resideo PROSIXPANIC-EU Installation And Setup Manual

The PROSIXPANIC-EU is a bi-directional wireless
panic device that is intended for use with Control
s
that support SiX™ series devices.
Panel
To activate this device, press and hold both buttons
briefly until the LED flashes. To clear the alarm at the
panel, enter a user code. To clear memory of alarm,
select Disarm and enter a user code.
LED Indications:
• Green flashing:
Unit is transmitting.
• Red flashing:
Low battery
(lights when button is pressed)

ENROLLING AND PROGRAMMING

You must enroll the device in the PROHP-EU Control Panel. Set the panel in Programming Mode, and when prompted:
Note: For detailed programming instructions refer to the Installation Instructions for the Control Panel with which this device is used.
1. Press and hold both buttons briefly until the LED flashes green to activate the enrollment process.
2. The LED continues to flash during enrollment (up to about 20 seconds).
The device sends data, and the panel registers the device.
NOTE: Enrollment time varies depending on the signal strength between the device and the Control Panel.
3. When completed, the LED lights solid green for 3 seconds to confirm enrollment.
If enrollment is not confirmed, press and hold both buttons briefly again to restart the enrollment process.
IMPORTANT: After enrolled in a system, the device cannot be used with another Control Panel until it is removed from the current
panel. When removed from a system, the sensor will revert to factory default settings.
After Enrolling: Verify an adequate signal strength by conducting a sensor test (see the Control Panel instructions).

24-HOUR ENROLLMENT DELETION AND DEFAULT

If the device is enrolled in a Control Panel different than the intended panel, and you are unable to delete it from the unintended
panel, reset the device to factory default setting:
• Press and hold both buttons [A] for 15 seconds. When successful, the LED comes back on flashing.
• The device self-deletes from the panel it was enrolled in.
This procedure is available for 24 hours after enrollment with a panel and the device remains powered (battery installed
Installation and Setup Guide
[A]
2-Button Wireless Panic Sensor
NOTE: The device can be used with a
belt clip, lanyard, or wristband.
PROSIXPANIC-EU-003-V0
PROSIXPANIC-EU
