Socket up

J 2
Connection to the mother board:
Warning:
After 50 plug in and 50 plug out of the socket up on the mother board, the efficiency of the connection
is no more guaranteed by the connector manufacturer:
Connector designation
Manufacturer
Part number
confidential ©
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written
agreement.
Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son
autorisation préalable.
V 1.0
ANUAL
T o p v ie w
B o t t o m v ie w
Socket up
Antenna PAD
J3
J2
80- pin header
on the mother board
DF12(3.0)-80DP-0.5V(80)
E ! R
RROR EFERENCE SOURCE NOT
Error! Reference source not found.
W ISM O
P5 1 8 6
M o d u le
A n t e n n a
P A D
J 3
Mother board
J300 (RF connector type IMP)
J301
J302
80- pin receptacle
on the socket up
HIROSE
DF12(3.0)-80DS-0.5V(80)
