Summary of Contents for Otoadd Classic R
- Page 1 RelaJet Tech Hearing Aid(Non-Sterile HFE-001 USER MANUAL...
- Page 2 What’s in the box How to wear Hearing Function Volume Adjustment Wireless Connection Index APP Download Charging Instruction Specification Warning/Caution...
-
Page 3: What's In The Box
01 What’s in the box Hearing Aid(Left Ear*1, Right Ear*1) Charging Case*1, Battery*4 Type-C Charging Cable*1 Ear Tip Set*1（S/M/L） User Manual*1... -
Page 4: How To Wear
02 How to wear l Part Introduction Replaceable Ear-tips Adjustable Ear Hook • Sponge ear tip • Made of shape memory 3 Sizes （S/M/L） alloys, can be bend to Choose to fit fit. Hearing Aid Rechargeable Battery • Unique acoustic design, provide •... - Page 5 l Install ear tip & battery 1. Choose suitable ear Power Up tips, put them on the Indicator hearing aid。 2. Power Up：Put ② Rotate clockwise battery into the socket, slightly rotate ①Put in clockwise. Make sure Power Off to install both ears. The indicator will light up after power up.
- Page 6 l How to wear 1. Put hearing aid into ear in 45°. 2. Gently insert the ear tip into ear canal. 3. Rotate the hearing aid 4. Adjust the ear hook...
- Page 7 03 Hearing Function l Buttons Instruction Back Microphone Front Microphone Top Button Bottom Button Indicator l Frequently used Hearing Function Function Operation Tone Volume Double click top button Thump Volume Double click bottom button Down Thump Single click bottom button, mode will change in cycle: ①...
-
Page 8: Volume Adjustment
5. If feel uncomfortable, please lower the volume. Otoadd Classic R can work without mobile connectivity, If you need to listen music/ make a phone call, please follow the instruction next page and enable wireless function. -
Page 9: Wireless Connection
Wireless Connection 1. Pairing Steps Operation Cue Tone Press top button of Otoadd Classic R for 3 Enter Pairing Pairing seconds to enter pairing mode. Mode LED Indicator will start blinking. Go to Bluetooth setting of your mobile or Pair with another —... -
Page 10: Frequently Used Function
2. Frequently used Function Function Operation Cue Tone Volume Double click top button Thump Volume Double click bottom button Down Thump Answer/Hang Up Short press top button — calls Stop/Play Short press top button — Music/Video Turn On/Off Short press buttom button —... -
Page 11: App Download
06 APP Download Otoadd provides App for better user experience, please scan the QR code below and download the App. Website : https://www.otoadd.com/mobile-app.html... -
Page 12: Charging Instruction
07 Charging Instruction Button Indicator(White ) 1. When power level is lower than 20%, hearing aid will give cue tone : battery low. Please change battery then. 2. Before put battery into the charging case, please press the button of the charging case to check the power status of charging case. - Page 13 3. Insert battery : put the battery into the charging case, push a little onward. 4. Take out battery : Flip the battery up, pull it out of the charging case. 5. LED indicator status : White : Battery fully charged Red : Battery charging LED indicator (White/Red)
-
Page 14: Specification
08 Specification Model Name HFE-001 Audio Codec SBC , aptX Maximum output 126±3dB SPL@2000Hz Maximum gain 40±4dB SPL Frequency Response 200Hz~6000Hz Hearing Aid：3.7V/45mAH Battery Capacity Charging Case：3.7V/450mAH Hearing Aid(1 ear, include battery)： 9g Weight Charging Case：92g... -
Page 15: Important Security Instructions
09 Warning/Caution Important Security Instructions Hearing aids are not able to cure or recover to normal hearing, nor to prevent any hearing impairment. Seek medical help if you experience tinnitus or any discomfort. Do NOT pull the ear hook roughly to avoid rupture. Do NOT submerge or expose the hearing aid for extended period to water, or wear while participating in water sports, e.g., swimming, waterskiing, surfing, etc. - Page 16 Federal Communications Commission (FCC) Statement 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 17: Federal Communications Commission (Fcc) Statement
Federal Communications Commission (FCC) Statement 15.19 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference and 2) this device must accept any interference received, including interference that may cause undesired operation. - Page 18 Product Remarks l Actual size and weight may differ due to different accessories. l Color display on the website is only for reference. Please refer to the actual product. l Detailed specification may differ between different models. Please refer to the actual product.
- Page 19 Product Name：Otoadd Classic R Model Name：HFE-001 FCC ID：2AX9Z-HFE-001 Designer Name：RelaJet Tech (Taiwan) Co., Ltd. Designer Address： 8F., No. 150, Sec. 4, Nanjing E. Rd., Songshan Dist., Taipei City 105, Taiwan (R.O.C.) Manufacturer Name： DONGGUAN TYMPHANY ACOUSTIC TECHNOLOGY CO. LTD. Manufacturer Address：...
