Glory E3 /SERES 3 User Manual
DFSK Motor Co., Ltd.
October 2019
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Glory 3 Series and is the answer not in the manual?

Questions and answers

Related Manuals for DFSK Glory 3 Series

Summary of Contents for DFSK Glory 3 Series

  • Page 1 Glory E3 /SERES 3 User Manual DFSK Motor Co., Ltd. October 2019...
  • Page 2 6 months. If you has to repair or maintain your car, please timely get in contact with DFSK or DFSK local dealers Special Service Center. All staff of DFSK or DFSK local dealers Special After-sales Service Center will provide considerate and satisfactory service for you.
  • Page 3 The Manual is applicable to all types of this vehicle, including some optional configurations. Therefore, maybe you will find some information not applicable to your car. All information, specification parameters and illustrations herein are in the specification when the Manual is printed, and DFSK reserves the right to modify the vehicle specifications or design at any time without any notice.
  • Page 4 Reading for Safe Driving Please read through the Manual before driving which ensures The symbol means “don’t do it” or “prevent it that you can know about the requirements of control and maintenance and is helpful for your driving. The arrow in the illustration means front of the vehicle. The Manual uses the sign of “...
  • Page 5 DFSK Automobile Co., Ltd. will not assume any liability. ● In order to ensure vehicle performance, please adopt the true DFSK parts. In case of any direct or indirect losses due to using of not true DFSK parts, DFSK Automobile Co., Ltd. will not assume any liability.
  • Page 6 New Energy Your car can be provided with good maintenance and reliable quality guarantee, and you have the supervision right over the run- in maintenance, regular maintenance and repairing done by DFSK Special After-sales Service Centers. DFSK Automobile Co., Ltd. is pleased to receive your comments or advices by phone or e-mail.
  • Page 7 Glory E# or SERES 3 used battery recycle as follow: Battery belongs to high-volt part, and vehicle owner shall drive the vehicle into DFSK authorized service station for the repair if any battery repair or battery shift.

  • Page 8: Table Of Contents

    Contents General Information ..................................Design ................... Trim ..................... Motor Compartment ................. Open & Close ....................................Key ....................Door Lock ..................Door Window ..................Storage ................... Seats and SRS airbag ..................................Front& Rear Row Seat ................Safety Belt ..................ISOFIX ................... SRS .....................
  • Page 9 Drive & Handle System ................. Car Starting ..................Drive .................... Gear-shift ..................Brake system ..................Steering Column Control ................ADAS System ..................Instrument Meter ................... Indicator and Sound reminder ................. Light Switch ..................Wiper & Washer Switch ................Cruise Control System ................Rearview Mirror ..................
  • Page 10 Heater & A/C ..................Audio Entertainment System ................Antenna ..................Reverse Camera System ................Panoramic Parking ................. Trip Recorder ..................Wireless Charge……………………………………………………………………………………………………………. Speaker………………………………………………………………………………………………………………………. Player………………………………………………………………………………………………………………………… MP5 ..................... Vehicle Charging ..................................... High-volt warning .................. Charge outlet ..................Charge gun and inlet ................Charge and discharge ................
  • Page 11 Maintenance ....................................Maintenance Precautions ................Car Cleaning ..................Protection and Corrosion ................Reservoire Water Tank ................Timing Belt ..................brake ..................... Air Filter ..................Windowshield wiper blade ................Windowshield wiper Cleaner ................Remote battery ..................Fuse Box ..................Vehicle Lights ..................Tire and wheel ..................

  • Page 12: General Information

    Lubricant and its rated quantity ................Vehicle Technical Parameters ................................ Vehicle Dimension .................. Register as travling or abroad ................. Vehicle Identification Number (VIN) ..............General Information...
  • Page 13 light 4. Windows (P.- 29 -) Front Design 5. Antenna (P.- 123 -) 1. Motor cover (P.- 27 -) 6. Tire 2. Front windscreen wiper and washer - Tire and wheel (P.- 178 -) - Tire pressure label (P.- 197 -) 7.
  • Page 14 Rear Design 5. Brake light - Operating switch (P.- 99 -) Note: As per GB1589, the parts indicated by item 2 and 5 (soft parts), 9, 10 and 12 are not included into the vehicle dimensions. - Replacement of bulb (P.- 176 -) 6.
  • Page 15 Passenger Cabin — Small storage box (P.- 35 -) 6. Door armrest - Power winder switch (P.- 29 -) 7. Baggage cabin - Hatchback (P.- 26 -) 1. Interior rearview mirror (P.- 109 -) 4. Rear interior light (P.- 108 -) 2.
  • Page 16 Driver Cabin (Left Rudder) 1. Access hole 2. Steering wheel — Electric power steering (EPS) system (P.- 80 -) 3. Klaxon button (P.- 105 -) 4. Cigarette lighter (P.- 34 -) 5. Knob electronic gear shift mechanism (P.- 78 -） 6.
  • Page 17 Instrument Panel (Left Hand Drive) 1. ABS (P.- 88 -) 2. Adjusting switch of headlight height (P.- 101 -) 3. Central defrosting outlet (P.- 119 - ) 4. Central air outlet (P.- 88 -) 5. Alarm switch (P.- 105 -) 6.
  • Page 18 Integrated Instrument 1. Motor tachometer (P.- 89 -) 2. Left and right turn signal lights (P.- 89 -) 3. Function indicator (P.- 89 -) 4. Liquid crystal display (LCD) (P.- 90 -) 5. Speedometer (P.- 89 -)

  • Page 19: Motor Compartment

    Motor Compartment 1. PTC circulating tank assembly 2. Battery compensation tank assembly 3. Water tank and motor of washer 4. Water tank assembly and accessories 5. On-board charger assembly 6. Motor controller assembly 7. Front cabin harness assembly 8. Battery...

  • Page 20: Open & Close

    Open and Close The car is equipped with two keys. Please keep one key at a safe place as a spare key. The key can operate: ① start switch; ② front door lock; ③ hatchback lock; ④ window glass; ⑤ hatchback switch Only when you used the key correctly, can you start the car.
  • Page 21 Remote Key 1. Remote locking button 2. Remote unlocking button 3. Car locating button Warnings ● Keep your remote key away from saline water which may damage transmitter chip and accordingly result in system failure. Don’t fall down the remote key. ●...

