Westward 2CZY5 Operating Instructions And Parts Manual

Operating Instructions and Parts Manual
Please read and save these instructions. Read through this owner's manual carefully before using product. Protect
yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could
result in personal injury and/or damage to product or property. Please retain instructions for future reference.
Description
This Westward heavy-duty service cart has a durable red finish,
two tiers and two full-extension drawers with ball-bearing drawer
slides and full-width aluminum drawer pulls. Cart includes
internal locking system and one side handle. Four swivel 4 x 1-
1/4 in. casters with a 250lb. load rating. This cart is ideal for
organizing and storing parts, components, and tools. Also great
for transporting those items to various work locations. Bottom
shelf ideal for bulky items. Powder-coated finish prevents
surface rust. Drawer liners included.
Unpacking
After unpacking unit, inspect carefully for any damage that may
have occurred during transit. Check for loose, missing, or
damaged parts. Shipping damage claim must be filed with carrier.
Specifications and Dimensions
Model Type
2CZY5 Heavy Duty
General Safety Information
Ensure the top cover and drawers are closed and locked completely before moving the cart. Use the brakes
when not moving the cart. When moving this product, do not pull it. Instead, push the product to prevent
personal injury.
Follow the assembly instructions to assemble the cart properly. Improper assembly may cause personal injury. Do
not alter the product in any manner. Do not step or climb on the cart.
MACH014
Printed in China
10/07
No. of
Casters Drawers
4 Swivel, 2 Lock 4
4-DRAWER SERVICE CART
Dimensions (Inches)
Width Depth
31
2CZY5
Surface
Height Construction
20 32 Steel
