SWASTIK LEMINAR CARD Quick Start Manual

Automation & Control
Model No: LEMINAR CARD
This instruction describes product function, features
and proper usage.
Content Index

Warning

S1

Note

S2

Features

S3 Technical specification
S1
Warning
! !
1. To avoid electric shock, DON'T touch the AC power supply
terminals after power on.
2. Before power on, please confirm voltage conformity in range of
AC 210~240V, to avoid damage to instrument.
3. Never remove, retrofit or repair the product or contact any
internal components.
4. Tighten screw with 0.74-0.90Nm torque, as loose screws may
cause fire.
5. Use appropriate fuse to ensure power supply line and
input / output line to prevent current impact.
6. Don't use the instrument in occasion of flammable,
explosive gas, discharge of steam.
Note
1. For heat radiation, leave space around the instrument and do
not jam the ventilation holes in the instrument
2. Keep enough space between the instrument and equipment
which generates high frequency and surge.
3. Connect wires correctly
4. Use the instrument under rated load and power supply.\
5. Use standard grade of alcohol to clean the instrument; don't use
paint thinner or similar chemicals
6. Read and understand this instruction carefully before use
7. Don't use the instrument in case the front panel peels of breaks.
S2
Features

Programmable Setting

16 x 4 LCD display

Easy to operate

High Accuracy of Length

Excellent quality, safety and strong resistance to
interference
Parameter Setting &
S4
Programming Mode Selection
S3

Technical specification

Display : 16 X 4 LCD Display
Measuring accuracy : + 0.0 1 %
Sensor : Analog Input
Range : Hr 999.59 Min / 99.59 Min.
Supply : 230VAc ± 20 %
S4
Panel Description & Explanation

SIMPLE / BURN MODE PARAMETER

Display
Sr.
Description
Message
No.
SET UV
Set the UV time
1
TIME
Set the total
TOTAL
2
tube time
TUBE TIME
RESET
Reset the total time
3
TOTAL TIME
SET TOTAL
Set the total
4
TUBE TIME
tube time
SET RTC Set the time
5
TIME & date
WELCOME
Set welcome
6
MESSAGE
message
Note: If low alarm will turn on then you will press reset
key then low alarm will turn off

ANALOG MODE PARAMETER

Display
Sr.
Description
Message
No.
SET UV
Set the UV time
1
TIME
Set the total
TOTAL
2
tube time
TUBE TIME
RESET
Reset the total time
3
TOTAL TIME
SET TOTAL
Set the total
4
TUBE TIME
tube time
Set the time
SET RTC
5
& date
TIME
SELECT Select channel
6
CHANNEL for observation
Set low alarm for
SET LOW
7
channel 1 & error
ALARM CH-1
for channel 1
Set low alarm for
SET LOW
8
channel 2 & error
ALARM CH-2
for channel 2
Set welcome
WELCOME
9
message
MESSAGE
Explanation
Range: Hr 99.59 Min.
Range: Hr 99.59 Min.
(Time for which tube have been in
operation)
This parameter will open in to
Password-1
Yes / No
This parameter will open in to
Password- 2
Range: Hr 99.59 Min.
This parameter will open in to
Password- 3
This parameter will open in to
Password- 4
This parameter will open in to
Password- 9
Explanation
Range: Hr 99.59 Min.
Range: Hr 99.59 Min.
(Time for which tube have been in
operation)
This parameter will open in to
Password-1
Yes / No
This parameter will open in to
Password- 2
Range: Hr 99.59 Min.
This parameter will open in to
Password- 3
This parameter will open in to
Password- 4
This parameter will open in to
Password- 5
This parameter will open in to
Password- 6
This parameter will open in to
Password- 7
This parameter will open in to
Password- 9
