USER
GUIDE
V1.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hybrid and is the answer not in the manual?

Questions and answers

Related Manuals for Triminator Hybrid

Summary of Contents for Triminator Hybrid

  • Page 1 USER GUIDE V1.3...
  • Page 2 POWER PACK CONTROL OVERVIEW VACUUM STRENGTH TRIMMER TILT SETUP FEED RATES OPERATING CONDITIONS UNCRATING THE HYBRID™ ASSEMBLY / DISASSEMBLY HOPPER AND CHUTE INSTALLATION AND REMOVAL TUMBLER COVER INSTALLATION AND REMOVAL TUMBLER INSTALLATION AND REMOVAL POWER PACK REMOVAL / INSTALLATION FRONT & REAR PANEL REMOVAL & INSTALLATION...
  • Page 3 VACUUM SYSTEM INSTALLATION AND REMOVAL TRIM AND KIEF BAG INSTALLATION CONNECTING TRIMMERS IN TANDEM OPERATION BEFORE YOU START MACHINE START-UP SEQUENCE MACHINE STOP SEQUENCE TRIMMING PLANT MATERIAL TRIMMING TIPS CLEANING YOUR TRIMMER PRESSURE WASHING HAND-CLEANING THE POWER PACK AND FAN MOTOR MAINTENANCE SERVICING YOUR TRIMMER SAFETY PRECAUTIONS...

  • Page 4: Safety Message

    All operators must read and understand this User Guide and be trained in the safe operation and use of the Hybrid™ Trimmer. We recommend the owner of this equipment develop a standard operating procedure specific to each worksite to address any local hazards or other conditions not outlined in this User Guide.
  • Page 5 Do not operate the Hybrid™ Trimmer when fatigued. Be alert. If tired while operating the device, take a break. Fatigue may result in loss of control. Working with any equipment can be strenuous. If you have any condition that might be aggravated by strenuous work, check with your doctor before operating the device.

  • Page 6: Warning Labels

    Your safety and the safety of others are very important. We have provided important safety messages in this manual and on the Triminator Hybrid™. This information alerts you to potential hazards that could hurt you or others. Please read these messages carefully. Of course, it is not practical or possible to warn you about all the hazards associated with operating or maintaining a trimmer.

  • Page 7: Service And Repairs

    SERVICE AND REPAIRS Repairs may only be carried out by Eteros Technologies or a designated authorized agent (service technician). Should the need arise, please notify us: Eteros Technologies 6175 South Sandhill Road, Unit 600, Las Vegas, NV 89120 www.eteros.com www.thetriminator.com service@thetriminator.com (530) 265 4277 Improper interfacing, improper repair, or an unauthorized modification could result in void warranty...

  • Page 8: Safety Precautions

    SAFETY PRECAUTIONS SAFETY INFORMATION Read and become familiar with the entire User Guide. Learn the equipment applications, limitations, and possible hazards. TRAINED WORKERS ONLY KEEP CHILDREN and BYSTANDERS AWAY from the device. Visitors should be kept at a safe distance from the work area.
  • Page 9 WORK IN A SAFE ENVIRONMENT DO NOT USE THE DEVICE IN A DANGEROUS ENVIRONMENT or damp or wet locations. Never expose the control panel directly to rain or water. Keep the work area well-illuminated. DO NOT use the device in the presence of flammable liquids or gasses. KEEP THE WORK AREA CLEAN Cluttered areas and workspaces invite accidents.
  • Page 10 COMPONENTS...

  • Page 11: Power Pack

    The two connectors are different so it is not possible to plug in the wrong cable. The AC supply cable requires a NEMA 5-20R outlet. Do not use the Hybrid™ Trimmer with an extension cord as the voltage drop across the extension cord will result in excessive current drawn by the Hybrid™, potentially tripping breakers and overheating the motors.
  • Page 12 The tumbler center button toggles the tumbler rotation on and off. The tumbler will rotate when the integrated LED is illuminated red and the Hybrid™ is in operational mode. The left arrow decreases and the right arrow increases the tumbler speed. The six LEDs above the buttons indicate the current...
  • Page 13 The vacuum button toggles the vacuum motor on and off. The vacuum motor will turn on when the integrated LED is illuminated red and the Hybrid™ is in operational mode. While there is no speed control for the vacuum motor, it is possible to adjust the vacuum level by manipulating the vacuum adjustment lever.
  • Page 14 TRIMMER TILT The product dwell time in the tumbler is controlled by the angle of the trimmer. To prevent over-trimming and to ensure a constant flow of material through the tumbler, the trimmer should be raised on the infeed side. The closer the trimmer is to horizontal, the longer the dwell time in the tumbler.

