Access control – and security management system

Advertisement

Access Control –
and Security Management System
Installation and Service
Manual
BCR-SD G2
1-981-2180-GB, 2021-03-16
BCR-SD G2
I
 SystemHouse Solutions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCR-SD G2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Integra BCR-SD G2

  • Page 1 Access Control – and Security Management System Installation and Service Manual BCR-SD G2 1-981-2180-GB, 2021-03-16 BCR-SD G2  SystemHouse Solutions...
  • Page 2 SystemHouse Solutions AB assumes no responsibility for or liability for errors contained in this guide or for incidental, special or consequential damages arising out of the use of this guide in operating the system. All product names and trademarks mentioned in this document belong to their respective owners. 1-981-2180-GB, 2021-03-16 BCR-SD G2  SystemHouse Solutions...
  • Page 3: Table Of Contents

    No communication with the Reader ................18 6.2.2 Reader is not working ....................18 ATTACHMENTS ..................19 ....................19 ONSTRUCTION ...................... 19 UNCTIONS BCR-SD G2 ........... 20 AS A PART OF DOOR ENVIRONMENT ....................... 21 RAWINGS 7.4.1 Dimensions ........................21 HISTORY ....................22...
  • Page 4: System Overview

    System Overview This manual provides instructions for installation, cabling, power supply evaluation for BCR-SD G2 and describe service procedures. Parts List Supplied: BCR-SD G2 1 pcs Connector 1 pcs III. Wall tamper springs 2 pcs Box tamper springs 2 pcs...
  • Page 5: Article Numbers

    Article numbers 44 28 03 70 BCR-SD G2 1.3.1 Accessories There are several accessories types available: 44 28 02 70 Installation plate for xCR-SD G2 44 28 02 71 Installation angle 15 Degrees xCR-SD G2 44 28 02 72 Installation angle 30 Degrees xCR-SD G2...
  • Page 6: Safety Instructions

    • Reader must be disconnected from voltage before installation and service. • Do not modify any components or part of device. • All reparation should be performed only by the manufacturer. 1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 6  SystemHouse Solutions...
  • Page 7: Installation Procedure

    Route cables to other accessories to be connected.  Install the bottom part of BCR-SD G2 box to the wall. Feed all cables inside the box to appropriate position and fix them to the box with cable ties.
  • Page 8: Device Overview

    Device overview 1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 8  SystemHouse Solutions...
  • Page 9: Opening Device

    For opening device follow instructions in Quick Installation Guide (part of device delivery) or look in section in this document. Opening tool: Maximum torque for box installation When device is installed by using an electrical screwdriver the maximum torque used shall be 2.5 N/m. 1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 9  SystemHouse Solutions...
  • Page 10: Installation On Metal Surfaces

    2. Cut tamper activators placed at bottom cover at plastic level. 3. Install springs from bottom side. 4. Fix bottom cover with screws at installation place. Surface level needs to be even. 1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 10  SystemHouse Solutions...
  • Page 11: Power Supply

    Power Supply BCR-SD G2 does not use its own power supply, instead it is powered from S-Node G2, central unit C-Node G2 or Moveo/XL. The S-Node G2 is normally powered from central unit where power supply and communication line are distributed together to door environments.
  • Page 12: Communication And Address

    Communication and address There is one RS485 communication line to/from the BCR-SD G2. Setting address For proper communication on RS485 device needs to have proper address assigned. All devices have from production address 1. If another address is required default address must be changed by following next steps: 1.
  • Page 13 Until the new address is confirmed you can change address any time. 4. Press “Menu button” to confirm new address. If you want to leave address configuration menu without change press “Back button”. 1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 13  SystemHouse Solutions...
  • Page 14: Rs485 Communication Line

    Up to two card readers can be connected to the same S-Node G2, in-reader and out-reader. Since together with communication line is distributed also power line we do use mixed cable to supply both in one. 5.2.1 Line installation PL1 24VDC/RS485 1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 14  SystemHouse Solutions...
  • Page 15: Line Termination

    ALWAYS calculate voltage drop before selecting cable. 5.2.3.1 PTS-HF-2x2x0.6 We always recommend screened, twisted pair cables, type PTS-HF-2x2x0.6 for RS485 lines. A screened cable is considerably more difficult to wiretap than an unscreened cable. 1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 15  SystemHouse Solutions...
  • Page 16: Rs485 Network Topology And Termination Principles

    This can be done by using two cable pairs for the bus, "RS485 out" and "RS485 in". C-Node G2 can be equipped with an optional connection block for this, CG2-VDE 1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 16  SystemHouse Solutions...
  • Page 17: Service Routines

    In this case bottom part must be exchanged. Measure voltage on screw terminal and compare it against level on used power supply. •  Voltage must be within range 20-30 V DC. 1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 17  SystemHouse Solutions...
  • Page 18: Fixing Common Issues With The Reader

    2. Check power supply if it’s within range 20-30 V DC. 3. Check setting of switch SW1 – termination of RS485 according position of reader on the line. 4. Check setting inside system if device has proper address set. 1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 18  SystemHouse Solutions...
  • Page 19: Attachments

    Display guided operation. The display provides for certain functions such as alarm areas, menu- based interface. LED’s for indication of door status, etc. Built in buzzer for warning and button press indication etc. Integrated heater is activated at low ambient temperatures. 1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 19  SystemHouse Solutions...
  • Page 20: Bcr-Sd G2 As A Part Of Door Environment

    BCR-SD G2 as a part of door environment 1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 20  SystemHouse Solutions...
  • Page 21: Drawings

    Drawings 7.4.1 Dimensions 1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 21  SystemHouse Solutions...
  • Page 22: History

    2018-05-04 Updated pictures of PCB. 2019-01-28 Accepting changes in manual file. 2019-02-15 Added description about installation on metal surfaces. 2020-01-03 Updates with new logos and company name 2021-01-25 Accessories types updated 1-981-2180-GB, 2021-03-16 BCR-SD G2 Page: 22  SystemHouse Solutions...
