Summary of Contents for MSA PremAire Escape
- Page 1 Operating Manual PremAire Escape Self-Contained Compressed Air Breathing Apparatus for Escape Order No. D4088228/00 MSAsafety.com...
- Page 2 MSA AUER GmbH Thiemannstrasse 1 D-12059 Berlin Germany © MSA AUER GmbH. All rights reserved...
-
Page 3: Table Of Contents
Lung Governed Demand Valve ....................... 26 Visual Inspection CVA and Cylinder ....................27 Visual Inspection of Carrying Bag with Neck Strap and Waist Belt (if Applicable) ......27 Compressed Air Cylinder ......................... 27 Quick-Fill Adapter (if Applicable) ..................... 27 Packing ............................. 28 PremAire Escape... - Page 4 Contents Storage ............................. 32 Technical Data ......................... 32 Certification ..........................33 Ordering Information ....................... 33 PremAire Escape...
-
Page 5: Safety Regulations
According to ISO 23269-1 The PremAire Escape with 3 l/300 bar or 2 l/300 bar cylinder, hereafter referred to as device, is an Emergency Escape Breathing Device (EEBD) for shipboard use with rated service duration depending on filling pressure and cylinder size used (see table below). The device enables the wearer to escape from a potentially hazardous atmosphere. -
Page 6: Liability Information
MSA or authorised persons. Liability Information MSA accepts no liability in cases where the product has been used inappropriately or not as intended. The selection and use of the product are the exclusive responsibility of the individual operator. -
Page 7: Description
Description Description The PremAire Escape is a positive pressure self-contained open-circuit compressed air breathing apparatus (SCBA) for escape. The device consists of either a full face mask or a mask-hood, both connected to a lung-governed demand valve (LGDV). The LGDV is connected to a compressed air cylinder via a medium pres- sure hose and the combination valve autostart (CVA). - Page 8 Description ® PremAire Escape Fig. 1 Overview (not true to scale) PremAire Escape...
-
Page 9: Positive Pressure Full Face Mask
The LGDV is stored in the carrying bag in standby position. For additional information see AutoMaXX-ASE manual. PremAire Escape... -
Page 10: Combination Valve Autostart (Cva)
EN 144-1 acoustic end of service time warning signal (optional) water tube or excess flow valve (optional) Compressed Air Cylinder For additional information see Compressed Air Cylinders manual. PremAire Escape... -
Page 11: Quick-Fill Adapter (Optional)
The compressed air cylinder is strapped into the carrying bag and the pressure gauge can be read through a window in the bag. Rated working durations and donning pictograms are shown on the bag. Fig. 3 Open bag with started device PremAire Escape... -
Page 12: Use
The device may only be put into use in a fully maintained and tested condition. If malfunctions or defects are noticed prior to use, do not use the device under any circumstances. Get the device checked and repaired by an MSA authorised service centre. WARNING Take care not to damage the device during carrying, donning and servicing. -
Page 13: Donning The Device
If the CVA is not activated: This can happen when the starter key is not connected to the opening loop. In this case, open the valve manu- ally by turning the handwheel anti- clockwise. Grab mask-hood by the LGDV. PremAire Escape... - Page 14 If the device is used in a hazardous area it is recommended to activate the LGDV by pushing the flush button for 2 seconds before starting breathing. With this procedure poisoned air could be flushed out of the mask-hood. (10) Pull firmly on the head straps on both sides to tighten as shown. PremAire Escape...
- Page 15 (14) Escape immediately and return to uncontaminated and non-hazardous area. (15) Check pressure gauge regularly The optional warning signal starts between 25 bar and 35 bar and sounds until the end of air supply. Remove device only in an uncontaminated area outside of explosive atmospheres. PremAire Escape...
- Page 16 If the CVA is not activated: This can happen when the starter key is not connected to the opening loop. In this case, open the valve manu- ally by turning the handwheel anti- clockwise. Grab full face mask by the LGDV. PremAire Escape...
- Page 17 2 seconds before starting breathing. With this procedure poisoned air could be flushed out of the full face mask. Quickly don full face mask. (10) Tighten straps. (11) Close and adjust waist belt if applicable. PremAire Escape...
