- Page 1 IW-RS112-08 1 U N V M e H y b r i d S t o ra g e S e r v e r User Manual...
- Page 2 InWin’s server website. SAFETY INFORMATION To ensure a safe and smooth operation of your InWin IW-RS112-08, it is essential that you choose an appropriate location for the system, provide an appropriate operating environment and supply an adequate amount of power for all components of the system.
- Page 3 Installing or Removing Jumpers: A jumper is a short length conductor used to close, open or bypass part of an electronic circuit. Jumpers on InWin backplanes have a small tab on top that you can pick up with your fingertips. Grip the jumper carefully and plug the jumper to cover the jumper pins on the backplane.
-
Page 4: Product Introduction
Product Introduction 1.1 Box Contents When you open the IW-RS112-08 box, the contents should include following:... -
Page 5: Accessories Box
1.2 Accessories Box Item Item Motherboard Screws x 11 Power LED 3-pin to 2-pin Adapter x 1 Motherboard Stand-off Sockets x 11 Cable Ties and Mounts x 5 Riser Card Screws x 2 Backplane Jumper x 1 PCIe Gen4x16 Riser Card, Left-facing 90 Degree Design x 1... -
Page 6: General Information
1.3 General Information When you open the chassis, it should reflect the diagram’s image. Back View Back View Top cover USB 3.0 x 1 Backplane Type-1 Mini-SAS HD & Slimline Slide rail mounting area Backplane Type-2 Mini-SAS HD 40 x 56mm PWM easy-swap fans x 6 Top cover open rubber ATX, CEB, EEB M/B mounting area Front controls and indicator... -
Page 7: Front Panel Controls And Indicators
1.3.1 Front Panel Controls and Indicators The IW-RS112-08 supports maximum 4 x hot-swappable 2.5" NVMe/SAS/SATA disk bays, and 8 x 2.5" (15mm) drive bays in specific areas. The control panel, USB I/O ports and indicators are located on the handles. -
Page 8: Rear Panel Configuration
InWin compatibility list to select the compatible models. System I/O (Depends on M/B InWin offers a customized service for 1U I/O shield. For Specifications) more Information, please contact InWin’s sales reps. The slot supports standard high profile cards. The bracket Full-Height PCIe Slot x 1 should be removed before using. -
Page 9: Hardware Installation
I/O window. If you cannot find the I/O shield, please check with your motherboard vendor, or contact InWin for I/O shield OEM service. HDD Tray Installation The IW-RS112-08 features tool-less trays. Users no longer need to use screws to mount disks, and can swap drives faster. Fan Installation The IW-RS112-08’s built-in fan modules feature a tool-less design, which makes it easy to maintain. - Page 10 2.4.1 Power Supply Cable Information 750W Redundant PSU Cable Information 420mm 150mm 150mm 24-Pin Main Power Connector 200mm 100mm 8-Pin CPU 270mm 100mm 200mm 8-Pin CPU 530mm 200mm 200mm 8-Pin Backplane Power 300mm 150mm 6-Pin Backplane Power 500mm 150mm 150mm 150mm PMBus...
-
Page 11: Connecting Cables
2.5 Connecting Cables Connecting LED Cable, Front Control Panel and Front USB I/O Ports Refer to your motherboard user guide for pin functions and locations, and then plug the connectors to the pins on the motherboard to activate the functions. •USB 3.0 •LED Connector Connector Name... - Page 12 The IW-RS112-08 is a rackmount model, which supports EIA-RS310D standard cabinets and chassis racks. InWin provides standard slide rails to allow users to mount the chassis onto the cabinets. Note: Please check rack post type. The rail pre-installed type is for square hole post. If rack post is round hole post, please switch to the suitable screws.
- Page 13 Please adjust the pre-installed Detach Front Bracket from Rack Post front screws order. default IW-RS112-08 Pull Step 4 - Insert chassis to complete the installation Ensure ball bearing retainer is located at the front of the rall. Insert the chasis into outer ralls.
- Page 14 Detach Front Bracket from Rack Post Loosen shlpping screw to pull out chassis. Press the disconnect tab forward to remove chassis. Pull...
-
Page 15: Backplane Introduction
SAS/SATA disk or U.2/U.3 NVMe SSD at a time. The backplane varies by order. Please reference the backplane user guide to complete the installation. The download link is at the download section of each product. Please visit the InWin website: ipc.in-win.com 3.1 Mini-SAS HD Backplane... - Page 16 3.3 Backplane Connection The IW-RS112-08 supports NVMe SSDs through SlimLine 8i connectors, and the backplane is backward compatible with Mini-SAS HD. 3.3.1 SlimLine Backplane Connection For SlimLine connectors, please use the SFF-8654 cable to connect to the motherboard or RAID/HBA controller card.
-
Page 17: Compatibility Lists
InWin’s chassis. You can download the latest updated device compatibility list ipc.in-win.com from InWin’s website: Technical Support If you need help with installation or troubleshooting, you can contact your local InWin reps, or send an e-mail to InWin’s local contacts for technical assistance. - Page 18 Co py r ig ht © I n W in D eve lo p m ent I n c . A l l Ri g ht s Res e r ved .
