Release date 01.07.2022
B6 Install & Operation
Manual
Safety
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
The unit should be isolated from the electricity supply before removal of any covers. Great care must be employed when
working with high pressure carbon dioxide, and in no cases should the maximum operating pressure of 0.4MPa (4 bar)
be exceeded.
The appliance is not suitable for installation in an area where a water jet could be used.
The appliance has to be placed in a horizontal position.
WARNING: Keep ventilation openings in the appliance enclosure or in the built-in structure clear of obstruction.
WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
This appliance is intended to be used in household and similar applications such as:-
Staff kitchen areas in shops, offices and other working environments
Farm houses and by clients in hotels, motels and other residential type environments
Bed and breakfast type environments
Catering and similar non-retail applications
A-weighted emission sound pressure level is below 70 dB(A)
R290 is a refrigerant-grade propane used on a wide range of commercial refrigeration and air
conditioning units. A highly pure propane, it has a low environmental impact and nominal global
warming potential (GWP), meaning it possesses no qualities that can destroy the ozone layer. R290
also is the preferred hydrocarbon alternative of the Environmental Protection Agency (EPA),
substituting more harmful fluorocarbon refrigerants like R22, R134a, R404a and R502.
Units with R290 can only be maintained and repaired by authorized technicians who are
properly trained and certified.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B6 and is the answer not in the manual?

Questions and answers

Summary of Contents for Borg B6

  • Page 1 Release date 01.07.2022 B6 Install & Operation Manual Safety This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 2 Always place the dispenser in its vertical position, on a surface which can capably support its weight. During use this machine must remain in its upright position. Adequate ventilation must be allowed for. Keep the machine away from sunlight, heat and moisture.
  • Page 3: Specification

    Specification...
  • Page 4 COOLING SYSTEM Stainless steel direct chill coil encased in a solid-block system for instant response cool down action. Ultra efficiency compression system with capillary control. Environmentally friendly R290 refrigerant. COLD TEMPERATURE 2°C - 11°C. OUTPUT PER HOUR 50 litres Chilled 50 litres Sparkling MAXIMUM RUNNING POWER 0.14kW - 230V CONSUMPTION - CHILLED &...
  • Page 5 FUSE RATING MINIMUM TO MAXIMUM INLET 0.05MPa (0.5 bar) - 1.0 MPa (10 bar) Internally regulated to 0.3 MPa (3 bar) WATER PRESSURE CO2 PRESSURE 0.4MPa (4 Bar) Maximum MINIMUM TO MAXIMUM 5°C - 35°C AMBIENT ROOM OPERATING TEMPERATURE CLIMATIC CLASS...
  • Page 6 Model Overview Introduction Hygienic and ergonomic, B6 flourishes in all environments – from boardroom to sports hall. Its compact size, large dispense area for bottles, multiple water options and flexible configuration. The B6 features a control panel designed for immaculate hygiene. Completely flush with no intricate buttons to harbour...
  • Page 7: Component/Feature Overview

    Component/Feature Overview B6 - Major Components Contents: 1 no Co2 Regulator with Gauge & Connection tube* 1 no Warranty Card 1 no B6 Unit 1 no 2.0m Power Cord Set...
  • Page 8 1. Unit Lid, 2. Side Panel, 3. Carry Handle, 4. Control Panel, 5. Dispense Outlet, 6. Drip Tray, 7. Power Connection, 8. On/Off Switch, 9. CO2 Inlet*, 10. Water Inlet...
  • Page 9 Please Note: Mains Installation Kit & Filters are supplied as extra items according to individual ordering requirement. *Sparkling versions only Dimensions...
  • Page 10: Installation Requirements

    Installation Installation Requirements Identify a suitable location for the B6 unit. It should be positioned within 2.0m of suitable services connections. Allow 15cm of free space at the rear for ventilation. The ProCore unit must be installed in accordance with the relevant requirements of: The appropriate building regulations by application of either The Building Regulations (England and Wales), The Building Regulations (Scotland) or The Building Regulations (Northern Ireland).
  • Page 11: Operation