  • Page 22: Door Lock

    ● Don’t place the remote key together with the device that produces a magnetic field, such as TV, audio device and personal computer. ● Where the remote key is insufficient of power, the start-stop function cannot be used for starting the car. Then, please conduct as per instrument instructions, and keep the remote key closer to the start-stop switch to start the car.
  • Page 23 Lock / Unlock Door with Remote Key 1. Locking button 2. Unlocking button 3. Car locating button When locking the door outside the car, close five doors (including hatchback), and press down the button “ ”, to lock such five doors. Before opening door, press button “...
  • Page 24 Warning Pull handle with your hand after closing door with remote key to ensure that the door is fully closed to avoid property loss. Operating Range: The remote key takes effect only when it is within the specific distance to the car. When the battery in remote key runs out or there is strong radio wave around, the effective distance of remote key will be shorter and even that the remote key is invalid.
  • Page 25 light will flash for two times. Defense Prompt If you don’t lock the doors within 10s after flaming out the car and closing all doors, the steering lights will flash three times (subject to door locking rather than anti-theft setting). Central Control Function (1) Insert key and turn the lock cylinder of front passenger door, or operate the central door lock and unlocking button on the switch of front left lifter, the locking device of five doors (including hatchback) unlocks normally.
  • Page 26 stop button is set at “ON”, all doors will be closed automatically. Crash-related Unlocking Function In case of crash, SRS ECU outputs signal to central control lock controller, and then such controller automatically controls all doors hatchback unlocking. Anti-theft Function 1.
  • Page 27 Warning Central control door lock is installed on the front passenger door. Don’t leave your key in car when locking doors with central control door lock. Rear Door Lock When locking the door, close the door slightly and press the lock button forward to lock the door; and when opening the door, first pull back the lock button to unlock the door, and then pull up the handle to open the door.
  • Page 28 Rear Door Child Lock Lock catch of child safety seat Unlocking Locking When using the child lock, pull its lock knob toward right to deactivate the inward opening handle, and the doors can only be opened outside the car. Pull the lock knob toward left to release the child lock. Warning If there is a child on rear row seats, do use the child lock to avoid accident caused by child due to opening door during driving process.
  • Page 29 Hatchback Lock Firstly, press down key unlocking button “ ”, to release defense status. When you are in car, operate the central control unlocking button on the lifter of front passenger door. And then, press the hatchback micro switch within 30s to unlock it. After 30s or pressing down remote control locking button, press hatchback micro switch, the hatchback will not be locked.
  • Page 30 ● Firstly use the hatchback micro switch and then pull the hatchback till that it is fully opened. When closing the hatchback, press down the hatchback till that it is fully closed. Warning Check if the hatchback is locked before driving to ensure driving safety. Check if the hatchback is closed before leaving the car to avoid property theft.
  • Page 31 Lift the motor cover ② by hand, then attach the movable end of the pole to the sheet metal mounting hole to lift the motor cover ③. If it is a high-configuration gas spring pole ④, we only need to operate the above step 1, and then gently lift the motor cover to lift it. Motor Cover Closing Slowly move the motor cover downward to the locking position.
  • Page 32 Windows Power Windows Warnings ● Don’t leave children or other incapable adults in car alone. Because they may unintentionally touch the switch and controlling devices, and accordingly cause accidents. When using the windows electric power switch, you may hurt others, especially children's hands, head or other parts. ●...
  • Page 33 Driver Seat Power Window Switch: Switch ①: Switch of central lock; when the doors are closed, touch the button, four doors will be opened. Switch ②: Front passenger door glass lifter switch The driver door glass windows are equipped with one-button decreasing function. If you click the switch, the glass will lower down, and if you release the switch, it will stop working.
  • Page 34 The right front door, left rear door and right rear door are equipped with independent glass lifter switch. If you touch the switch when you do not touch the left front door glass lifter locking switch, the glass will be lower, and if you release it, the glass will stop lowering;...
  • Page 35 ① The glass lifter suffers from power failure for 24s during operation; ② The diagnostic apparatus turns off the anti-pinch function; ③ The windows position exceeds the scope of the initial learning position; ④ The system losses power over 15s under the un-sleeping state or over 600s under sleep state; ⑤...
  • Page 36 Button 4 controls the curtain of panoramic sunroof. If you touch it ≥250ms, it starts manual mode; and if you touch it ＜250ms, it starts automatic mode. Button 5 controls the curtain of panoramic sunroof. If you touch it ≥250ms, it starts manual mode; and if you touch it ＜250ms, it starts automatic mode.
  • Page 37 Warning The power of electrical devices shall not be more than 120W to avoid damaging fuse. Cigarette Lighter Touch cigarette lighter button, the cigarette lighter’s resistance wire will be red and hot, and will go back to original position about 18s later. And then, you can use it. The cigarette lighter has an indicator which will be on when you turn on the side marker light.
  • Page 38 In addition, when you remove the cigarette lighter, you can use it as vehicle-mounted DC 12V power. Warning After using the cigarette lighter, please place it back in time, to avoid burning other objects in car or causing fire. Storage Device Warning To focus on driving, don’t use storage device.
