Summary of Contents for Capetti Elettronica WineCapKey WSD12T-EX Series
- Page 1 WSD12T-EXn User Manual Strain gauge and/or Load cell/Temperature...
-
Page 2: General Warnings
WSD12T-EXn User Manual General warnings. • The following information must be read and understood before proceeding with the installation, commissioning and maintenance of the devices described in this document. • ATTENTION! Any omission or failure to follow these instructions scrupulously can cause danger. •... - Page 3 WSD12T-EXn User Manual 1. Description WSD12T-EXn is a datalogger with 4 input channels to acquire, strain gauges/load cells inputs and outdoor temperature value, with storage functionality of samples acquired. 2. Order code nomenclature. • 1 CH temperature WSD12T-EX1 • 120Ω – 4,950µV/V - ½ bridge 3 CH full scale strain gauge - 2.5µV/V resolution •...
- Page 4 WSD12T-EXn User Manual 3. Device pre-set and use mode. a. Wireless Mode: In this use mode, the datalogger records and transmits each measure sampled to the linked gateway. Typically, the monitoring system is refer to Picture 4 - Status table – configured in factory, so, if the device is already associated to the system gateway is in STANDBY mode ( Wireless mode refer to...
-
Page 5: Device Enrolment
WSD12T-EXn User Manual The following COMMAND table describes the available commands: WIRELESS DEVICES USER INTERFACE Flash count Command Description Shows the device STATUS. As answer the led perform a flash sequence as 1 flash refer to STATUS reported in the STATUS table. If the device is performing the TEST ( TEST command ) this command stops it. - Page 6 WSD12T-EXn User Manual WineCapKey For each flash, a different command is associated; to confirm the command the must be removed from the sensible area immediately after the number of flashes corresponding at the desired command. The TEST corresponds to the second pulse and activate the "Field Measurer"...
- Page 7 WSD12T-EXn User Manual 8. Shutting off/Reactivating the device. (refer to Picture 3 – If the device is shut off and left unused for a long time, you can issue the STANDBY command . It corresponds to the command number 4 and must be issued twice to confirm the operation. Position the WineCapKey in the spot indicated in (...
- Page 8 WSD12T-EXn User Manual 9. Transducer’s connection layout. ¼ bridge - three wires strain gauge connection. CHANNEL 4 CHANNEL 3 CHANNEL 2 ¼ bridge - two wires strain gauge connection. CHANNEL 4 CHANNEL 3 CHANNEL 2 ½ bridge dual strain gauge connection (advised for strain gauge connection as temperature compensation). CHANNEL 4 CHANNEL 3 CHANNEL 2...
-
Page 9: Technical Information
WSD12T-EXn User Manual 10. Technical Information. Power supply 8.5Ah - 3.6V type “C” lithium internal battery ( BAT2 Up to 10years (samples every 60 minutes and radio signal quality at least Battery life (*) sufficient) • Temperature (4 input channels) Measures acquired •... -
Page 10: Mechanical Dimensions
Picture 7 - Mechanical dimensions 12. Disclaimer. • Specifications are subject to change without notice and should not be interpreted as a commitment on the part of Capetti Elettronica S.r.l. • Capetti Elettronica S.r.l. assumes no responsibility for possibly errors that may appear in this document. In no case Capetti Elettronica S.r.l. -
Page 11: Reference Standards
WSD12T-EXn User Manual 13. Reference standards. EN 61010 -1 For electromagnetic compatibility EN 61000 - 3 - 2 EN 61000 - 3 - 3 EN 300 220 -2 EN 301 489 - 03 EN 61000 - 6 -1 This symbol indicates that this product is compliant with the European Directive 2011/65/CE that restricts the use of substances in the manufacturing of electronic devices.
