- Page 1 5” LAPPI ASSEMBLY MANUAL WWW.SB-COMPONENTS.CO.UK...
- Page 2 LapPi Assembling Guide Step 1 : Take out the base plate Step 2 : Connect M2x3 screws & M2x3 stand-offs M2x3 Screw M2x3 Stand off...
- Page 3 Step 3 : Place Raspberry Pi & Connect M2 nut M2 Nut M2 Nut Step 4 : Connect M3x5 screw to place Powerpack M3x5 Screw M3x10 Stand-off...
- Page 4 Step 5 : Place Powerpack & screwit using M3x5 M3x5 Screw M 3X5 Screw Step 6 : Connect Powerpack Side Layer & screw it using M3x10 screw & M3 nut M3x10 Screw M3 Nut...
- Page 5 Step 7 : Place the other side layer using M3x10 screw Step 8 : Now take Top Layer(for LCD) & connect M3x15 stand-off using M3x10 screw M3x10 Stand-off...
- Page 6 Step 9 : Place LCD Screen & screw it using M3x10 screw Step 10 : Connect HDMI dongle with HDMI flat cable...
- Page 7 Step 11 : Connect HDMI dongle & Micro USB with LCD screen Step 12 : Connect camera on top layer & screw it using M2x6 M2x6 Screw...
- Page 8 Step 13 : Now connect top layer & screw it using M3x10 screw Step 14 : Connect micro usb male to female extension cable...
- Page 9 Step 15 : Now connect screw and nuts Step 16 : Now connect hinge parts Insert nut Insert screw Final Hinge...
- Page 10 Step 17 : Now connect hinge with sheets to attach them together as shown : Step 18 : Connect the lcd sheet with hinges sheet as shown & connect the camera wire with Rpi power cable with power pack, hdmi dongle with hdmi cable &...
- Page 11 Step 19 : Now connect hinge to place the supportive sheet for keyboard Step 20 :Connect keyboard top layer...
- Page 12 Step 21 : Connect the keyboard supportive sheet Step 22 : Connect keyboard and keyboard usb to raspberry pi and your LapPi is now ready...