  • Page 39 Middle Cover Cup Holder and Storage Box If your car has EPB, its control box has one cup holder and one open storage box and one concealed storage box for storing some small articles. Such storage box can contain some small articles. - 36 -...
  • Page 40 Storage Box To open storage box, pull the storage box cover pull ring upwardly. If you are to close the storage box, pull the storage box cover pull ring downwardly. If you are to open the tools box, pull the storage box cover pull ring to a higher level. Shelves Shelves are placed above the storage box and behind the rear seats.
  • Page 41 Bottle Holder and Map Bag The bottle holders are located at the interior fender apron of four doors. - 38 -...
  • Page 42 Seat and Supplemental Restraint System (SRS) - 39 -...
  • Page 43 Seat the property position. (See details in Chapter “Seat Belt”) Warning When adjusting the seat position, don’t touch any parts to avoid any potential injury or damage. Front Seat Warning Don’t adjust the seats on the driver's side during driving process, which will divert case of accident.
  • Page 44 Front Seat - Front Passenger Seat (4- Front Seat - Front Passenger Seat (4- Front Seat - Driver Seat (6-direction direction Electric Operation) direction Electric Operation) Locking- release Electric Operation) button headrest Locking-release adjustment Locking- button for headrest release adjustment button headrest adjustment...
  • Page 45 electrical adjusting button outside the while pressing the locking-release button, seat and release it when adjusting the seat and release the button to lock it. to the proper angle; manual adjustment: When adjusting the headrest, keep the upwardly rotate the handle and release it center of headrest and the upper part of when adjusting the seat to the proper ear in a line as far as possible.
  • Page 46 folding the 2nd row seat. ● When returning to the original seat position, please confirm that the ● When the seat is folding, prevent seat is secured at the locking anyone from sitting in the baggage position. If the seat is not fully area or on the 2nd row seat.
  • Page 47 vertical after unlocking Backrest Right Split Seat (Rear Seat) tilting handle adjustment angle of middle-row seat, which is the normal use status of backrest. Backrest Seat cushion Adjustment of Headrest Height Use the method the same as that of front seat. Removal of Headrest Folding Seat Rear seat backrest cannot be adjusted,...
  • Page 48 The interior width of the passenger compartment of the front seat is greater than or equal to 1200mm, and the seat cushion width and seat cushion depth of each front seat passenger is greater than or equal to 400mm, and it is approved to carry 2 passengers.
  • Page 49 Rear Seat: The distance between the back seat and the front seat is more than 600mm, the seat cushion depth is more than 400mm, the length is 1305mm, and it is approved to carry 3 passengers. - 42 -...
  • Page 50 Headrest Warning Don't use the car when the headrest is dismantled, because it is dangerous. The correct use of headrest can effectively reduce injury in case of accidents. Others shall timely check the headrest height after using it. The correct method to adjust headrest is as shown in figure: - 43 -...
  • Page 51 Locking-release button for headrest adjustment Seat Belt Notes for Seat Belt: If you correctly tie and adjust the seat Adjustment of Headrest Height belt, sit straightly and lean back on the Adjust the headrest to the proper position backrest, it is less possible for you to while pressing the locking-release button, get hurt in case of accident, and the and release the button to lock it.
  • Page 52 be more than the quantity of seat belts. shoulders and chest. The seat belt shall Warning ● Don’t use the seat belt reversely. keep away from face and neck, and it ● The seat belt is designed according Don’t twist the woven tape of seat cannot fall down from shoulder.
  • Page 53 The seat belt protection is proper or not is based specification. and its retractor must be replace on their body size. together. Please get in contact with the service stations authorized by DFSK Older Child - 46 -...
  • Page 54 When the The backrest shall not be excessively seat belt does not get close to the face DFSK recommends the wounded to slant for own comfort. The seat belt can and neck of the child, and the child can use seat belt.
  • Page 55 If the retractor cannot works when you use the aforesaid inspection methods, please consult service stations authorized by DFSK Warning The backrest shall not be slant downwardly but stay at the pleasant position.
  • Page 56 Child Safety Seat Remember: the child safety seat left in the closed driver cabin may get very hot. Before placing child on the child safety seat, please check temperature of the seat surface and its lock catch. ● DFSKrecommends that the infant should sit in the child safety seat.
  • Page 57 is safer for child to sit on the rear specification of child safety seat. ● Where the child safety seat is not seat than on the front seat. ● You should adjust the backrest of used, please secure it with the ●...
  • Page 58 General Child Restraint System for All Seats When choosing any child safety seat, pay attention to the following: ● Comply with the latest GB 27887- 2011; ● Enable you child to sit in the child safety seat and check all adjustable parts to ensure that it is suitable for your child.
  • Page 59 Specified Position of Child Safety Seat Seat position Rear-row Right split Rear-row Front Front left split Age group seat (rear left split passenger seat passenger seat outboard (with SRS) (without SRS) seat) middle seat seat 0, 0+ Group <13kg × L*, I* ×...
  • Page 60 Adaptive Information of Different ISOFIX Positions for ISOFIX Child Restraint System ISOFIX position in car Front Rear- Rear-row Mass group Size category Fixing module passe Other outboard nger middl positions seat seat e seat ISO/L1 Portable bed ISO/L2 ISO/R1 Group 0: ﹤10kg ISO/R1 ISO/R2 Group 0+: ﹤13kg...
  • Page 61 Group II: 15kg-25kg Group III: 22kg-36kg Note: (1): With respect to child restraint system not meeting the size category of ISO/XX (A-G), for the suitable mass group, the vehicle manufacturer shall specify the recommended special ISOFIX child restraint system for each position. IUF: suitable for forward-facing general ISOFIX child restraint system approved by the mass group.

