  • Page 2: Table Of Contents

    Playback ..........................16 5.1. Navigate among the Recordings ..................... 17 5.2. Filtering the Detectors ......................18 5.3. Exporting the Recordings ......................18 Events ............................19 Page 2/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 3 8.3. I/O Outlets ..........................55 8.4. Reset to factory default ......................56 8.5. Install storage media ....................... 56 8.6. Device restart........................... 58 Contact Information........................59 Page 3/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 4: Overview

    2. Type the username and the password on the displayed login interface and click on [Login]. The default user account is the following: Username: admin Password: admin Page 4/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 5: Default Ip Address

    IP addresses. If the device does not appear, ensure that the firewall does not block the multicast protocol on the network and that the device and the PC are in the same network range. Page 5/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 6: Ar Device Tool

    If newer firmware or engine are available for any of the listed cameras/devices, a star sign is added into the green indicator. Double-click on the selected device/camera to open its web interface in the default browser. Page 6/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 7: Firmware, License, And Engine Upload - Manually

    Previously created user profiles can be edited or deleted using the buttons next to the [+] button. Page 7/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...

  • Page 8: Firmware And Engine - Checking For Updates

    A new folder will be created in your Download folder: ArDevi- ceToolDownloads. Please delete it if you no longer need the firmware(s)/engine(s). Page 8/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...

  • Page 9: Overview Of The Web Interface

    Status − Device − Network − Security − Storage − − Service − Notifications − External MEDIA − Video ANALYTICS − Settings − Detectors Page 9/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 10: Live

    The camera’s live stream can be displayed on full screen by clicking on the icon located in the bottom- right corner of the image. To exit from the full-screen mode, press the ESC keyboard key or click on the icon mentioned above. Page 10/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 11: Saving Image

    Next to the [Streams] icon is the [Help] button. It brings up keyboard shortcuts on how to use and navigate the video feed. To exit from the Help OSD, press the [Help] button or click in the grey area. Page 11/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...

  • Page 12: Overlay

    Name: (optional): The name of the device can be entered. • Adress: IP address where the device is accessible. • ONVIF Username: The device's ONVIF username. • ONVIF Password: The device's ONVIF password. Page 12/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 13 For many cameras, the ONVIF Username and Password do not match the username and password used in the browser. ONVIF may also need to be enabled on the camera. Page 13/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...
  • Page 14 Recognition memory: Recognised license plates which will not be recognised again. The time range while the recognised license plates remain in the memory can be set in {ANPR engine} ”Ig-nore same plate for (s)”. Page 14/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 15: Event Preview

    Clicking on the image shows the event image in full view. One more click takes you back to the event window. Page 15/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...

  • Page 16: Playback

    In case the storage is turned off but the storage device is available, the previously recorded elements can be viewed and played if the storage function is switched on. Page 16/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...

  • Page 17: Navigate Among The Recordings

    To modify the playback speed, click the cogwheel on the video menu and select a speed value. This is where you have the help and the image saving options. Page 17/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...

  • Page 18: Filtering The Detectors

    The duration of the video to be exported is displayed in the bottom line ("Du- ration"). You can adjust the exact time by clicking on the calendar icon. Page 18/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 19: Events

    The events appear as small images. The latest events are at the top. Use the buttons in the bottom left corner to switch between Grid view and Detailed view. Page 19/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...
  • Page 20 The interface can be redirected to the PLAYBACK menu item by clicking on the [Show in play- back] button. The data belonging to the event can be saved as a ZIP file by clicking on the [Download] button. Page 20/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 21 An additional license plate search form is available. Similar license plates can be listed if the "Include similar matches" option is turned on. Searching based on vehicle direction and MMR data is also avail- able. Page 21/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 22: Settings

    On this interface, you can find a summary of the important data of the device, the installed detectors, the operating time, the ANPR licenses, etc. API documentation can also be found here for integrating. Page 22/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...

  • Page 23: System / Device

    NTP server to the field of the NTP servers. Use at least a local NTP server if you manage more than one camera and/or use integration via API/HTTP/FTP/etc. Page 23/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...
  • Page 24 During the update process do not unplug the device. To use the device with the on-board ANPR function, license file and engine file must be up- loaded to the device. Page 24/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 25: System / Network

    DHCP server fails. Put the Carmen Box device and your camera in the same network segment. Page 25/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 26: System / Security

    2. User: The user can view but not edit the parameters of the device. Some pages containing sensitive information may be hidden. 3. Operator: The operator has the same privileges as a user. Page 26/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 27 The duration of the block can be set between 30 seconds and seven days. The Active sessions and Blocked clients can also be seen on this tab. Page 27/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...

  • Page 28: System / Storage

    Recordings before and after activation (seconds) The recording time (in seconds) before and after the events can be regulated with the help of the sliders. Page 28/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 29 Click on the [Yes] button to start the operation. The capacity bar indicates the remaining time of the formatting process. The formatting deletes every data from the storage device. Page 29/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 30 Reset Uploader: Resets the uploader progress to the current date. Event that are older and not yet uploaded will be ignored. In the Uploader status section, you can view the status and the data of the uploader. Page 30/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 31 Reset Uploader: Resets the uploader progress to the current date. Event that are older and not yet uploaded will be ignored. In the Uploader status section, you can view the status and the data of the uploader. Page 31/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 32 With the [Start test] button you can test the connection between the camera and the FTP server. In the Uploader status section, you can view the status and the data of the uploader. Page 32/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...

