SR1201625
ITEM 1
INNER CHIMNEY PANEL
INNER CHIMNEY BOLT ON PANEL
QTY 2
ITEM 5
SCREW 6 32 X 1/4"
QTY 24
ITEM 8
MID CHIMNEY GASKET
NYLON PLUG/GUIDE
QTY 2X (15.75")
2X (20.875"
TOOLBOX
ITEM 2
OUTER CHIMNEY PANEL
QTY 2
ITEM 6
KNOB 1/4 20 FOUR ARM
QTY 2
ITEM 9
ITEM 10
FASTENER KNOB
QTY 8
QTY 4
Phillips Head
Screw Driver
ASSEMBLY INSTRUCTIONS FOR
HAMMOND ADJUSTABLE CHIMNEY
ITEM 3
OUTER CHIMNEY BOLT ON PANEL
QTY 2
ITEM 7
TOP CHIMNEY GASKET
QTY 2X (15.75")
2X (20.875")
ITEM 11
FASTENER BASE
QTY 4
HAMMOND FRAME
NOT INCLUDED
ITEM 4
QTY 2
HAMMOND
MANUFACTURING
ELECTRONICS GROUP
visit our website @ www.hammondmfg.com
BUL10436
A
REV.
Page: 1 of 4
TM
Advertisement
Summary of Contents for Electronics HAMMOND MANUFACTURING SR1201625
- Page 1 ITEM 11 MID CHIMNEY GASKET NYLON PLUG/GUIDE FASTENER KNOB FASTENER BASE QTY 2X (15.75") QTY 8 QTY 4 QTY 4 2X (20.875" HAMMOND FRAME NOT INCLUDED HAMMOND Phillips Head TOOLBOX MANUFACTURING Screw Driver ELECTRONICS GROUP visit our website @ www.hammondmfg.com...
- Page 2 BUL10436 ASSEMBLY INSTRUCTIONS FOR SR1201625 REV. HAMMOND ADJUSTABLE CHIMNEY Page: 2 of 4 ref. NOTE ref. NOTE ref. NOTE STEP 1 INNER CHIMNEY ASSEMBLY STEP 2 INNER CHIMNEY ASSEMBLY NOTES: (ITEM 1) ENSURE FLANGE IS FACING OUT AND ON BOTTOM FOR BOTH CHIMNEY PANELS (ITEM 2) ENSURE COUNTERSINKS...
- Page 3 BUL10436 ASSEMBLY INSTRUCTIONS FOR SR1201625 REV. HAMMOND ADJUSTABLE CHIMNEY Page: 3 of 4 ref. NOTE STEP 4 OUTER CHIMNEY ASSEMBLY STEP 5 OUTER CHIMNEY ASSEMBLY NOTES: (ITEM 4) ENSURE COUNTERSINKS FACE OUT AND PEM-NUT IS ON BOTTOM FOR BOTH PANELS STEP 6 OUTER CHIMNEY ASSEMBLY...
- Page 4 BUL10436 ASSEMBLY INSTRUCTIONS FOR SR1201625 REV. HAMMOND ADJUSTABLE CHIMNEY Page: 4 of 4 STEP 7 STEP 10 GASKET ATTACH CHIMNEY TO CABINET INSTALLATION Outer Chimney ALIGN CHIMNEY WITH HOLES ON TOP OF Assembly AS SHOWN: CABINET FASTEN USING ITEM 10 FROM OUTSIDE CABINET 15.75"...