  • Page 15: Feed Rates

    80% at 31°C (88°F), decreasing linearly to 50% at 40°C (105°F) Voltage and Current Rating 120 V (60 Hz), 16 A Overvoltage Category Environment: While the Hybrid™ can be used in a variety of conditions, the best results are achieved in spaces with low humidity and cool temperatures.
  • Page 16 NOTICE If this equipment is used in conditions outside the specified operating conditions, Eteros Technologies cannot guarantee that the built-in safety functions of the Triminator Hybrid™ will function as intended. UNCRATING THE HYBRID™...
  • Page 17 ASSEMBLY / DISASSEMBLY HOPPER AND CHUTE INSTALLATION AND REMOVAL The hopper and chute hang on the trimming module end plates. The hopper/chute have tabs and the end plates have corresponding slots. To install the hopper or chute, align the tabs with the slots, push the hopper/chute in towards the tumbler, and then push the hopper/chute down to latch them in place.
  • Page 18 TUMBLER INSTALLATION AND REMOVAL To facilitate regular cleaning, the tumbler is designed to allow for quick tool-free removal. REMOVAL 1. Make sure the machine is powered off and all motors have stopped turning. 2. Unplug the power cords. 3. Remove the hopper, chute, and cover. 4.
  • Page 19 3. Grasp the Power Pack by the handles on either end of the machine. Use two people if necessary. 4. Lift the Power Pack up and towards the tumbler to clear the hangers. 5. Set the Power Pack down on a stable surface. 6.
  • Page 20 2. Press the two tabs on one end of the machine until the tab disengages with the slot. 3. Rotate the panel away from the middle of the machine. 4. Remove the panel. PANEL INSTALLATION 1. The panel with the cutout belongs on the rear of the machine (Power Pack side) and the perforated panel belongs on the front of the machine (tumbler side).
  • Page 21 the entire trimming module off the frame and set aside. 5. Remove the trim and kief bags from the fan housing. 6. Pull up the handle above the motor to unlock the vacuum system and allow for removal. 7. Slide the bypass assembly until it clears off the hooks in the rails, and lift it out of the machine using the built-in handles.
  • Page 22 DRY TRIMMING Dry trimming can result in kief dust in the exhaust air stream. The normal trim bag will not capture the kief dust, but the kief bag will. Prior to dry trimming, both the trim and kief bags should be installed to contain discarded plant material and dust.
  • Page 23 CONNECTING TRIMMERS IN TANDEM For faster processing times and/or a closer trim, two Hybrid™ Trimmers can be connected in tandem. To connect your machines in tandem: 1. Use the jack mechanism to raise one of the trimmers until the gang plate is above the tandem locks on the other trimmer.

  • Page 24: Operation

    BEFORE YOU START SAFETY CHECK NOTICE Please take the following steps to confirm the Hybrid™ Trimmer is ready to operate: ● Complete a thorough inspection of the equipment to ensure no damage occurred during shipment. ● Confirm the power cords are in good condition.
  • Page 25 b. Press the arrow buttons next to the “BLADE” button to set the desired operating speed. NOTICE Note that the blade will not run unless the start/stop button is in the “start” state. 3. START THE TUMBLER a. Press the tumbler button; the tumbler is on when the red status light is on. b.

  • Page 26: Trimming Tips

    SUGGESTED SETTINGS: When feeding product into the Hybrid™, aim to keep the tumbler ¼ to ⅓ full of material. Too little material may result in over-trimmed product and too much may result in poor trim quality due to low vacuum.
  • Page 27 Vacuum Lever Moisture Content Tilt Tumbler Speed Blade Speed Position WET (18% +) 2.5 Turns MAX (6) SEMI-DRY (11-18%) 4 Turns MAX (6) DRY (9-11%) 7 Turns 4 to MAX (6) Trim Quality Troubleshooting: Symptom Possible Cause Suggestion Helical blade cutting too slow Increase blade speed Increase vacuum setting Not enough vacuum...

  • Page 28: Cleaning Your Trimmer

    CLEANING YOUR TRIMMER The toolless disassembly of the machine allows for easy breakdown and cleaning. With the exception of the Power Pack and the fan motor, the machine can be pressure washed. PRESSURE WASHING 1. POWER DOWN Shut off motors. Unplug power cords. 2.
  • Page 29 Solutions, focusing primarily on the Flex-Knife™, tumbler, helical blade, impeller, and vacuum housings. 7. DEGREASE Let the degreaser sit on trimmer components (EXCEPT for the Power Pack and fan motor assembly) for several minutes. 8. RINSE Using a pressure washer with no more than 1800 PSI rinse the degreaser from all components (EXCEPT for the Power Pack and fan motor assembly).

  • Page 30: Maintenance

    Triminator technician. To ensure the best quality and reliability, use only new, Triminator genuine parts or their equivalents for repair and replacement. Some of the most important safety precautions follow. However, we cannot warn you of every conceivable hazard that can arise in performing maintenance.
  • Page 31 TUMBLER ROLLER ADJUSTMENT The tumbler is supported by three urethane rollers. The bottom roller on each end of the trimmer can be adjusted to change the gap between the tumbler and the Flex-Knife™/helical blade interface. There are four settings (I, II, III, & IIII), with I being the closest trim (lowest tumbler) position. The default position is II.
  • Page 32 4. Align the notched groove on the eccentric nut with the desired position indicated on the side plate. 5. Apply a drop of thread-locker to the screw. 6. Tighten the screw to secure the eccentric nut and roller firmly against the side plate. 7.

  • Page 33: Maintenance Schedule

    MAINTENANCE SCHEDULE BEFORE EACH USE Inspect all electrical cords for damage and replace as required. Never use a damaged or frayed power cord. Ensure the trim bag(s) are installed or the exhaust is properly vented. DURING EACH USE Monitor the trim and kief bags for product build-up and empty when they are ½...

  • Page 34: Warranty

    Triminator. The above terms are valid if Triminator equipment is used and maintained as directed. If the equipment is modified in any way, all terms of this warranty are void. This warranty does not apply to cosmetic damage, such as scratches or general wear and tear.
