- Page 1 DA601W Wireless Audio Amplifier Instruction manual w w w . p e a r l l e r . c o m...
- Page 2 Hoping that you will be satisfied of your purchase, we thank you again for your trust in our brand and we invite you to read our website www.pearller.com where you will find the whole range of Pearller products, along with useful information and updates.
- Page 3 Cautions and warnings • Read carefully the instructions given in this manual and follow them strictly. • Keep this manual for future reference and include it if you give the product to another user. • This device works with dangerous 230V mains power. Do not open, do not disassemble and don’t try to operate inside.
- Page 4 Before making any connection, be sure that the unit is unplugged from the power outlet. All connections must be made with the appliance turned off. Impedance speaker connection This type of connection does not allow to limit individually the power of each single speaker, but it gives the possibility to obtain higher performances.
- Page 5 Constant voltage speaker connection It is the type of monophonic system realized in shops, conference rooms, churches and in any place where a uniform sound reinforcement is necessary, with maximum ease of installation and use. Only 2 wires are used, starting from the amplifier and getting up to the last speaker. On the amplifier you have to connect a wire to the “com”...
-
Page 6: Remote Control
Front ON/OFF BUTTON IR RECEIVER WINDOW MODE LED INDICATOR USB PORT 3.5MM AUX INPUT blue Model: PAA 100T VOLUME CONTROLLER MODE REPEAT SD/MMC CARD MIC 1 MIC 2 PHONO BASS TREBLE POWER Back INPUTS MUTE SPEAKER OUTPUTS PHONO FUSE 12-24V 4Ω... - Page 7 The MUZO Player App 1 - Download the MUZO Player application The MUZO player application is available on Google Play and Apple Store platforms. Below are the download links for each platform. 2 - Connection 1. Connect your smartphone to the device’s WI-FI network. 2.
-
Page 8: Speaker Outputs
4. Once the device is connected, click on «Add device». 5. The following page gives you the status of the WI-FI connection. 3 - Rename your device Once your device is connected, you can rename it. This will allow you to identify it among other connected devices. MIC 1 MIC 2 PHONO... - Page 9 4 - Devices control This window allows you to manage the different device connected to the application. Add a device Refresh list button Access to settings Device 1 Stereo adjustment Device 2 Volume bar Start playback on all devices 5 - Playback window Access to favorites Access to media sources...
- Page 10 6 - Preset content Through this window you can quickly access different services. These pre-set contents are shortcuts that prevent you from setting up media sources each time you use them. 7 - Media sources Search function Phone memory Shared music Playlists Recently listened Streaming or web radio platforms...
- Page 11 8 - Service Management In this window you can enable or disable online broadcasting services so that only those you have subscribed to appear in your list. 9 - Multi-zone management If you have several wireless amplifier devices spread over several zones, you can choose either to play different music in each zone or to play the same music over several zones simultaneously.
-
Page 12: Wiring Procedure
Wiring Procedure Powered speakers Mains transformer/5V Jack/Jack cord RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER, CONTAINS NO USEFUL PARTS FOR THE USER. REFER TO QUALIFIED STAFF FOR ASSISTANCE. This symbol alerts you of the presence of important operating and maintenance instructions, in the manual or in the documentation accompanying the product. -
Page 13: Technical Specifications
TECHNICAL SPECIFICATIONS Power 2 x 30W Impedance 8 Ohms Frequency Response 20Hz - 20kHz Sensitive Ratio 90 dB Output Interface RCA Stereo Operating Voltage 100-240V AC to 12V DC Adapter (included) Operating Temperature -50C - 40C Wireless Connectivity Support 802.11 b/g/n standarts Wired Connectivity Connection to wired Ethernet Wifi Index:...
