Hello, I have an Atlas VF9100 Front and Rear Dashcam, My car Battery keeps on discharging, it's a new battery, so if I do not use the car for a week would the Dashcam Drain the Battery
Page 3
DISCLAIMER This is an auxiliary product for recording the external images of vehicles, which does not have the function of guaranteeing the safety of users. Virtus Fleet accepts no liability for any driving accident caused by product failure, information loss, operation of the product and any loss caused by the product.
Page 4
The default file partition format of the storage card may not be consistent with the format supported by this product. Please format it in the device when you insert it in the device for the first time. Do not insert or unplug the memory card in the boot state, or damage may be caused to the SD card.
Page 5
APPEARANCE ITEM NO. DESCRIPTION ITEM NO. DESCRIPTION Mount/Bracket Mini USB Connector (for rear cam) Speaker Hole Memory Card Slot Camera Lens Power Button Mini USB Connector (for power) Indicator Light Rest Button Microphone...
Page 6
INSTALLATION INSTRUCTIONS 1. FRONT CAMERA INSTALLATION: 1.1 - Please clean the windshield glass before installation. Take the static sticker from the box and stick it on the front windshield, in the recommended area shown below in red. Squeeze the bubbles between the static sheet and the glass during installation.
1.3 - In line with the image below, lay the power cable along the top of the front windshield, down pillar A and around the glove compartment on the passenger side, ending at the cigarette lighter port. 1.4 - Adjust the angle of the camera to ensure correct positioning. This can be seen via the smartphone application.
Page 8
Remove protective sticker on the camera bracket and place the camera in the middle of the electrostatic sticker. Press the base of the bracket to ensure that the camera adhesive is in close contact with the static adhesive. 2.3 - Run the secondary camera cable through the vehicle (see image below) and connect it to the main camera unit.
Image Resolution: 1080P at 30FPS SMARTPHONE APPLICATION USAGE GUIDE: This product needs to be used in combination with the Virtus Atlas smartphone application. Please search Virtus Atlas in either the Google Play Store or the Apple App Store to install.
PLEASE NOTE: Some Android phones require mobile data to be disabled and location services to be enabled in order to connect to the camera correctly. APPLICATION OPERATION Initially when you open the app the live view will be displayed. Underneath the main video you have the option of taking a picture with the red shutter icon, as shown below.
Page 11
To save a file to your device, go to Album, DVR then choose either Photo, Video, or Event. Once the file list has loaded tap the downward facing arrow. This file will then be available in Local for you to view or send any time. You can also delete the file by using the icon that looks like a bin.
Page 12
To access the settings tap on the icon labelled Settings at the bottom of the screen. Here you can change options such as audio recording, G-sensor sensitivity, and file length. You can also adjust the time and format the SD card from the device itself.
