ________________________ (ROUNDS) LOC 7AE For zone 6 ________________________ (ROUNDS) LOC 7AF The DET-6C/12C is capable of transmitting a code when it detects that its battery voltage is below a present level. The following locations have to do with transmission (or non- transmission) of a code when a low battery condition is detected.
-
Page 23: Section 3 Installation
Install the conduit and wiring into the shell, as per local electrical codes. The DET-6C/12C has a buzzer that will activate when there is an open or trouble. If the trouble relay output of the DET-6C/12C is connected to the FACP trouble input, the buzzer can be disabled by cutting the jumper J1. - Page 24 DET-6C/12C INSTALLATION AND OPERATION MANUAL (+) line on the terminal block right of the boards for both the DET-6C and DET-12C. Connect trouble contacts to the FACP local trouble input. A FORM “C” contact is supplied for this purpose. Terminal 7 is common (C), Terminal 8 is normally closed (NC) and Terminal 9 is Normally Open (NO).
- Page 25 DET-6C/12C INSTALLATION AND OPERATION MANUAL FIGURE 1 – WIRING DIAGRAM DET-6C DIGITIZE, INC. 700174-0000 REV.D 02/16...
- Page 26 DET-6C/12C INSTALLATION AND OPERATION MANUAL FIGURE 2 - WIRING DIAGRAM DET-12C DIGITIZE, INC. 700174-0000 REV.D 02/16...
-
Page 27: Section 4 Theory Of Operation
When the time has elapsed the microprocessor will activate relay K2 to send out the code for the alarm input. If the DET-6C/12C senses a code on the 100mA line, it will wait for the line to clear before trying to send its code. -
Page 29: Section 5 Maintenance
If the voltages are correct and the DET-6C/12C is not working, the box guts should be replaced with a spare and the service left to qualified service personnel. -
Page 30: Battery Maintence
The battery should be checked at least once every six months to be sure that it has the ability to run the DET-6C/12C. To test the battery, remove the AC power from the unit and measure the 12 VDC going to the DET-6C/12C PCB. Should the voltage fall below 12 volts within the first 30 minutes the battery should be replaced. - Page 31 Digitize by telephone or in writing. Buyer will prepay all freight charges to return any products to the repair facility designated by Digitize and include the RMA number on the shipping container. Digitize will, at its option, either repair the defective products or parts or deliver replacements for defective products or parts on an exchange basis to Buyer, freight prepaid to the Buyer.