  • Page 62: Isofix

    Anchor point of ISOFIX child seat ISOFIX Child Seat Anchorage Meanwhile, use the seat belt on the car anchorage is located at the back of the Your car is equipped with special to secure the child seat. Check if the cushion close to the backrest.
  • Page 63 can only be installed at the special lower anchor point to confirm if row seat outboard seat. position. With respect to the there is any obstacle including belt Lock catch of left split forward-facing installation position of lower part or cushion material. If any, the child seat of child safety seat, see “ISOFIX child safety seat cannot be secure...
  • Page 64 Lock catch child Lock catch Lock catch of safety seat child child safety safety seat seat Lock catch of right split backward- Lock catch of right split forward-facing facing child seat child seat...
  • Page 65 2. Secure to the special lower anchor it closely lean against the backrest and cushion. point ② with the connector of child 5. Check the child safety seat before safety seat; placing child onto it. Shake it to ensure 3. Keep the backrest of child safety seat the child safety seat is secured properly.
  • Page 66 the child safety seat is secured properly. 5. Secure the child safety seat with seat ③ belt of the car. 6. Check if the child safety seat is ④ secured properly before using. If the child safety seat is flexible please reinstall it as per the step 3.
  • Page 67 2. Let the seat belt spring bolt go across Backward-facing: your knees to press down ③ and Confirm that you are correctly using the child safety seat, and insert to the backwardly ④ the middle of child the child safety seat as per the product lock catch ②...
  • Page 68 safety seat to keep it closely lean against the backrest and cushion. Installing on Front seat 2. Let the seat belt spring bolt go across the child safety seat, and insert to the lock catch ② until feel and hear the 5.
  • Page 69 be backward-facing; and if the following steps: Warnings front passenger seat is equipped ● If the front passenger seat is with effective SRS, don’t install equipped with SRS, don’t install the child safety seat. the rearward-facing child safety seat. The SRS explosion will cause great impact.
  • Page 70 placing child onto it. Shake it to ensure ⑥ the child safety seat is secured properly. Supplemental Restraint System (SRS) 5. To avoid the loose seat belt, use the Notes of SRS locking device of the child safety seat to This chapter will...
  • Page 71 helpful for buffering the impact on SRS will quickly be flat after driver and front passenger’s (optional) expansion. head or chest. SRS warning light will be on when the SRS is designed for providing auxiliary brake is stepped down and the motor protection for driver and front passenger start-stop button is set at “ON”, and it in case of crash instead of replacing the...
  • Page 72 degree in case of any accidents. ● When you sit on the seat and the !arnings backrest is upright, the seat belt and auxiliary pre-crash SRS ● When system can play the best role. car meets side There is a great impact when the impact, rear SRS is exploded.
  • Page 73 If there is no proper protection for Don’t install the backward- ● ● Warnings child, when the auxiliary pre- facing child safety seat on the Don’t let child to sit freely or ● crash SRS system is exploded, the front seat, because the exploded stretch head or hands out of child may get serious hurt and SRS will seriously hurt the child...
  • Page 74 Warnings Using the seat belt is helpful for ● reducing the injury or injury degree in case of any accidents. When you sit on the seat and the backrest is upright, the seat belt can play the best role. There is a great impact when the SRS is exploded.
  • Page 75 SRS Air Bag please refer to Chapter “Child Safety The warning sign (optional) is on the Seat”. surface of visor on the front passenger SRS Warning Light seat. SRS warning light in instrument is Front Front Passenger Seat & Side SRS shown as , and it supervises the for Front Seats...
  • Page 76 the auxiliary SRS is exploded, front seat). SRS system requires repairing in and accordingly result personal either case as follows: injury. ● Once the SRS is exploded, some SRS warning light is still on after ● sub-assemblies of it will be hot, so don’t touch them, or you may get hurt.
  • Page 77 Operation on or around the SRS ● Auxiliary Pre-crash SRS system must be done by service Warnings System stations authorized by DFSK ● Once the SRS is exploded, the Don’t change or disconnect the SRS module cannot work again, The auxiliary pre-crash SRS at driver...
  • Page 78 DFSK The correct procedure for you to give out is as shown in DFSK Service Manual, wrong procedure may cause personal injury. The SRS and pre-crash seat belt are designed for disposable use. After the SRS is exploded, it is an alarm that the SRS warning light will be on if it is not damaged.
  • Page 79 Drive and Handle System - 72 -...
  • Page 80 over-temperature indicator of motor. When leave your vehicle unattended. Vehicle Starting the indicator is off for more than 5 minutes, Notes for starting and driving ● Use parking brake. perform the next operation. Warnings ● Step on the brake pedal. Set the vehicle at “D”...
  • Page 81 It is very important to drive as per Driving in Winter driver can press the start-stop button to ● Ensure safe driving. environment and conditions for driving unlock it. No sudden starting, speeding up and ● safety and comfort. A driver has to know Warning braking.
  • Page 82 dynamic performance pleasant reducing steering power That for hatchback opening is about sensation for you. accelerating steering response. This mode 1.2m away from the hatchback opening Switching Method turns off the automatic start-stop function. button. When you press Drive Mode button, the Eco: the mode changes vehicle properties, Passive Entry Function drive mode will switch among Eco, Normal...
  • Page 83 be locked via passive button: off the motor. Then the power is set at Vehicle Start-stop Function When the intelligent key is within the The power is not set at “LOCK”; “OFF”. activated area of start-stop system, press the The intelligent key is left in car; or In emergency case, press the start- start-stop button to start and stop the motor A door or hatchback is not closed.
  • Page 84 “Vehicle Starting”. Before Motor Starting Vehicle Driving Step on the brake pedal and shift the Warnings shifting knob to “D” gear. Warning Your car's driving characteristics may be Slowly step on the accelerator pedal, ● Don’t suddenly lower gear on wet and greatly changed due to additional load, load and release the clutch pedal and electric slippery road, or will cause the vehicle to be...
  • Page 85 ● Fasten the seat belt, and ask all Gear Shifting passengers to do so. When you set the shifting knob at “D” gear, ● Ensure that all doors are closed. the wheels will be controlled and shifted ● Set motor start-stop button is set at gear as per accelerator opening and speed.
  • Page 86 For you to pull the electrical parking switch, Notes for Operation this, DFSK will not provide warranty and shift shifting knob to proper gear, or regardless of that it is within the warranty ● Don’t tow the car during run-in period.
  • Page 87 (including tow hook, safety chain and regulations. Meanwhile, check and ensure ● In towing, please note the temperature others). You may consult DFSK dealer for other towing devices meet the local laws indicator of motor coolant, to avoid purchasing such devices and more notes for and regulations.
  • Page 88 (EPS) system. friction face may be rusty due to being out send your car to DFSK dealers for If turning the steering wheel so fast, you of service for a long time or rainy day. If the inspection and repair.
  • Page 89 providing friction for car brake. If it have to increase power to step on it to park overheating will reduce brake performance, exceeds the use limit of brake friction pair, your car, and the brake distance will be and cause vehicle to be out of control. the brake will be out of service, and even longer too.