-
Page 18: Longer Escape Durations
Y-piece Connection to Rescue Airline (If Applicable) The PremAire Escape can be equipped with a Y-piece with a non-return nipple with flush function and check valve (optional) to enable a connection to a rescue airline e. g. in “safe havens”. The operation pressure of the compressed air feeding hose should be between 6.0 bar and 8.5 bar. - Page 19 Pull the starter key. Disconnect Y-Piece and continue escaping. The Y-piece function is only certified for this emergency air supply situation and not certified for use as an airline breathing apparatus. PremAire Escape...
-
Page 20: After Use
Exchange the Cylinder (Optional) PremAire Exchange Cylinders are devices which can be connected via the Y-piece (optional) to the PremAire Escape system without interrupting the air supply to the user. For additional information see PremAire Exchange Cylinder manual. After Use... - Page 21 Do not throw off the compressed air breathing apparatus. This could damage the valve and any remaining compressed air could escape suddenly. This could cause fatal injury to you or to any bystanders. WARNING After use the device has to be serviced to be ready to operate! PremAire Escape...
-
Page 22: Cleaning
The cleaning/disinfection of of mask-hood or full face mask is performed in accordance with the suitable manual. Lung Governed Demand Valve For cleaning/disinfection instructions of the LGDV, see AutoMaXX manual. Compressed Air Cylinder For cleaning instructions of the cylinder, see Compressed Air Cylinder manual. PremAire Escape... -
Page 23: Filling The Compressed Air Cylinder
Connect the filling connector to a 300 bar filling connection of a compressor and fill to 200/300 bar. Follow the compressor instructions and use the relevant adaptor if required. Depressurise the medium pressure system: Push the flush button first and then close the medium pressure system by pushing the stand-by button. PremAire Escape... -
Page 24: Quick-Fill System (Optional)
Depending on the pressure and the volume of cascade cylinders used, and the number of users the achievable filling pressure will vary! This influences the possible duration of air supply! Quick-Fill adapter Filling hose coupling to couple Sleeve to uncouple pull back sleeve PremAire Escape... -
Page 25: After Filling
The temperatures may reach approx. 70 °C. After returning to ambient temperatures check if the filling pressure of 200/300 bar is reached. If necessary, top up pressure. After filling, the cylinders must be checked for tight- ness. PremAire Escape... -
Page 26: Maintenance
Always use original parts from MSA. Repairs and maintenance must be carried out only by authorised service centres or by MSA. Changes to devices or components are not permitted and will result in loss of approval. -
Page 27: Visual Inspection Cva And Cylinder
Verify that the bag securely retains the cylinder and the components of the device. Compressed Air Cylinder For maintenance instructions of the cylinder, see Compressed Air Cylinder manual. Quick-Fill Adapter (if Applicable) For maintenance instructions of the Quick-Fill Adapter see Quick-Fill System manual. PremAire Escape... -
Page 28: Packing
The CVA has to face the opening side. Adjust the medium pressure hose on filling port side. Close cylinder fixation as shown. Push filling port through side opening in the bag. Open handwheel on CVA completely (anticlockwise). PremAire Escape... - Page 29 The key must stay in place after closing the hand- wheel. Put mask-hood/full face mask into carrying bag: Mask-Hood version Fold the mask-hood according to the Mask-Hood manual. Put the mask-hood with the LGDV pointing towards the bag opening into the carrying bag. PremAire Escape...
- Page 30 Check that the LGDV is switched off WARNING An open LGDV leads to loss of air when donning the escape device in an emergency situation. (10) Connect the starter key and bag flap (11) Fill the cylinder. PremAire Escape...
- Page 31 (13) Fit the anti-taper tag through the openings in lid and bag. (14) Fully extend the neck strap and waist belt (if appli- cable). PremAire Escape...
- Page 32 For additional storage information, see the manuals for the parts of the device. Mask-Hood or Full Face Mask MSA rubber products are protected by an anti-ageing agent that can become visible as a light coating. This coating is harmless and can be removed.
- Page 33 Description Part No. PremAire Escape, with PremAire Mask-Hood,2 l composite cylinder (empty) 10151746 PremAire Escape, with 3S full face mask, 2 l steel cylinder (empty) 10152573 PremAire Escape, with 3S full face mask, 2 l composite cylinder (empty) 10152574 Waist belt (pack of 5)
- Page 34 For local MSA contacts, please visit us at MSAsafety.com Because every life has a purpose...