    Operation Tap Control Panel 1. Unlock Button (commissioning mode), 2. Chilled Dispense, 3. Sparkling Dispense, 4. Ambient Dispense, 5. Hot Dispense 6. ‘eco’ Mode Symbol 7. Warning Symbol. Basic Functions...
  • Page 12: Warning Symbol

    Advanced functions Hold ‘Hot Unlock Icon’ for 10 seconds for decommissioning and commissioning. B6 Installation & Water Connection Connect the water inlet adapter as Connect the CO2 supply from gas Connect the chiller to the electricity...
  • Page 13 Turn on the water supply. The carbonator should be purged of The hot versions will be in air by activating the sparkling water commissioning mode which stops the dispense for approximately 10 unit from running only allowing seconds. dispensing. With hot water versions fill the hot tank until you see water dispense.
  • Page 14 Attach the regulator to the disposable Unpack CO2 Regulator and fit elbow Connect the assembled CO2 bottle CO2 bottle, ensuring the small fitting to spigot outlet. and regulator to the CO2 inlet using a pressure relief vent in the stem is facing ¼”...
  • Page 15 NOTE: Sparkling water flow rate factory setting = 2.4L per minute MAX. This may need adjusting depending on inlet pressure. To do so follow below steps: Remove the 2 screws Remove the right hand side Locate the flow control Flow can then be adjusted holding the unit lid down panel screws.
  • Page 16 Maintenance & Cleaning Sanitisation Guide NOTE: Failure to use sanitising products and processes approved by Borg & Overström will invalidate your warranty. This operation must only A sanitisation procedure is Turn off incoming mains Briefly press chilled be carried out by trained...
  • Page 17 Turn on incoming water, Dispense water using the Leave the solution inside Pay particular attention to allow the service filter chilled button until the machine for sanitisation to the dispense faucet and cartridge to fill water appears pink. take effect (minimum 5 the push button controls.
  • Page 18 Turn off water and briefly Remove the service filter. Fit new filter and turn on Pre-flush the new filter to press chilled dispense Retain service filter for incoming water supply. waste using the chilled button to release internal reuse. button until the water water pressure from the appears clear and is free machine.
  • Page 19 Advanced Troubleshooting Fault Diagnostics...
  • Page 20 Problem/Report Possible Cause Suggested Action No Water Dispensing Power supply Check the power supply has been fitted properly and turned on. turned off Water Pressure Check water flow through the regulator. Regulator Replace if necessary. Check Tap HMI Check fault codes. Control Water isolated Check water inlet supply.
  • Page 21: Fault Codes

    Problem/Report Possible Cause Suggested Action Water lying on top edge Overflowing drip Empty waste container and check drainpipe is not blocked. of lower door panel tray or waste and/or bottom of container cabinet Water lying in bottom of Leak in pipe work Contact your distributor.
  • Page 23 Technical Information Chilled & Ambient Circuit Schematic Chilled, Ambient & Sparkling Circuit Schematic...
  • Page 24 Chilled, Ambient & Hot Circuit Schematic...
  • Page 25 Chilled, Ambient, Sparkling & Hot Circuit Schematic...
  • Page 26 Water Pathway - Chilled & Ambient...
  • Page 29 Water Pathway - Chilled, Ambient & Sparkling...
  • Page 32 Water Pathway - Chilled, Ambient & Hot...
  • Page 34 Water Pathway - Chilled, Ambient, Sparkling & Hot...
  • Page 37 Spares B6 Exploded Parts Diagram...
  • Page 38: Spares List

    Spares List...
  • Page 39 Part No. Description CSAH 720337 Main Control PCBA • • • • 700154 LED PCB • • • • 701630 Top Panel • • • • 701678 Side Panel • • • • 720341 Front Panel Black • • • •...
  • Page 40 Part No. Description CSAH 701588 3/4'' BSP Inlet Solenoid • • • • 701886 8mm PRV 2 Bar • • • • 702146 Flow Restrictor • • 701729 Hot Inlet Solenoid • • 701937 8mm 2 Way Solenoid • • 701992 8mm 3 Way Solenoid •...