  • Page 90 step on the accelerator pedal gradually, so brake distance is longer than that on ABS controls brake, preventing wheels that the vehicle will release the electronic slippery road although your car has an ABS. from locking in case of sudden brake or parking device after perceiving the driver's When you use tire chain on coarse, gravel driving on slippery road.
  • Page 91 It is normal, and the ABS brake warning light on integrated diagnosis or driving, please drive your car indicates that ABS works normally. instrument. Then, the brake system will to the service stations authorized by DFSK - 84 -...
  • Page 92 for inspection. see it. At night, park at a bright place. ● Please keep longer brake distance ● If your car is equipped with safety when driving in cold weather. The Warning system, use it, even though you only use it opportunity for braking shall be prior to If both ABS / EBD fault indicators are on in for a moment.
  • Page 93 before using car. Refer to “Replacement of The anti-skid performance of rubber remove snow and ice on windows and wiper. Vehicle Coolant” in “IX. Maintenance and studded tire on wet or dry roads may be You can place the hard board under What You Can Do”.
  • Page 94 Driver Cabin Maintenance”. Other rust-proof and anti-corrosion actions may be prohibited in some areas, so please consult the local DFSK dealers. 1. Access hole 2. Steering wheel 3. Klaxon button 4. Cigarette lighter 5. Knob electronic gear shift mechanism 6. EPB switch 7.
  • Page 95 1. Adjusting switch of power rearview Instrument Panel mirror 2. Adjusting switch of headlight height 3. Display screen 4. Alarm switch 5. Central air outlet 6. Front defrosting outlet 7. Side air outlet 8. Side defrosting outlet 9. Tool box 10.
  • Page 96 Integrated Instrument Speedometer Instantaneous Power Meter Real-time display of vehicle power (KW) Voltameter Voltameter The accuracy of the display bar for the battery power of the instrument is 1%, and Integrated instrument Speedometer the range of display power is 0-100% with Speedometer pointer indicates the driving speed (km/h).
  • Page 97 c) On the interface of classic theme and Battery Thermometer Operation science theme, press the up and down keys on the left side of the multi-functional steering wheel to switch to the secondary interface; on the interface of passion theme, press the right button on the left side of the multi-functional steering wheel, move the Battery Thermometer...
  • Page 98 Tire Pressure Display: prompts that the current vehicle deviates Multimedia from the lane line. Displays the current pressure of four tires Phone Fault Description Driving computer screen Displays the fault description of the current ECU shows the following information. vehicle Average power consumption:...
  • Page 99 Fatigue driving setting: includes the entertainment host. fatigue driving time (2h, 3h, 4h) or turns off * Phone the fatigue driving prompts. Displays the Bluetooth telephone contact * Unit setting: includes the unit of Note: information from entertainment host. temperature, pressure and mileage. The instrument displays many interfaces, * Outside Temperature * Maintenance setting: includes...
  • Page 100 Operating indicator of brake vacuum * Autohold indicator controller * EPB fault indicator * ESP OFF indicator Indicator and Voice Prompt * ESP failure alarm indicator * Cruise control indicator Turn signal / danger indicator ECO mode indicator Power limit indicator Driver seat belt indicator SPORT mode indicator SRS alarm indicator...
  • Page 101 Please contact the service danger. tank, please add brake liquid as required stations authorized by DFSK for inspection. ● Braking when the drive motor is off (refer to “Brake Liquid” in “9. Maintenance...
  • Page 102 Note: when the front passenger seat belt is treating the power steering system from the not fastened, the indicator is constantly on service stations authorized by DFSK. Driver seat belt indicator when the speed is＜10km/h, and it is off - 95 -...
  • Page 103 (Refer to “Electric Please do slow down to park and contact the hereinafter) Power Steering (EPS) System” in “6. service stations authorized by DFSK at Side marker light / position indicator Starting and Driving”) once for inspection. (Refer to “Parking When you turn on the side marker light, the Brake”...
  • Page 104 It is on when the signal state is "Fault", and off when the signal state is "No Fault". due to safety logic. Please contact DFSK The warning light is on when the power is off when the signal state is "No Fault".
  • Page 105 DFSK after-sales service center or light is on, it indicates that the battery is alarm sound reminding you of turning off the designated 4S store for repair.
  • Page 106 motor start-stop button is set at “ON” of the driver. The switch icon is shown different frequencies according to the below. When the vehicle is started again, (whether the motor is started or not) and the differences from the reverse radar to the system will be turned on by default.
  • Page 107 in the direction of handle vertical to turned off, it is unable to alert pedestrians steering wheel. When you slightly pull and vehicles to approach, which will reduce the light switch to overtake gear, the the safety of the vehicle. high beam headlight and low beam Integrated Switch of Light headlight will be on, realizing overtake...
  • Page 108 turn indicator flashes for 5 times at a delays 30s to be off; if you turn the your driving habit. The greater the certain frequency, and the switch overtake switch for 3 times within 2s, number on switch is, the lower the returns automatically.
  • Page 109 Don’t use the washing liquid over 30s work at a low speed. continuously. If you are to stop the wiper, set the lifting lever downwardly to “OFF” gear. If there is no washing liquid in washer If you set the lifting lever at “MIST” storage, don’t use washer.
  • Page 110 windscreen (nominal quantity), the at “ ”, the wiper motor and automatic wiper command is given; washer motor will work together. and if there is no water vapor (the If the wiper suspends working due to nominal quantity), the automatic wiper snow or ice, the wiper will not work to command is not given.
  • Page 111 Cruise Setting 4. Step on brake pedal to the speed goal, Defrosting Switch Setting the gear at D, keeping speed press down the setting button to set the over 40km/h, pressing down the cruise current speed as the speed goal. setting button, and activating the cruise Cruise Releasing function, the cruise indicator is...
  • Page 112 After 14 minutes, press the defroster remind of other drivers. is connected to steering column via spline, turn steering wheel to driver switch again, to turn off defroster. When you press the warning light steering column so as to control vehicle switch, all turn signal lights flash.
  • Page 113 Bluetooth (circulating); Ash pan Bill Fold 6. Under the status connecting to You can directly see the bill fold. mobile phone Bluetooth, click the button to answer the call; Caution 7. Under the status connecting to Don’t insert the card or several bills mobile phone Bluetooth, click the button to hang up the call;...
  • Page 114 Front Reading Light it will be off after 10 minutes if you have no operation. When the five doors are closed and the motor start-stop button is used, and the central control lock is used, the light is immediately off; and when five doors all closed, the light ①...
  • Page 115 Rear interior light When it is set at OFF gear, the light trunk. When the hatchback is opened, the light is on. When the hatchback is is off. closed, the light is off. When it is set at DOOR gear, and the Door light front reading light is set at DOOR gear too, the control and front reading light...
  • Page 116 Interior Rearview Mirror Exterior Rearview Mirror Manual Control Type Warnings Adjust the angle of interior rearview mirror Don’t touch the moving exterior ● to the proper position. Remote Control Type rearview mirror to avoid clamping your fingers or damaging rearview mirror. The exterior rearview mirror is folded, ●...
