T- Bar Lumo
PANEL
Product code
Product code
Installation Manual
Notes
⚫
This fitting requires 100-240V AC/50HZ power input to the driver.
⚫
Do not interchange any parts of this fitting.
⚫
Do not touch fitting when in use.
⚫
Do not cover with any form of heat proof material.
⚫
If you have any questions about the installation of this product, please contact Mondolux.
MP02
595mm
Installation Steps - Recessed
1.
Ensure the mains power is turned off.
2.
Cut required holes in ceiling or remove the plaster board for existing ceiling. Ensure minimum
space requirements between fitting and driver. See pictures 1a and 1b.
3.
Insert and fix the recessed plaster frame into the cut-out. See pictures 2a and 2b.
4.
Mount the fixture on to the recessed plaster frame and secure it. See picture 3.
5.
Connect flex and plug to the power supply.
6.
Installation is complete. See picture 4.
MP02 MP23 MP24
MP23
1a
2b
mondolux.com.au
MP24
1b
3
2a
4
