Summary of Contents for Ultimate Power UPL-12100F
- Page 1 Lithium Iron Phosphate (LiFePO4) UPL-12100F Rechargeable Battery Operator's Manual Operator's Manual...
-
Page 2: Table Of Contents
Table of Contents Battery Diagrams Product Information Battery Operation Battery Specifications Operating Conditions Battery Heater Function Installation Instructions Charging Instructions Disharging Instructions Series and Parallel Connection Instructions Wiring Diagram for Batteries in Series Wiring Diagram for Batteries in Parallel Warning & Attention Troubleshooting Storage &... -
Page 3: Battery Diagrams
Battery Diagrams Top View Side View – –... -
Page 4: Product Information
Product Information The battery is designed and intended only for use in deep cycle applications. It is equipped with Ultimate Power's (UP) Battery Management System (BMS) which can manage and monitor battery performance during charge and discharge to ensure the safety and optimization of the battery. Common applications include utility trucks, emergency vehicles, RV, yacht, golf cart, solar street light, UPS, emergency lighting, alarm system and photovoltaic energy storage. -
Page 5: Installation Instructions
Installation Instructions Please follow the vehicle/equipment manufacturer's instructions: • When replacing various types of deep cycle applications, please ensure the battery capacity is not less than the original lead-acid battery. Please check the following items for battery before installation: • Check the battery voltage with a multimeter. If <13V, please recharge the battery (Refer to "Charging Instruction"... -
Page 6: Series And Parallel Connection Instructions
(4 AWG - 16 inches.) If you want to use them in series and in parallel concurrently, please contact Ultimate Power (UP.) If not wired as per guidance from UP, then UP reserves the right to nullify and void product warranty. -
Page 7: Wiring Diagram For Batteries In Series
4ga-16in 4ga-16in 4ga-16in 4ga-16in Wiring Diagram For Batteries In Series Copyright ©2020 Ultimate Power Company, All Rights Reserved Nov 25, 2020 Rev:C Wiring Diagram for Batteries in Parallel Lithium Batteries in ParaLLeL 2 - Batteries 200Ah 3 - Batteries 300Ah... -
Page 8: Warning & Attention
Warning and Attention • Do not reverse the positive and negative of the battery. • Do not touch or store the electrodes of the battery with unnecessary wires or other metal materials to avoid short circuit. • Do not puncture, impact, drop or step on the battery. •... -
Page 9: Troubleshooting
Troubleshooting Symptom Possible Causes Corrective Actions Check the circuits/working environment and confirm the load power to ensure battery Battery being protected by BMS is being charged/discharged No DC Output within Max charging/ discharging current stated in the Specifications BMS failed Replace the battery Charging voltage is too low and Adjust the... -
Page 10: Storage & Transportation -8
Storage and Transportation Item Criteria <1 month 14°F to 113°F (-10°C to 45°C) Storage Temperature <3 months 14°F to 95°F (-10°C to 35°C) 32°F to 86°F (0°C to 30°C) >3 months Relative Humidity <75% RH 40% to ~60% • To ensure longer battery lifespan, please recharge battery every 3-6 months. •... -
Page 11: Warranty Information
Some States do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. What Batteries Are Covered Ultimate Power (UP) provides this limited warranty for UP’s batteries purchased directly from UP or its authorized reseller that come with a limited warranty. UP’s Performance Warranty UP warrants that your battery is free of defects in material and workmanship for the duration of the warranty periods listed in the Chart below. - Page 12 Contact For more information on this limited warranty, please contact us at: Ultimate Power, Customer Service, 115 N. East Street, Coudersport, PA 16915. You may also contact UP by phone at 888-447-5920 or visit www.ultimatepower.com. – –...
- Page 13 Need additional information? Contact Ultimate Power at 888.447.5920 or email info@ultimatepower.com 115 N. EAST ST • COUDERSPORT, PA 16915 info@ultimatepower.com • 888.447.5920 • ULTIMATEPOWER.COM © UPL-12100F LiFePO4 Battery Operator's Manual • Copyright Ultimate Power Company, All Rights Reserved • December 2020 • Rev. N...