  • Page 117 rearview mirror is closer than the actual distance. ● The size of and distance to objects outside the exterior rearview mirror are not true. Adjustment of Rearview Mirror Remote Control Type When the ignition switch is set at “ACC” or “ON”, the remote control and adjustment are applicable to the exterior rearview mirror.
  • Page 118 in car alone. They may unintentionally brake will be on (red) and the LED on EPB Folding and Electric Adjustable Type release parking brake, and accordingly switch will be on too. result in serious accident. Press switch ④, and adjust the shell Electric Parking Brake (EPB) When releasing parking brake, step down of rearview mirror to fold to the maximum...
  • Page 119 If you are to replace the brake pad of ● rear calipers, please get in contact with the Warning service stations authorized by DFSK Dynamic Parking Such function can be used when the ● During driving process, pull EPB switch to driving brake system is out of normal realize emergency parking.
  • Page 120 Heater and Air Conditioner (A/C) - 113 -...
  • Page 121 central display. actual distance. Safety Precautions ● It is visually opposite for the objects in Reverse Camera System the reverse camera system, and it is the Warnings When shifting to gear “R”, the reverse same to see the objects from the inside and ●...
  • Page 122 reference only, and it may be different from shock. the distance from the car to the objects ● Don’t hit the camera which is a precise shown. instrument, or it may be faulted or damaged, ● When reversing the car on slope, the and accordingly result in fire or electric distance from the car to the objects shown shock.
  • Page 123 the camera, the reverse camera system may However, when the motor is off, the brake ● When the temperature is too high or not clearly show the objects, so please clean is stepped down and the motor start-stop low, it is not a fault that the display screen the camera.
  • Page 124 1. A/C air volume control knob 2.OFF button 3. Top blowing mode → top and foot blowing mode → foot blowing mode → foot blowing mode and defrosting mode 4. Front defroster button 5. Internal and external circulation button 6. Rear defrosting and rearview mirror heating button 7.
  • Page 125 mode → foot blowing mode → foot blowing mode → top and foot blowing Operation of Heating Ventilator Heating (if equipped with auto A/C): blowing mode and defrosting mode. mode → foot blowing mode → foot When you press the automatic A/C You can control air volume by using the blowing mode and defrosting mode, and button “...
  • Page 126 Press down the internal circulation button this key, and it will not exit the defogging button “ ” (the system corresponding state, and the key state will not be remembered; “ ”. automatically starts A/C, the inlet mode is ② When the key is used, the operating Regulate the mode to face blowing external circulation, but it can be regulated indicator is on.
  • Page 127 the same, and LCD only displays ① Use the button under OFF status, Temperature Button temperature. activate the system to get the air volume The temperature available is 17-32℃. PTC Heating Button level 1. Return to the status before OFF for Clockwise rotation is for temperature +, Use the button to send the request for others (if it is AUTO before OFF, exit...
  • Page 128 The disqualified with the service stations authorized by coolant or lubricant will seriously damage DFSK the A/C system. (See details in “X. If the air flow is obviously reduced or the Technical Information”...
  • Page 129 Audio Entainment System - 122 -...
  • Page 130 provide the detailed instructions for sound 2. Under status, click Antenna system so as to be convenient for your use, carcorder APP at MP5 terminal to enter diagnosis and repairing. video interface; Precautions for Sound System 3. Click the screen on carcorder Operation interface to set parameters;...
  • Page 131 setting interface to format the memory of carcorder so as to improve user experience. 2) If recording the video of 1080P, the carcorder memory (16G) can only record for 2.5 hours. In case of accident, please record the valid video timely. Reverse Camera System - 124 -...
  • Page 132 Surround View Camera requests to display the surround view 1. The panoramic system has four within 6s after switching to IGN with wide-angle cameras around the vehicle start-stop switch, the corresponding that can cover all the field of view around the vehicle, and processes the request will not receive a timely multi-channel video images collected response.
  • Page 133 Button S/N Button Name Button Function Button 1 Homepage Button Turn off surround view camera and back to main interface Display the image information of front camera in the side-view box in the aerial Button 2 Front-view Button view. Display the image information of left camera in the side-view box in the aerial Button 3 Left-view Button view.
  • Page 134 indicates that the current view is Button 2 Button 1 front-view. Please confirm indicates that the current view is surrounding conditions rear-view. Button 3 indicates that the current view is left-view. indicates that the current view is Button 4 right-view. Button 5 Attention If the image cannot be displayed or the...
  • Page 135 Wireless Charging Function Bluetooth mode: touch (for ＜ 1.5S) to Player switch to the previous song/video; It is connected to power + and used under 3) “∨”: RADIO mode: switch to the next the "ON". Mobile phone shall have wireless ●...
  • Page 136 information inquiry. call one’s number / dial 156... / call mobile b) Sunroof raised opening Note: Do start the voice assistant before customer service” to find the phone number The term “sunroof raised opening” can voice interaction. and dial as per voice prompt. be used to make the sunroof raised Start voice assistant Review Call Records...
  • Page 137 The term “open hatchback / close hatchback” can be used to open or close the hatchback. 11 Seat a) Seat heating The term “turn on heating for all seats / turn off heating for all seats, turn on heating for driver’s seat / turn off heating for driver’s seat, turn on heating for front passenger seat / turn off heating for front passenger seat,...
  • Page 138 1. Message Center 2. USB Music 3. Picture 4. Settings 5. Music Note: As for specific operation of various functions in MP5 interface, the driver can enter "Settings" in the system interface. - 131 -...
  • Page 139 Vehicle Charging Attention In the cold weather or snow, when the charging port cover is frozen, do not force to remove it. Use hot water or other heating devices with a maximum temperature of less than 100 degrees to melt the ice before removing the charging port cover. Charging Port ②...
  • Page 140 ● When the charging plug is connected to the vehicle, the integrated instrument lights up the charging connection indicator. Meanwhile, the AC charging connection device’s power indicator flickers. During the charging process, the integrated instrument displays the relevant charging parameters and the charging animation. ●...
  • Page 141 more charging guns. The charger should be Environment Requirements programmed so that the charging gun can for Use of Charging Gun be used alternately. Charging equipment shall be located at the Choose charger controlled If any unknown foreign matter is position with rain facilities such as rain temperature sensor and which has the found in the charging gun, charging gun...
  • Page 142 Keep the charging gun facing the must be inserted with force vertically; drawing the charging gun. charging socket, press the button to unlock When charging, the charging gun Hold the charging handle with one the charging gun with your thumb evenly, cable must be straight and not twisted to hand, press the "UNLOCK"...
  • Page 143 charging pile. abandoned or dropped on the ground, the charging socket. In case of any unexpected said method should be promptly used for circumstances (the dust cover of socket is Maintenance cleaning. not closed), the said method should be promptly used for cleaning. Charging gun clearing: Charging Holder...
  • Page 144 If any abnormal smell or smoke coming from the car while charging, please Notes for Charging stop charging immediately. When the SOC indicator bar of the To avoid serious personal injury, Please charge in a relatively safe integrated instrument enters the red please note the following when charging: environment without liquid, fire and others.
