1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:24 페이지 2
▶ Read the user's manual thoroughly before using the unit.
▶ The rated voltage of this unit is 220-240 V~/ 50 Hz only
▶ Unit appearance, specification, etc. are subject to change without
prior notice if necessary for improving unit performance.
▶ Design and color may differ from the picture.
ChungHo Bidet WHI CLE N N IS S
User'sManual
CHB-1300S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WHI CLEAN NAIS S and is the answer not in the manual?

Questions and answers

Summary of Contents for Chungho WHI CLEAN NAIS S

  • Page 1 ▶ The rated voltage of this unit is 220-240 V~/ 50 Hz only ▶ Unit appearance, specification, etc. are subject to change without prior notice if necessary for improving unit performance. ▶ Design and color may differ from the picture. ChungHo Bidet WHI CLE N N IS S User'sManual CHB-1300S...

  • Page 2: Table Of Contents

    Table of Contents Composition 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:24 페이지 3 1. Product Features 2. Safety Precautions 4 ~7 3. Names of each Part 4. Description of Control Panel 5. Usage 10 ~ 14 6. Installation Instruction 15 ~16 6-1.

  • Page 3: Product Features

    1. Product Features 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:24 페이지 4 1. 제품의 특징 Energy Saving Provided into two different power saving modes (normal power saving/enhanced power saving), the user can select the power saving mode suitable for him/her. The optimal energy saving modes set automatically the temperature of the hot water and toilet seat to prevent unnecessary power waste and to reduce the burden on the electricity bill.

  • Page 4: Safety Precautions 4 ~7

    2. Safety Precautions 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:24 페이지 5 "DANGER" "CAUTION". Cautions are divided into 2 categories: Associated with the possibility for serious injury or death. D NGER If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified •...
  • Page 5 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:24 페이지 6 Associated with the possibility of injury, property damage and performance degradation. C UTION Keep the product away from water. Do not throw away inflammables such as cigarette into toilet. (A malfunction, short circuit and fire may occur.) (A fire may occur.) Do not place heavy object on the product or do not Do not open up and close down with excessive...
  • Page 6 2. Safety Precautions 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:24 페이지 7 Associated with injury, property damage, and performance degradation. C UTION Do not disconnect the product. While using the product, if abnormal noise or smell arises, then plug out the power cord immediately. (An electric shock may occur.) (Request follow-up service.) Keep the air outlet and nozzle clean from urine.
  • Page 7 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:24 페이지 8 C UTION Associated with injury, property damage, and performance degradation. When the product is transported, hold the body of Child, the elder or physically challenged people are the product. recommended to lower the temperature of water, toilet seat and dryer.

  • Page 8: Names Of Each Part

    3. Names of each Part 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:25 페이지 9 Seat Cover Seating Sensor Bidet Nozzle Wash Nozzle Control Panel Seat "Seat occupied sensor" operates only when user sits down on the seat. Do not cover toilet •...

  • Page 9: Description Of Control Panel

    4. Description of Control Panel 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:25 페이지 10 Stop: Stop all the operations. Wash: This is for anal hygiene purpose. Press button once to operate. By repressing same button once more, it enters to “ Nozzle Position” mode. Bidet: This is for feminine hygiene purpose.

  • Page 10: Usage 10

    5. Usage 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:25 페이지 11 Plug power cord • When the power plug is connected to the power outlet, the indicator lamp will light up with the sound effect. Sit down on the seat. • Seat occupied sensor gets started and the product is set to be ready. Press "Wash"...
  • Page 11 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:25 페이지 12 ■ "Wash" and "Bidet" operations Wash Bidet Wash Bidet Press Press Massage + Massage + Press then press Press then press Wash Bidet Move + Move + Bidet Press then press Press then press Wash Move +...
  • Page 12 5. Usage 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:25 페이지 13 Kids setting • If "Kids" mode is set, the seat occupied sensor is disabled for 3 minutes to allow children to use "Wash" and "Bidet" without any inconvenience. • Set the restrictions on hot water and low water pressure. Multi Wash function •...
  • Page 13 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:25 페이지 14 Water Temperature function • Water temperature is controlled by pressing "+ " or "-" button. • As "+" or "-" is pressed, the water temperature changes by one level. • Water temperature can be controlled from level 1 up to level 5. At the initial point, the level is to level 3 (97 °F(36 °C)).
  • Page 14 5. Usage 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:25 페이지 15 ECO function • This function automatically lowers the water and toilet seat temperatures. • By pressing once, the LED will display in green color, and it will goes into general power saving mode.

  • Page 15: Installation Instruction 15 ~16

    6. Installation Instruction 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:25 페이지 16 6-1. Installation Insert bolt to bracket and put them into fixing plate. ① ② Place fixing plate beneath of the product body. Position bolt properly to insert it to hole of toilet. ③...

  • Page 16: Connection

    6. Installation Instruction 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:25 페이지 17 6-2. Connection ① Shut down the water supply valve by turning the faucet to the right. ③ ② Flush the water from the toilet bowl. ① ③ Disassemble the flexible hose connecting the water supply valve to the toilet bowl.

  • Page 17: Maintenance

    7. Maintenance 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:25 페이지 18 7-1. Cleaning Plug out the power plug before cleaning the product for safety. • Wash it up with wet towel. (Adjust the amount of water on the towel at small amount.) •...

  • Page 18: Troubleshooting

    8. Troubleshooting 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:25 페이지 19 Symptom Check point Insert power plug Is the power plug inserted Check if power failure occurs, properly? Request follow-up service. properly. The product does not work. Power is turned on? Request follow-up service.

  • Page 19: Memo

    Memo 1300S_영문매뉴얼_말레이시아향_CHB-1300S 18. 4. 13. 오후 5:25 페이지 20...
  • Page 20 Power cord length 1.8 m Dimension 469 W×545 D×152 H (mm) Product weight 4.6 kg ChungHo Malaysia, 10TH FL, FABER IMPERIAL COURT, JALAN SULTAN ISMAIL, 50250 KUALA LUMPUR, MALAYSIA TEL:+60-32-603-1800 / 1800-886677 / E-MAIL: info@chunghomy.com.my / HOMPAGE: www.chunghomy.com.my MANUAL DOWNLOAD: http://www.chunghomy.com.my/base/download Rev,No.00...
