- Page 1 REMOTE CONTROLLED LOG SPLITTER WINCH 16 / 20 / 25 INSTRUCTIONS FOR USE AND MAINTENANCE...
-
Page 2: Table Of Contents
INDEX INTRODUCTION ........................3 SPLOŠNA GENERAL SAFETY INSTRUCTIONS ................4 2.1. Important instructions before use ....................4 2.2. Technical data ..........................5 2.3. Description of the hydraulic winch ....................5 UNLOADING FROM THE TRANSPORT VEHICLE ................6 USING THE HYDRAULIC WINCH WITH A WIRE ROPE..............7 4.1. -
Page 3: Introduction
1. INTRODUCTION Dear buyer! Congratulations on purchasing the ROBUST log splitter with a winch. We would like to thank you for your trust. At the same time, we are convinced you will be pleased with the product and will be able to use it for a long time. -
Page 4: Splošna General Safety Instructions
(children). Ensure adequate visibility. 15. Before transport, move the log splitter to the required position. 16. Always adapt the driving speed to the current conditions. Avoid rapid turning when driving up, down or laterally across a slope. 17. The user is not allowed to change the factory settings. -
Page 5: Technical Data
2.2. Technical data Suitable for log splitters: ROBUST 16 / 20 / 25 Drive Hydraulic engine connected directly to the drum Traction force [kg] Weight of the winch [kg] Dimensions HxWXL [mm] 472 x 520 x 810 Length of wire rope [m]... -
Page 6: Unloading From The Transport Vehicle
3. UNLOADING FROM THE TRANSPORT VEHICLE High risk of tipping over. Figure 1 Place the log splitter from the transport vehicle on a flat and firm surface. To unload the machine use a movable hydraulic ramp or a lift that can be attached to the lifting eye on the winch (1). Remove the packaging from the log splitter. -
Page 7: Using The Hydraulic Winch With A Wire Rope
4. USING THE HYDRAULIC WINCH WITH A WIRE ROPE The hydraulic winch operates by reeling the wire rope with a hook to the drum. 4.1. Connecting the electrical socket To ensure correct operation, the electrical socket on the tractor must be connected as shown in figure 2 or in accordance with the ISO 1724:2003 standard that regulates traffic signalization of attachments. -
Page 8: Using The Remote Control
4.2. Using the remote control The left button (3) is used to activate the reeling of the wire rope, while the right button (6) is used to activate the unreeling function. The safety button (4) switches off the functions of the remote control. To re-activate the remote control, press and hold button 4 for at least three seconds, until the signal indicator turns on (5). -
Page 9: Using The Remote Controlled Winch
4.3. Using the remote controlled winch By pressing the right button (6) on the remote control, the function of unreeling the wire rope from the drum is activated. Pull the hook (2) of the wire rope with your left hand and at the same time press and hold the right button (6) on the remote control. -
Page 10: Video Of The Remote Controlled Winch Operation
Pull the wire rope close to the log, wrap it around the log and secure it with the wire rope hook (Figure 4). Lifting clamps can also be used for pulling and lifting (additional equipment – figure 5, figure 9). Figure 5 When you press the left button (3) for reeling, the wire rope starts reeling back on the drum and thus towing and lifting the log. -
Page 11: Regular Inspections And Maintenance Of The Log Splitter With Winch
5. REGULAR INSPECTIONS AND MAINTENANCE OF THE LOG SPLITTER WITH WINCH Prior to each inspection, maintenance, cleaning or repair of the log splitter with winch, turn off the tractor engine and remove the key. Secure the tractor against moving. 5.1. -
Page 12: Remote Control
Unscrew the safety nut (2) and tighten the ball and spring screw (3) for ¼ of a turn. Check the unreeling of the wire rope. If the wire rope is unreeling even though you are not pulling the hook, tighten screw (3) as necessary. After the settings are carried out, keep the screw (3) still and tighten the safety nut. -
Page 13: Additional Equipment
6. ADDITIONAL EQUIPMENT Gripping pliers for rope winch Figure 9 7. MAINTENANCE AND REPLACEMENT PARTS We are offering repairs, maintenance, and the necessary replacement parts and additional equipment for the product for a period of at least five (5) years after the end of serial production of the product. -
Page 14: Declaration Of Conformity
ARJA VAS 104, SI-3301 PETROVČE DESCRIPTION OF DEVICE – MACHINE: LOG SPLITTER ROBUST 16 / 20 / 25 WITH A HYDRAULIC DRIVEN REMOTE CONTROLLED WINCH UNDER OUR SOLE RESPONSIBILITY WE DECLARE THAT THE MENTIONED MACHINE: LOG SPLITTER ROBUST 16 / 20 / 25 WITH A HYDRAULIC DRIVEN REMOTE CONTROLLED WINCH... -
Page 15: Warranty
Warranty is valid for 24 months from the date of purchase. In the event of failure of the log splitter or winch within the warranty period, the manufacturer ROBUST d.o.o. is obliged to eliminate the failure in a legally defined period. Repairs will be carried out by qualified professionals and only original replacement parts will be used. - Page 16 ROBUST d.o.o. +386 (0)3 703 88 23 Arja vas 104 +386 (0)3 703 88 07 3301 Petrovče www.robust.si Slovenija info@robust.si © Copyright ROBUST d.o.o. May 2014.