  • Page 145 AC charging equipment equipped. It is restart charging without reconnecting to the charging. recommended to use 220V 50Hz 16A AC charging equipment. When the charging is stopped, the circuit and grounding socket. Special When charging, personnel are not vehicle plug should be disconnected first, recommended to stay in the vehicle.
  • Page 146 life of power battery. socket to charge the vehicle. public places. For ease of use, the integrated The socket should be the special Charge Method instrument will indicate the expected time charging socket, because the high-power Introduction to Charging of full charge. charging will lead to line damage and line When the power bar in the power display tripping protection, affecting the normal...
  • Page 147 10A single-phase bipolar grounding socket Inspection before Charging and the vehicle plug connected to AC Make sure the charging equipment is charging port. not scratched, rusted or cracked or the surface of the charging port, cable, control box, wire and plug is not damaged. Do not charge if the surface of the vehicle socket is damaged, rusted or cracked or the connection is too loose.
  • Page 148 Instant Charging Method special charging bag and place it properly; During the charging process, the The power supply is set at “OFF”. Apply the AC charging port cover and integrated instrument displays the relevant Unlock the car and remove the AC cover plate.
  • Page 149 be opened in the following ways: automatically. power system fault indicator is on the Use hot water or other heating devices with Power battery temperature is lower integrated instrument, or there is a fault a maximum temperature of less than 100 than 0℃...
  • Page 150 for charging. power consumption at "OFF” gear. Discharge outside the vehicle is that Power battery temperature is too When the front cover of the vehicle is not the vehicle discharges from the vehicle to high: when the integrated instrument shows that the power battery temperature is too closed or the instrument has oil pressure the VTOL.
  • Page 151 inside the vehicle; The indicator will be on (red) and the socket Discharge Stopping Plug the electrical device into the will discharge normally. When you unplug the electrical device, the discharge socket and wait for a few seconds. socket indicator will be off. - 144 -...
  • Page 152 Power Battery Power battery basic function description: one of the main power sources of S513 is power battery which can be repeatedly charged and discharged. The main ways to charge the power battery through external power supply are household single-phase AC charging and single- phase AC charging by charging pile.
  • Page 153 Do not drive into deep water to avoid electric leakage and short circuit. When the vehicle is immersed in water, do not continue driving but immediately power off and get out of the vehicle. When driving on poor road conditions, the height of the vehicle to the ground should be taken into account to avoid the battery pack being squeezed.
  • Page 154 Low-voltage Battery Notes for Using Low-voltage Battery In "ON" mode, do not turn on the electrical devices for a long time. Intelligent charging mode is added in the design of the vehicle, that is, when the low voltage battery is detected, the low voltage battery can be charged by the power battery if the safety conditions are satisfied so as to ensure that the low voltage battery will not lose power for a period of time.
  • Page 155 Roadside Assistance - 148 -...
  • Page 156 Use the triangle warning board as per the Attentions Tools provisions of laws and regulations. ● Completely screw back thread of jack Reflective Vest before placing into the tool box again. Get The reflective vest is placed in the storage Triangle warning the crank closed against the side of jack.
  • Page 157 parking switch. 8. Ask all passengers to leave from ● Ensure that the shifting knob is the car, stand at a safe place to keep Spare Tire adjusted to a proper gear (“P” gear, away from passing-by vehicles. rather than “D” or “R” gear). Seek for assistance from professionals.
  • Page 158 Vehicle Jacking ① Warnings ② Tire Retaining Warning Ensure to retain the wheels properly to avoid moving and getting persons injured. which is not a supporting point. ● Please read through and abide As shown as follows, when tire ② is flat, by the operation instructions herein.
  • Page 159 avoid injury. ● Read through the notes before Spare Tire Installation using the jack. Place the jack under the point as Warnings shown in figure, so as to enable jack's top to ● Don’t use the not original wheel nut, Jack contact the vehicle.
  • Page 160 120)N m accident sudden parking, ⑤) for at least two times, until that the nuts Tightening torque of aluminum wheel nut: accordingly result in danger. are fully screwed up. Properly keep the damaged tires, jack (100～130)N m and used tools at the storage area. (See Keep the wheel nut at the specified details section...
  • Page 161 I, to release steam. status of cooling fan. insufficient power of motor or any Please check / repair your car at DFSK Visually check if there is any abnormal sound, please take the following franchise store.
  • Page 162 DFSK recommends to use push trolley or Warnings flatbed trailer for towing as shown in by DFSK to ask the service operator to tow figure. ● The driving wheel (front wheel) of the your car. Before preparing towing, the...
  • Page 163 When the car cannot get out of the sand, snow or slough, use the tow hook. The front trailer hook is placed in the trunk and should be installed in the designated Warnings position on the front right of the front Remove the front hook cap after pressing Keep anybody away from the ●...
  • Page 164 Maintenance - 157 -...
  • Page 165 car body, or there will have water spots on avoid corrosion by sea breeze; Exterior Cleaning surface. ● When the car surface is contaminated It is important to take correct measures to ● Don’t use close-knit flannelette or by smoke, bird droppings, metal particle or coarse cloth, such as car washing gloves.
  • Page 166 Glass ● DFSK recommends to wax wheel in After waxing, you are recommended to Use glass cleaner to remove the smoke dust winter if you are to drive on road with salt.
  • Page 167 regularly removed. Don’t use leather seats with dust collector or banister brush. Warnings washing soap, vehicle wax, polishing agent, Use clean soft cloth soaked with soft soap- Please follow the following instructions to oil, cleaning liquid or solution, detergent or suds to wipe plastic parts and leather avoid wheel pollution and fading.
  • Page 168 Protection against Corrosion Temperature Warning Primary Causes for Vehicle The increasing temperature will speed up When cleaning inside of window, don’t use Corrosion the corrosion rate of parts at the location sharp tools, grinding detergent or the ● The wet dirt and debris accumulate on with improper ventilation.
  • Page 169 ● Check if there is sand, dust or salt required by some areas, please consult the accumulated on underbody. If there is any service stations authorized by DFSK sand, dust or salt, wash with water as soon as possible. Warnings ●...
  • Page 170 Notes for Maintenance When your car is under any inspection or maintenance, be carefully to avoid any serious injury or vehicle damage. The following are the general notes which should be abided by. Warnings ● Park your car on flat ground to ensure to stop wheel with parking brake so as to avoid vehicle movement. ●...
  • Page 171 ● r swatch and others before inspecting your car. ● Where the car is only supported by a jack, don’t get into underbody. If you have to work under the car body, support your car with a scaffold. ● Ensure to keep fuming objects, flame and spark away from battery. ●...
  • Page 172 If you are unfamiliar with a maintenance item, please go to the service stations authorized by DFSK Inspection of position in motor cabin 1. PTC circulating tank assembly 2. Battery compensation tank assembly 3.
