- Page 2 Olympus Cube Assembly Procedure Step Action 1.1.1 The cube assembly has two filter retainer rings; one is located on the Exciter side and one is on the Emitter side as shown below. Emitter Retaining Ring Exciter Retaining Ring 1.1.2 Remove both filter retainer rings from the cube assembly. 1.1.2.1 Each filter retaining ring has two slots where the spanner wrench blades are...
- Page 3 Olympus Cube Assembly Procedure Step Action 1.1.2.3 Spanner wrench blades inserted into the retaining ring slots. 1.1.2.4 To remove the retaining ring, insert the spanner wrench into the slots. Applying even pressure across the ring, carefully turn the ring counterclockwise to loosen and remove it from the cube assembly.
- Page 4 Olympus Cube Assembly Procedure Step Action 1.1.2.6 Note that there are two distinctly different sides to the retainer rings. One is the flat (Shoulder) side and one is the open side. The open side ALWAYS faces into the cube assembly and is tightened against the installed filter.
-
Page 5: Filter Orientation
Olympus Cube Assembly Procedure Filter Orientation The filters are oriented in the assembly as follows: The Exciter is mounted with its arrow pointing inward. The Dichroic reflective side is mounted facing the Exciter The Emitter is mounted with its arrow pointing outward. Light passes through the cube in the direction of the arrows. - Page 6 Olympus Cube Assembly Procedure Step Action 1.2.2 Remove the two Phillips Head screws to separate the cube halves. Set the screws aside for reassembly later. Remove Screws 1.2.3 Separate the cube halves to prepare for assembly of the Semrock filter set. 6/11...
- Page 7 Olympus Cube Assembly Procedure Step Action 1.2.4 Assemble the Dichroic/Emitter half of the cube first. Loosen the mounting screws on the Dichroic holding clamp. Note: Do not remove the screws. Loosen the screws to allow space between the housing and the clamp for installation of the Dichroic filter. 1.2.5 Reflective “Coated Side”: The filter edge is concealed by the reflective coating and appears colored all the way to the edge.
- Page 8 Olympus Cube Assembly Procedure Step Action 1.2.6 Install the Dichroic under the mounting clamp with the Reflective coated side against the clamp facing outward as shown below. Center the filter within the mounting area and against the stop on the mounting clamp. Alternately tighten the screws until they are snug. Once snug, slightly tighten the screws past their stopping point.
- Page 9 Olympus Cube Assembly Procedure Step Action 1.2.8 Orient the Emitter with the arrow pointing away from the cube as shown below. 1.2.9 Place the filter inside the Emitter mounting area with the arrow pointing up. 9/11...
- Page 10 Olympus Cube Assembly Procedure Step Action 1.2.10 Insert the filter retaining ring open side into the Emitter mounting area of the cube. Note that the cube threads are at an angle. This will require careful installation of the retaining ring to avoid cross threading. Using the Spanner Wrench, carefully turn the ring while observing its position in the threads.
- Page 11 Olympus Cube Assembly Procedure Step Action 1.2.12 Place the filter inside the Exciter mounting area with the arrow pointing in. 1.2.13 Insert the retaining ring open side into the Exciter mounting area of the cube. Using the Spanner Wrench, carefully rotate the retaining ring to avoid cross threading. If the ring will not turn, it is not threaded properly –...
- Page 12 Olympus Cube Assembly Procedure Step Action 1.2.14 Completed Olympus OMF Cube Assembly. 12/11...
