Switches
Ignition Switch
The ignition switch is a three-position, key-operated
switch. The key can be removed from the switch when it
is in the OFF position.
OFF The engine is off. Electrical circuits are off,
except Acc, 12V.
ON Electrical circuits are on. Electrical equipment
can be used.
START Turn the key to the START position to engage
the electric starter. The key returns to the ON
position when released.
Light Switch
The ignition switch key must be in the ON/RUN position
to operate the headlights. Press the top of the rocker
switch toward the dash to place the headlights on high
beam. Move the rocker switch to the center position to
place the headlights on low beam. Press the bottom of the
rocker switch to turn off the headlights.
AWD/Differential Lock Switch
The AWD/Differential switch has three positions:
• All Wheel Drive (AWD)
• Differential Lock (2WD)
• Differential Unlock
Press the top of the rocker switch to engage All Wheel
Drive (AWD). See page 46 for operating instructions.
Move the rocker switch to the center position to lock the
differential and operate in rear wheel drive. Press the
bottom of the switch to unlock the differential and allow
the two rear drive wheels to operate independently. See
page 47 for differential lock operating instructions.
FEATURES AND CONTROLS
Differential Lock
Differential Unlock
Ignition Switch
HIGH
LOW
OFF
AWD
