Combi BLODGETT BC142GDS Specifications

BC14GDS AND BC142GDS
Single or Double
Combination-Oven/Steamer
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Legs
4" (101.6mm) adjustable legs
6" (152.4mm) adjustable legs
6" (152.4mm) seismic legs
25" (635mm) adjustable legs
Drain assembly/steam vent kit
Single
Double
Floor stand with rack supports
Stand Mount Casters
Programmable digital controls with cook and hold
and Vario Steam®
Locking control panel
Locking door hasp
Tamper proof screws
Additional stainless steel wire shelves
Core temperature probe with digital readout
Stainless steel back panel
Chicken roasting rack
Gas manifold (for double stacked units)
Extended warranty
OPTIONS AND ACCESSORIES
(AT NO CHARGE)
LP gas
208/240 volt
Project
Item No.
Quantity
All data is shown per oven section, unless otherwise indicated.
Refer to operator manual specification chart for listed model names.
EXTERIOR CONSTRUCTION
Stainless steel top, front and sides
Stainless steel door, right hand hinge only
Tempered viewing window
Door mounted condensate trough
INTERIOR CONSTRUCTION
Fully welded stainless steel frame
Fully insulated cooking chamber
Fixed drain bottom center of cavity
Self draining door drip pan
OPERATION
Pull out control panel for service access
Modular controls allow for field upgrade to digital controls
Standard control with four function selection switch for steam, hot air, com-
bined steam/hot air, cool down, Vario Steam® and steam on demand feature
Solid state rotary dial thermostat - range 150-500°F (66-260°C)
Synchronous motor driven 120 minute timer
Two speed fan
Automatic shut-down at elapsed time with audible buzzer which continues until
manually shut off
Magnetic door interlock switch shuts off oven when door is opened
Electronic ignition
Open vented system
Waste air quenching. Condenses steam and drains away by-products of the
cooking process, eliminates flavor transfer
Automatic steam regulation
Maximum capacity - 14 steam table pans, 7 bake pans
STANDARD FEATURES
Five (5) stainless steel wire shelves per section
Pressure spray bottle
Hose and spray assembly for interior cleaning
Stacking kit and casters for double stack ovens
Two speed fan
Water pressure regulator (1 per section)
Start-up inspection service by factory authorized service agent - operational
testing and installation inspection
One year parts and labor oven warranty*
* For all international markets, contact your local distributor.
44 Lakeside Avenue, Burlington, VT 05401
Phone: (802) 658-6600 • Fax: (802) 864-0183
