EBERBACH E6003.00 Manual

Shaker power unit variable speed with digital tach and timer 115-230v, 50/60 hz
Hide thumbs

Advertisement

Quick Links

Download this manual
5900 Schooner Street – Belleville, MI 48111 – USA
TEL (800) 422-2558 – FAX (734) 665-9099
Eberbachlabtools.
.
com
www
E6003.00 Shaker Power Unit
Variable Speed with
Digital Tach and Timer
115-230V, 50/60 Hz

Advertisement

loading
Need help?

Need help?

Do you have a question about the E6003.00 and is the answer not in the manual?

Questions and answers

Summary of Contents for EBERBACH E6003.00

  • Page 1 5900 Schooner Street – Belleville, MI 48111 – USA TEL (800) 422-2558 – FAX (734) 665-9099 Eberbachlabtools. E6003.00 Shaker Power Unit Variable Speed with Digital Tach and Timer 115-230V, 50/60 Hz...

  • Page 2: General Information

    If you have any doubts or inquiries, please contact your supplier or Eberbach Corporation technical service. OPERATION The Eberbach bench top reciprocating shaker (catalog E6003.00) features: o A continuously variable speed range, adjustable between 60 and 260 osc/min with fixed stroke length set to 1.5” (38mm).
  • Page 4 1) Power Switch 2) Liquid Crystal Display (LCD) 3) Directional Pad (D-Pad) 4) Enter Button 5) Cursor Operation: Press the Power Switch down into the ON position. The LCD should light up and show the main menu. There are three different run modes to choose from.
  • Page 5 Run Mode: The shaker will begin the run mode at its lowest speed. The speed shown in parenthesis (xxxx) is the set speed controlled by the user. The speed listed to the right is the tachometer read out or the actual speed of the shaker in real time. The speed can be increased/decreased by pressing and holding the up/down arrows on the D-PAD.
  • Page 6 Timed Run Mode: The timed run mode features a count down timer that automatically shuts the shaker off when the time runs out. When selected the user will be taken to the Timed Run Setup Menu and will need to input the run time in hours, minutes, seconds and select the speed for the run.
  • Page 7 After selecting START the shaker will begin at the selected speed and the timer will begin counting down. The speed can be adjusted in real time using the up/down arrows on the D-PAD. The speed shown in parenthesis is the target speed controlled by the user and the speed listed to the right is the actual speed as read by the tachometer.
  • Page 8 Speed Run Mode: The speed run allows the user to program in a set run speed. Once engaged the timer will begin counting all the way up to 999 hours before the timer overflows back to zero. Select the speed run mode from the main menu and press the Enter Button.
  • Page 9 Note: All run menus will have two speeds listed. The leftmost speed will be displayed inside parenthesis. This is the target speed controlled by the user. The shaker will attempt to match this speed and should do so within ten seconds after making an adjustment. The rightmost speed is the tachometer reading, which shows the user what the shaker is actually running at.
  • Page 10 To calibrate the tachometer system follow these steps: Step 1 Hold down the Green Enter Button and power the machine on to access the utilities menu Step 2 Select the “Tests Menu” and press the Enter Button. Step 3 Select the “Calibration” item and press the Enter Button.
  • Page 11 Step 4 Make sure the machine is empty and ready to be run at maximum speed. Select “Yes” and press the Enter Button. Step 5 Machine will now run at maximum speed for one minute. You will see the tachometer scaling ratio displayed on top and the DAC (Digital to Analog Converter) set point displayed on the bottom.
  • Page 12 TRUE RPM reading. This should be capable of +/- 5 RPM of your “Calibration Test Kit.” The calibration is now complete. The tachometer should maintain its accuracy until your next belt replacement. If you have any doubts or inquiries concerning operation contact your supplier or Eberbach Corporation technical service.

  • Page 13: Belt Adjustment

    When a belt is tight, the operator should be able to press lightly on the middle of the belt and cause it to bow in an amount equal to the width of the belt. Contact Eberbach Tech Support (800) 422-2558 for instructions on replacement of belt between idler assembly and crankshaft assembly.
  • Page 14 LUBRICATION: See exploded view of shaker power unit for points of lubrication. Use a good grade of SAE #30 oil. Lubrication when shaker is used in continuous duty applications of 100 hours or more: A. Oil crank bearing through hole in center of bearing bracket every 3 months. B.
  • Page 15 REPLACEMENT PARTS LIST FOR E6003.00 PartNo DESCRIPTION QTY. 4281 3L300R V-BELT 4283.2 3L290 V-BELT 4351 COLLAR 5528 3.75" SUCTION CUP W/ 5/16-18 THREADED POST 6009.1 200W POWER SUPPLY 6010.7 POWER SUPPLY, 5V 30W 6063.1 CABLE TIE MOUNT 6063.2 CABLE TIE...
  • Page 16 EP6003.SS.502A ORIENTAL MOTOR MOUNT ASSEMBLY EP6003.SS.503A FRONT PANEL ASSEMBLY EP6003.SS.525A DC LEFT END EP6003.SS.551A BASE ASSEMBLY EP6013.SS.116 ORIENTAL POWER SUPPLY MOUNT If you have any doubts or inquiries concerning operation contact your supplier or Eberbach Corporation technical service @ 1-800-422-2...