  • Page 173 ● In extremely cold weather, when the Replacement of Antifreeze true tank of DFSK or replace it with the In order to avoid the poor heating or cooling battery pack temperature adjusting system equivalent product as necessary.
  • Page 174 0℃ around the year). When supplementing or replacing coolant, recommended to refill at the service center Motor Cooling System use the DFSK motor coolant or the products authorized by DFSK. Please use the special Warnings battery antifreeze for DFSK.
  • Page 175 “MIN’, please add coolant to scald you seriously. tank of DFSK or replace it with the the level between “MAX” and “MIN”. ● Keep your skin away from motor equivalent product as necessary.
  • Page 176 30s, and keep the pedal height normal position, please consult the service status remained. stations authorized by DFSK and ask for If such distance is outside the following 4． Turn on the power supply of the inspecting brake system.
  • Page 177 DFSK ● Only use the new brake liquid taken out from the sealed container. The used, poor or polluted brake liquid may damage the brake and clutch systems. The wrong brake liquid will damage brake system and impact the brake capacity of car.
  • Page 178 windscreen water jet. If the nozzle is down the wiper rubber. placed at the place inaccessible to children. blocked, get it through with needle or small Regularly check the washer fluid capacity Take down the wiper rubber. nail ②, and avoid damaging the nozzle. in washer.
  • Page 179 Electronic Plate Installation ● The improper treatment of battery may Instructions pollute environment, so please abide by the Take down the front windscreen mirror seat local laws and regulations about battery trimming II, paste the electronic plate onto treatment. the windscreen, and finally install the front ●...
  • Page 180 If you need help, please ask for after-sales please check if the fuse is broken. service from DFSK If any electric appliances are out of normal ① ③ service, please check if the fuse is broken. Fuse Box Ensure that you turn off the power of the vehicle.
  • Page 181 1; in case of any broken fuse, please replace it with the one of the same model. Check and replace the fuse at the repair station authorized by DFSK - 174 -...
  • Page 182 Lights 1. Front reading light assembly 8. Rear fog light of rear bumper 15. Integrated headlight 2. Door light assembly 9. Rear bumper’s rear steering light 16. Integrated front position light 3. Rear interior light assembly 10. Rear reversing light of rear bumper 17.
  • Page 183 1. Rear position light switch of light for the methods of turning on sales service from DFSK 2. Steering light or off position light, low beam headlight, 3. Rear fog light Note 4.
  • Page 184 or off license plate light. 2×12.15 (LED) License Plate Light 2×5 Interior Light Integrated beam 2×55 (bulb) Item Watt (W) Note headlight 2×12.15 (LED) When the hatchback is open, the rear fog Rear interior light 2×5 (bulb) Integrated front steering 2×21 (bulb) light will have steering light, position light Door Light...
  • Page 185 Tire and Wheel Tire Type Warning If the tire is flat, refer to “Flat Tire” in “7. If the lights are accessible to water Caution Emergency Measures”. When replacing with the new tire, confirm leakage, please seek for overhauling from the Tire Inflation Pressure that all tires are of the same type (that is: DFSKafter-sales service center to avoid...
  • Page 186 DFSK recommends performances of rubber studded tire on wet Install the tire chain onto the driving wheel. Don’t install tire chain onto the car running you to four snow tires. or dry roads may be poor than that of tire on the snow-free or good roads.
  • Page 187 store. Warnings ① ② Tire Life ● After tire exchange, please adjust tire The tire which has been used over 5 years pressure. shall not be used regardless of its status. ● After tire exchange, adjust tire Tires will be aging as the times goes and it pressure and screw up wheel nut again after is used.
  • Page 188 refer to technical information in Chapter same offset distance regardless of the regularly. When conducting dynamic “Tire and Wheel”.) The use of tires which replacement for any reasons. The tires of balance test, remove the wheels from are not the recommended ones or those of different offset distances will be early worn.
  • Page 189 - 182 -...
  • Page 190 - 183 -...
  • Page 191 - 184 -...
  • Page 192 Recommended Lubricating Oil and Capacity The following table shows the theoretical capacity which may be slightly different from the actual one. So, refer to the refueling standard as mentioned in this chapter. Specification Refueling capacity Item TZ230XSIN107 — Gearbox gear oil 75W-90·GL-4 (2.2±0.1)L FD-20 (general)
  • Page 193 FD-40 (extremely cold areas) You are recommended to use the DFSK original motor coolant to avoid corroding the aluminum metal in the motor cooling system. Note: If the transmission is damaged due to the use of not original motor coolant, it is not guaranteed, even if it is faulted within the warranty period.
  • Page 194 Recommended A/C Refrigerating Fluid and Lubricant DFSKA/C system must be filled with R134a refrigerating fluid and DFSK lubricant or equivalent. Any other refrigerating fluid or lubricant may cause serious damage and even the case the whole A/C system should be replaced.
  • Page 195 Tire and Wheel Standard 225/60 R17 225/55 R18 Tire size Spare Tire T165/80 *17 225/55 R18 Tire specification 225/60 R17 or 225/55 R18 Tire pressure (cold Front wheel 230 (no load)/230 (full load) state) (kPa) Rear Wheel 230 (no load)/230 (full load) T-shaped spare tire 420kPa Type...
  • Page 196 Wheel Position Toe-in of front wheel (one-sided) 0±0.2° Front-wheel camber (one-sided) -0.5°±0.5° Kingpin inclination angle 14.4°±0.5° Kingpin caster angle 3.4°±0.5° Rear-wheel camber (one-sided) -1.0°±0.5° Front toe-in of rear wheel (one-sided) 0～0.4° Vehicle's Main Technical Parameters Item Parameter Motor model TZ230XSIN107 Rated power (kw) Maximum authorized total mass 2130...
  • Page 197 Axle load distributed under unladen mass (front / rear axle) 955×800 (kg) Overall dimension (length × 4385×1850×1650 width × height) (mm) Wheel tread (front / rear) (mm) 1580×1582 Front suspension / rear 925×820 Size suspension (mm) 917×813 parameter 2640 Wheelbase (mm) 2655 Approach angle / departure No load: 20.0/28.0...
  • Page 198 Speed-up time ≤10.00 (0～100km/h） Steep slope Gradient (%) ≥35.00 performance Economic NEDC (km） ≥300 efficiency Driver type Front-motor front-wheel-drive layout - 191 -...
  • Page 199 Traveling or registration abroad Vehicle Identification Sign If traveling to other countries or districts, please firstly confirm Vehicle Identification Label (Nameplate) where you can charge your car. Vehicle nameplate is fixed below the Column B on the right side. If you have to register for your car in other countries, states, province or districts, go to the authority to confirm if your car meets the local laws and regulations.
  • Page 200 Position of Vehicle Identification Number (VIN) The vehicle identification number plate is the legal sign. Vehicle Identification Number (VIN) It is located below the front passenger seat as shown below: 2. Rear floor, see the following picture: - 193 -...
  • Page 201 - 194 -...
  • Page 202 Motor No. It is printed on motor as shown as the following arrow: - 195 -...
  • Page 203 VCU Sign - 196 -...
  • Page 204 Tire Pressure Label The pressure of cold state tire is shown on the tire pressure label on the middle upright of driver side. - 197 -...
  • Page 205 Electric Identification (Microwave Window) Microwave Window The position of the microwave window is shown in the figure above; and the installation of the electronic identification should meet the requirements of GB/T 35790.1-2017. - 198 -...
  • Page 206 All the file information, DFSK(including SERES) Patent rights and other intellectual rights belong to DFSK or SERES NEV Sales Company or its authorized enterprise. Without any written authorization or written permit by SERES or DFSK nobody has right to copy or edit. SERES brand is registered in USA or other countries as follow: SERES NEV Sales Co., Ltd...

This manual is also suitable for:

Glory e3
