rough country 921995100 Manual

8 speaker, 500-watt sound bar
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
921995100
8 SPEAKER, 500-WATT SOUND BAR
Thank you for choosing Rough Country for all your vehicle needs!
Please read instructions before beginning installation. Check the kit hardware
against the kit contents shown below. Be sure you have all needed parts and
know where they go.
If question exist, please call us at 1-800-222-7023. We will be happy to answer
any questions concerning this product. Check all fasteners for proper torque.
Check to ensure for adequate clearance between all components.
Periodically check all hardware for tightness.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 921995100 and is the answer not in the manual?

Questions and answers

Summary of Contents for rough country 921995100

  • Page 1 921995100 8 SPEAKER, 500-WATT SOUND BAR Thank you for choosing Rough Country for all your vehicle needs! Please read instructions before beginning installation. Check the kit hardware against the kit contents shown below. Be sure you have all needed parts and know where they go.

  • Page 2: Left Side

    Sound bar Layout Backlit Speakers Control Panel FRONT Backlit Woofer Backlit Woofer LEFT SIDE RIGHT SIDE Auxiliary Power Out 12V Power In SAE SAE Connector (Black) Connector (Red) Light Bar BACK...
  • Page 3 In/Out Connections AUX-IN AUX-OUT Port (Gray) Port (Black) USB Charging Port Do NOT use these connections if they are wet. AUX-IN: This input can be used to connect a CD player, MP3 player, etc. AUX-OUT: This output can be used to connect to an amplifier or to another speaker AUX-IN connection.
  • Page 4 Connecting to 12VDC Power Supply The sound bar does not have an internal battery. It must be connected to an external 12VDC power supply to function. When you install the sound bar to a battery or a voltage regulator on a golf cart, a boat, a quad bike, a UTV, or another vehicle, you need to make sure that your vehicle battery or battery pack terminal voltage is 12VDC.
  • Page 5 Installation: Gas Vehicle 1. Loosen the bolts on the battery terminals. Use Caution: Do NOT attempt to loosen bolts if battery is wet. Contact may cause electric shock and injury if wet. 2. Connect the BLACK wire to the Loosen Bolts BLACK, negative terminal, then the RED wire to the RED, positive terminal.

  • Page 6: Control Panel

    Controls 1. LED Indicators: Each of the 4 LEDs correspond to different functions: Power, Bluetooth, Mode, and Status. 2. Power Button: Press button to turn the sound bar on / off. 3. Mode Button: Press button to cycle through the following modes: Bluetooth, EcoCast Transmitting, EcoCast Receiving, FM, and AUX-IN.

  • Page 7: Led Indicators

    Operations LED Indicators From left to right, the 4 LED Indicators correspond to Power, Bluetooth, Mode, and Status. 1. Power Solid Green: Power On No Light: Power Off 2. Bluetooth Flashing Blue: Bluetooth Paring Solid Blue: Bluetooth Connected 3. Mode Solid Blue: Speaker Mode Solid / Flashing Red: EcoCast Transmitting Mode Solid / Flashing Green: EcoCast Receiving Mode...

  • Page 8: Pairing A Bluetooth Device

    Pairing a Bluetooth Device 1. Turn on your Bluetooth device. 2. Power on the sound bar. “Speaker on, ready to connect” voice prompt will be heard. If the Bluetooth LED Indicator (the second LED Indicator from the left) is not flashing, briefly press start pairing your device.
  • Page 9 Play Music (Bluetooth Mode) After the sound bar is connected to your Bluetooth device, press briefly on the sound bar controls to play, press again to pause. Press briefly to play previous song. Press briefly to get the next song. Notes: ·...
  • Page 10 EcoCast – Broadcast Your Music to Multiple Speakers When you have two or more sound bars, you can build a broadcast system by initiating EcoCast Transmitting Mode in one sound bar speaker and broadcasting your music to one or more sound bar speakers in EcoCast Receiving Mode.
  • Page 11 EcoCast: Additional Receiving Speakers 1. Power on the additional SoundExtreme speaker(s) (Speaker C and Speaker D). Press to cycle through to and initiate EcoCast Receiving Mode. The Mode LED Indicator will flash Green, and the speaker(s) will announce, “EcoCast receiving. ” 2.

  • Page 12: Accessory Mode

    Listening to FM Radio (FM Mode) Press briefly to cycle through to FM Mode. Press briefly to tune in a radio station. To “seek” (jump to the next available station), PRESS AND HOLD either button down for a few seconds until it starts to seek a station.

  • Page 13: Pairing Your Remote Control

    Remote Control Pairing Your Remote Control Before you use your Remote Control for the first time, pull and remove the plastic tab at the bottom of the Remote Control. Your Remote Control should be paired to your unit. IF NOT paired, please follow the steps below.

  • Page 14: Remote Switch

    After the sound bar is connected to your Bluetooth device, press briefly to play, press again to pause. Press briefly to play previous song. Press briefly to get the next song. Press briefly to adjust the speaker volume. LED: Backlit Speakers Press briefly to turn on your speaker backlights.
  • Page 15 Mounting Your Speaker 1. To mount the speaker, first place the 2 Mounts on the ends of the sound bar at your desired orientation and attach them using three or four (depending on the orientation of your mount) Button Head Bolts, each. Tighten securely.

  • Page 16: Troubleshooting

    Troubleshooting The sound is distorted Try lowering the volume control of your connected device or musical instrument. Also, try to reduce the overall volume of the sound bar. Cannot Pair With Bluetooth Device Make sure that your device is compatible with Bluetooth. Turn off your sound bar and Bluetooth device, then power on and reconnect.

  • Page 17: Specifications

    Specifications Dimensions 4.5 in / 114.3 mm 25.5 in / 647.7 mm Bluetooth Compliance EcoCast Bluetooth V 5.0 Using Qualcomm® Broadcast Audio technology Bluetooth Frequency Band EcoCast Range 2.402~2.480GHz ISM Spectrum 30 ft / 9.1 m between Casting Modulation speaker and Receiving speakers GFSK, π/4-DQPSK, 8DPSK Compatibility Bluetooth Range...
  • Page 18 Read and follow all instructions. Use only as intended. The Rough Country Bluetooth speaker is intended to be used indoors or outdoors and in land or water environments. The speaker has been tested to IP66 waterproofing standards, which means the speaker can be exposed to dust and water, but should not be submerged underwater.
  • Page 19 5.) Contact Rough Country or return the sound bar to a certified recycling center, if you suspect water ingress into the unit or if the unit has experienced a severe impact that may have affected the integrity of the unit to take on water.

  • Page 20: What's In The Box

    921995100 8 SPEAKER, 500-WATT SOUND BAR Thank you for choosing Rough Country for all your vehicle needs! Please read instructions before beginning installation. Check the kit hardware against the kit contents shown below. Be sure you have all needed parts Auxiliary Power Out Mating Connector and know where they go.