  • Page 33: I/O

    Active state: The active state of the port. If it is "Open", the port is open when an event occurs. If it is "Closed", the port closes when an event occurs. Page 33/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...
  • Page 34 For some cameras, the IO port must also be enabled separately on the camera. Select which ONVIF device the Detector should be associated with. Page 34/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 35: System / Service

    Allow discovery: Enable or disable the device discovery provided by the UPnP protocol. • Service port: The service port of the IVS can be specified by filling in the field. Page 35/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 36: System / Notifications

    E-mail settings: set the display name and the email address that the device uses when sending email messages. The "Send to" field is used to set the recipients. Page 36/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...

  • Page 37: External

    For many cameras, the ONVIF Username and Password do not match the username and password used in the browser. ONVIF may also need to be enabled on the camera. Page 37/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...

  • Page 38: Media / Video

    „Enabled” and fill in the „User” and „Password” fields. Some examples of RTSP source field values in case of different manufacturers: AR Vidar, MicroCam: rtsp://Camera_IP/stream/h264 Intellio Visus: rtsp://Camera_IP:554/primary/h264 rtsp://Camera_IP:554/secondary/h264 Intellio Initio: rtsp://Camera_IP:554 Page 38/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 39 (tested with IPC-HDBW4431E-ASE, FW: 2.460.0000.14.R, Build Date: 2017-07-20) Hanwha: rtsp://Camera_IP/profile2/media.smp (tested with PNO-A6081R, FW: 2.11.02_20210630_R206) Hikvision: Main stream: rtsp://Camera_IP:554/Streaming/Channels/101 Sub stream: rtsp://Camera_IP:554/Streaming/Channels/102 Page 39/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 40 JPEG still images can be accessed with the following url, and event image quality can be set here. Videostream / image URL links can be found on this interface, such as: H.264 stream: rtsp://CARMEN_BOX_IP:554/stream/stream1 JPEG image: http://CARMEN_BOX_IP/image/stream1 Page 40/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 41: Analytics / Settings

    When it is set to "Exclude”, it will not trigger inside the area. The mask can be modified by clicking on the green area. Page 41/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...
  • Page 42 Violation time (ms): The time between sensing movement and the alarm event. If the movement stops during the masked area during this time, the alarm will not sound. Page 42/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...
  • Page 43 Violation time (ms): The time between sensing movement and the alarm event. If the movement stops during the masked area during this time, the alarm will not sound. Page 43/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...
  • Page 44 Although the ANPR engine recognizes the license plates in the image, to make it work pro- perly, the area around the license plate must be visible (front or rear of the vehicle). Page 44/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...
  • Page 45 Traffic type: Type of traffic the device processes. Some engines contain more than one recog- nition possibility. If the uploaded engine supports „Quick” recognition mode, you can select it as „SlowTraffic” mode. Page 45/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 46 Ignore same plate for (s): A time limit can be set for previously-read license plates. This value determines a waiting time in seconds before the same license plate is read again. Page 46/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...
  • Page 47 ANPR Cloud key: Enter the individual key of the subscription The Status field displays information about the operation of Carmen Cloud, e.g. successful/failed con- nection, upload status, expired credits, etc. Page 47/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 48 Stop on first recognition: Any further license plate detection is stoppped after the first succesful plate detection. Read count on impulse: Specify the number of reads per impulse. Page 48/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 49 In the example below, the „ANPR detector MSNLP” is triggered if a license plate containing M, S, N, L or P characters are detected. Page 49/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 50 The ANPR Engine mask must have a common intersection with both detectors. This can be checked by activating the corres- ponding OSD layer(s). Page 50/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 51 Description: A brief description can be added to the detector. • Distance between events: The device produces a test event at the set intervals. • Signal duration: To adjust the signal length. Page 51/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 52: How To Use The Carmen Box

    3. Mount your camera or adjust your existing camera as follows: a. The maximum angle of rotation and/or tilt of the camera should not exceed 25–30 degrees. Page 52/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 53 After changing any settings (eg.: the field of view, position, direction of the camera, resolution, etc.) restart the device to reset internal statistics. Page 53/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 54 General/ANPR engine status layer during device setup {Overlay}. Also, display these captions during playback and reduce the playback speed to facilitate more accurate evaluation. Page 54/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 55: Dimensions

    It lights up and will remain steady while the system is powered on. HDD LED The Yellow LED is linked to Solid-state Drive (SSD) activity signal. LED flashes every time SSD is accessed. Page 55/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 56: Reset To Factory Default

    You can use one of the following storage media on which the CarmenBox can store events: external USB drive (plugged into the device’s USB2/USB3 port), or microSD card inserted inside the device. Page 56/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 57 Step 4: Turn the MicroSD card upside down, and hold it with fingers at a 30 degree angle up from horizontal, and then insert and press it gently. Page 57/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary...

  • Page 58: Device Restart

    (The SSW1 switch is set as above in devices manufactured after 2023.02.13.) Page 58/59 REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic WWW.ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 59: Contact Information

    Carmen Box USER MANUAL Contact Information Headquarters: Service Address: Adaptive Recognition, Hungary Inc. Adaptive Recognition, Hungary Inc. Alkotás utca 41. Ipari Park HRSZ1113/ 1 HU-1123 Budapest, Hungary HU-2074 Perbál, Hungary Phone: +36 1 201 9650 Phone: +36 1 2019650 Fax: +36 1 201 9651 E-mail: rmarequest@adaptiverecognition.com...
