Whirlpool 6AKZ 148 Product Description Sheet

6AKZ 148 AU
Last
First
ACCESSORIES • Grid
• Pan set kit
OVEN FUNCTIONS TABLE
Function Preset
Function
symbol temperature/level
0 OVEN OFF -
OVEN LIGHT -
MLTF
35C
(Heat Maintenance)
STATIC 200C
PASTRY
175C
(Static+Fan)
FAN 160C
GRILL 3
TURBOGRILL
3
(Grill+Fan)
PROGRAMME P1
5019 100 54562
PRODUCT DESCRIPTION SHEET
First-Last.... shelf positions
1. Control panel
2. Cooling fan* (not visible)
3. Top heating element (can be lowered)
4. Oven light
5. Round heating element (not visible)
6. Fan
7. Bottom heating element (not visible)
8. Door hinge
9. Oven cool door
*N.B.: The cooling fan switches on only when the
oven has reached a certain temperature.
After the oven switches off, the cooling fan may,
however, continue to run for a certain time to
ensure proper cooling.
• Catalytic panel
Function description
(see details in the user's manual)
-
To switch on the oven light.
To keep a constant temperature, either
35° C or 60° C.
To cook food at one shelf level. Preheating.
To cook on two shelf levels, at the same
temperature.
To cook on more than one shelf level, at
the same temperature.
To grill small pieces of meat, toast, etc....
To grill large pieces of meat.
To bake pizza, bread, focaccia.
1
1. Selector knob: to choose the oven functions.
2. Button to select and confirm the different operations (operate by single presses only).
3. Knob to set: time of day, cooking time, the time at which cooking should terminate, the
temperatures and the power levels (Function P).
Push-Push knobs
• To use this type of knob, press it in the middle.
• Turn the knob to the desired position.
• Once cooking is over, turn the knob back to the position marked by "0" and press it again
to restore it to its initial setting.
STARTING THE OVEN
When the oven is connected to the power supply for the first time, or re-connected after a
power failure, the display shows "
To start the oven:
• turn knob 1 to "0".
The display shows "--:--".
• press button 2.
PRE-HEATING YOUR OVEN
Your Whirlpool oven has a special pre-heating programme to ensure a speedy heat up time.
To pre-heat your oven:
1. Select the P1 feature on the functions selector knob.
2. Set the required temperature on the temperature selector knob.
3. The temperature is indicated by the lights at the top of the control panel.
4. When the lights are fully lit, the pre-set temperature has been achieved.
5. As a guide, the temperature you select will normally be achieved within 12 minutes.
6. Now select the function and set the time you require, then continue the cooking process.
FOR A DESCRIPTION ON HOW TO USE THE OVEN, PLEASE REFER TO THE
PROGRAMMER DESCRIPTION SHEET.
