- Page 1 EXCAVATOR MOUNTED COMPACTOR IHC150 MODEL CREATING SAFE WORKING ENVIRONMENTS mgf.co.uk...
- Page 2 CREATING SAFE WORKING ENVIRONMENTS With 40 years of experience, MGF is a privately-owned company whose primary focus is the provision of fully engineered excavation support solutions to the civil engineering, construction, rail and utilities sectors. We combine technical expertise and operational performance to ensure the highest levels of customer service.
-
Page 3: Table Of Contents
CONTENTS SECTION 1: INTRODUCTION SECTION 2: TECHNICAL DATA SECTION 3: PARTS DESCRIPTION / IDENTIFICATION SECTION 4: COMPONENT WEIGHTS & DIMENSIONS SECTION 5: RISK ASSESSMENT CHECKLIST SECTION 6: DO’S / DON’TS SECTION 7: COMPACTOR OPERATION 7.1 DELIVERY 7.2 CONNECTING TO THE COMPACTOR VIA AN EXCAVATOR QUICK HITCH 7.3 CONNECTING THE HYDRAULIC LINES 7.4 PRE-USE CHECKS 7.5 OPERATING INSTRUCTIONS... -
Page 4: Section 1: Introduction
INTRODUCTION Excavator mounted compactors (also named compaction plates) can be used to provide safe, fast, efficient compaction for surfaces including soil sand gravel hardcore or recycled materials. In addition to open areas, they can also be used within excavations and on embankments. They can be used to drive in piles or formwork. -
Page 5: Section 2: Technical Data
Oil Flow to motor 120 L/min Max Working Pressure adjusted to the excavator 200 bar Max Backpressure 21 bar Note: Weights stated above do not include QH connection bracket. IHC150 - CENTRIFUGAL FORCE - VS - FLOW IN IHC150 IHC150... -
Page 6: Section 3: Parts Description / Identification
Alternate size QH Bracket Pins (IHC 150 only – Ø65 & Ø80 pin options provided) Spare QH Pin – Locking Bar 4 x Lift Point (suitable for – MGF Std Duty 4 Leg Chain) 4 x Ratchet Strap attachment points – see blue lines in image above for strap pathway... -
Page 7: Section 4: Component Weights & Dimensions
470 (Ø80 pin centres) 365 (Ø65 pin centres) 1240 1360 330 - max QH frame width IHC150 WEIGHTS: Compactor IHC150 = 800kg • • Quick Hitch Connection Bracket (with 2 pins fitted) = 190kg Spare Pins (2off) = 30kg total (15kg ea) •... -
Page 8: Section 5: Risk Assessment Checklist
Ensure that regular checks are carried out to ensure that hazards are controlled and the equipment is in good working order • Ground vibrations may lead to substantial nuisance or hazard to the adjoining areas. *MGF Ground Vibration Monitors are available for hire. • Improper use of the compactor can lead to dangerous situations... -
Page 9: Section 6: Do's / Don'ts
Store the compactor in a safe clean area, on or with its transport skid when not in use Place compactor onto transport skid and fit ratchet straps when ready for re- collection Have hydraulic spill kits available (can be sourced from MGF) before commencing works Employ Safe manual handling techniques where applicable... - Page 10 DONT’S: Do not operate the compactor if anyone is in the exclusion zone Do not enter the ‘Exclusion Zone’ if the compactor is being operated Do not use the compactor if it is faulty in any way Do not touch the compactor during the operating process (even if the excavator is switched off) as it can become hot Do not over compact and this can lead to services damage.
-
Page 11: Section 7: Compactor Operation
If moving the skid at any point the ratchet straps must always be used and secured. (For IHC150 only) the compactor will be supplied with a Quick Hitch bracket that can have either Ø65 or Ø80 pin options fitted. -
Page 12: Connecting To The Compactor Via An Excavator Quick Hitch
• Ensure the compactor is only ever fitted to uni-directional flow systems, unrestricted back to tank • An MGF fitter will set up and identify hoses – by putting RED PVC tape around the ‘flow in’ designated hose on the compactor. Red tape around also around the excavator flow out QR fitting. -
Page 13: Pre-Use Checks
Return Hose HVFK050F000 Pressure Hose Manifold In – Out orientation of Compactor – ref for fitters 7.4 PRE-USE CHECKS When all installation works are completed, check the following before operating the compactor. While moving the excavator’s bucket cylinder slowly in and out in the direction of ‘crowd’ and ‘dump’, check: For any interference or obstruction between the compactor and excavator Whether the length of the connecting hoses are too short or too long... -
Page 14: Operating Instructions
7.5 OPERATING INSTRUCTIONS Press down in a direction vertical to the ground, with compactor plate angled to match ground angle. Whilst applying force, elastomer blocks must not deform/stretch by more than 40mm. -
Page 15: General Advise/Instructions
Max deflection = half original elastomer diameter • Place the compactor uniformly on the ground you want to compact • Lower the excavator’s boom slowly to press the compactor vertically to the ground Ensure that the Elastomer Block is deformed/stretched less than 40mm. If the Elastomer Block is pressed more than the specified limit, it may be damaged or its life might be shortened If you operate the compactor, having touched a very hard object such as a concrete floor... -
Page 16: Section 8: Maintenance
MAINTENANCE SERVICING AND MAINTENANCE OF COMPACTORS TO BE CARRIED OUT BY MGF ONLY. DO NOT ATTEMPT TO CARRY OUT MAINTENANCE OR REPAIRS. IHC150 = Reservoir Capacity = 4.8L (85/90W Gear Oil) CHECKS / FREQUENCY OF CHECKS DAILY: Check Quick Hitch connecting bracket for loose cracked or missing bolts (this is both... -
Page 17: Section 10: Steps To Attempt Release Of Hydraulic Pressure In 'Pecker Circuit' Of An Excavator
STEPS TO ATTEMPT RELEASE OF HYDRAULIC PRESSURE IN ‘PECKER CIRCUIT’ OF AN EXCAVATOR ISSUE = WHEN ATTEMPTING TO RELEASE OR USE THE ‘QUICK RELEASE’ COUPLINGS OF THE COMPACTOR FROM AN EXCAVATOR ‘PECKER CIRCUIT’, PRESSURE CAN BE TRAPPED IN THE CIRCUIT WHICH MEANS THE QUICK RELEASE COUPLINGS ARE VERY HARD TO OPERATE, OR CANNOT BE OPERATED DUE TO THE PRESSURE. - Page 18 Ensure the dead man switch (usually a lever at the side of the operator’s seat) is up or enabled. Do not operate or move the joysticks or other controls, but carefully move only the control switch for the pecker circuit. This should be switched several times.
- Page 19 Complete the steps within approx. a 30 second period. (reason - accumulator pressure can drop over time due to wear or seal leakage. A newer machine will give you more time to complete the steps etc.) If pressure cannot be released by this method contact an MGF fitter.
