- Page 1 ETP2 Power Supply Interface for ETK User Guide...
- Page 2 The data in this document may not be altered or amended without special noti- fication from ETAS GmbH. ETAS GmbH undertakes no further obligation in relation to this document. The software described in it can only be used if the customer is in possession of a general license agreement or single license.
-
Page 3: Table Of Contents
Mechanical Dimensions ..........19 ETP2 - User Guide... - Page 4 ETP2 ........
-
Page 5: About This Document
Presentation of Supporting Information NOTE Contains additional supporting information. Scope of Supply Prior to the initial commissioning of the module, please check whether the product was delivered with all required components and cables (see chapter "Ordering Information"). ETP2 - User Guide... -
Page 6: Additional Information
ETAS About this Document Additional cables and adapters can be obtained separately from ETAS. A list of accessories and their order designation is available in this manual and at the ETAS Home Page. Additional Information The configuration instructions for the product can be found in the correspond- ing software documentation. -
Page 7: Basic Safety Notices
• “Use of Open Source Software” on page 13 General Safety Information Please observe the Product Safety Notices ("ETAS Safety Notice") and the fol- lowing safety notices to avoid health issues or damage to the device. NOTE Carefully read the documentation (Product Safety Advice and this User's Guide) that belongs to the product prior to the startup. - Page 8 Do not use the product in a wet or damp environment. Do not use the product in potentially explosive atmospheres. Keep the surfaces of the product clean and dry. ETP2 - User Guide...
- Page 9 CAUTION Risk of short circuiting the internal signals of the ETK! When you mount the ETK to the ECU, you must ensure that the screws and washers used will not penetrate the ETK printed circuit board. ETP2 - User Guide...
- Page 10 Cabling Use exclusively ETAS cables at the connections of the product! Adhere to the maximum permissible cable lengths! Observe the assignment of the cables to the connectors! Detailed information about cabling is located in the ETK User's Guides.
-
Page 11: Identifications On The Product
Order number of the product (example) SN: yyxxxxx Serial number (7-digit) XXXX/YY Product version ZZZZ Year of manufacture ETAS GmbH,... Manufacturer's address NOTE For symbols and product information one or several adhesive labels can be used. ETP2 - User Guide... -
Page 12: Taking The Product Back And Recycling
CE Declaration of Conformity (European Union) With the CE mark attached to the product or its packaging, ETAS confirms that the product corresponds to the applicable product-specific European Direc- tives. The CE Declaration of Conformity for the product is available upon request. -
Page 13: China
Some products from ETAS GmbH (e.g. modules, boards, cables) use compo- nents with substances that are subject to declaration in accordance with the REACH regulation (EU) no.1907/2006. Detailed information is located in the ETAS download center in the customer information "REACH Declaration" (www.etas.com/Reach). This information is continuously being updated. -
Page 14: Introduction
The board should only be taken from its package, configured, and installed at a work place that is protected against static discharge. Applications The ETP2 Power Supply Interface for ETK is used as a front end power supply for ETAS ETKs. Features •... -
Page 15: Hardware Description
In this chapter, the individual function blocks of the ETP2 hardware are explained in detail. Architecture The ETP2 is a device used as the front end power supply for ETAS ETKs. The ETP2 is connected between the vehicle battery and the ETK’s power supply connector. -
Page 16: Power Supply
The input of the ETP2 is connector "J1". It is connected directly to the vehicle power supply or battery. 4.4.2 DC Output The output of the ETP2 is connector "J2". It is to be connected to the power supply input (battery input) for the ETK. ETP2 - User Guide... -
Page 17: Cabling
ETAS Hardware Description Cabling The ETP2 is connected between the permanent power supply and the ETK power supply connector (see Fig. 4-3). The ETK is connected to the ETP2 using the CBM200 cable. Power Supply Connector Isolated Power Supply Permanent Supply... -
Page 18: Technical Data
- 40 °C to + 110 °C - 40 °F to + 230 °F Pin Assignment 5.3.1 Connector J1 (Input) Fig. 5-1 Connector J1 Pinout Signal Description To battery "+" To battery "-" Tab. 5-1 Connector J1 Pin Assignment ETP2 - User Guide... -
Page 19: Connector J2 (Output)
Signal Description To ETK "+" (power supply) out+ To ETK "GND" out- Not connected Tab. 5-2 Connector J2 Pin Assignment Mechanical Dimensions Fig. 5-3 ETP2 Dimensions - Top View Dimensions Millimeters Inches Length 49.78 1.96 Width 34.93 1.375 Height max. 13.58 max. -
Page 20: Cables
NOTE The ETP2 to ETK cable (CBM200-0m1) is included in the ETP2 delivery. The ETP2 power cable is not included in the delivery. Either the ETV or ETV2 cables described below should be purchased seperately. For order numbers refer to chapter 7 on page 21. -
Page 21: Ordering Information
ETAS Ordering Information Ordering Information ETP2 Type Order-No. Note ETP2 Power Supply F 00K 104 010 ETP2 with ETK interface cable Interface for ETK CBM200-0m1 Cables Type Order-No. Note CBM200-0m1 F 00K 900 052 ETP2 to ETK cable Y 261 A24 446 Power supply cable... -
Page 22: Contact Information
Germany Internet: www.etas.com ETAS Subsidiaries and Technical Support For details of your local sales office as well as your local technical support team and product hotlines, take a look at the ETAS website: ETAS subsidiaries Internet: www.etas.com/en/contact.php ETAS technical support Internet: www.etas.com/en/hotlines.php... -
Page 23: Figures
Fig. 4-3 Isolated Power Supply ETP2 inside ECU ....... . .17 Fig. -
Page 24: Index
Pins ETP2 Interface ....16 Power Supply ....16 Product Exclusion of liability .
