AM-1000
LOOM TAKEUP
Instruction Manual
AM1000-000
AM1000-001
AM1000-002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AM-1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Carotron AM-1000

  • Page 1 AM-1000 LOOM TAKEUP Instruction Manual AM1000-000 AM1000-001 AM1000-002...
  • Page 2: Table Of Contents

    Table of Contents 1. General Description....................... 3 2. Specifications ........................ 3 2.1 Electrical ......................3 2.2 Physical ......................4 3. Installation ........................5 3.1 Wiring Guidelines ..................... 5 3.2 Signal Connections................... 6 4. Description of Terminals....................7 5. Description of Features & Adjustments ................. 7 6.
  • Page 3: General Description

    General Description The AM-1000-XXX series of drives is designed to run either a 1/4 or 1/2 horsepower (HP) permanent magnet (PM) DC motor. The AM-1000 series was originally an OEM product of which there were two models. The -000 model accepted a 0-10mA speed reference while the -001 model accepted a 0-10V speed reference.
  • Page 4: Physical

    2.2 Physical Figure 1: Physical Dimensions...
  • Page 5: Installation

    Any relay, contactor, starter, solenoid or other electro-mechanical device located in close proximity to or on the same line supply as the AM-1000 should have a transient suppression device such as an MOV or R-C snubber connected in parallel with its coil.
  • Page 6: Signal Connections

    3.2 Signal Connections Figure 2: General Connections...
  • Page 7: Description Of Terminals

    Description of Terminals TB1-1 & 2 (AC INPUT) These terminals are used for the A.C. line input. The AM-1000 accepts 115VAC. The circuit should be able to provide a minimum of 20A. TB1-3 & 4 (CLOSE TO ENABLE) Closing a set of contacts across these terminals will place the drive in the RUN mode.
  • Page 8: Adjustment Procedure

    DRIVE THAT COULD BE DAMAGED OR CAUSE INJURY DURING THIS PROCESS. 1. Connect the AM-1000-XXX per the connection diagram. Place switch S1 in the appropriate position (I or V) based on the type of external sensor. 2. If a 1/4 HP motor is used, make no connection from CN1 to CN2. If a 1/2 HP motor is used, connect a wire jumper from CN1 to CN2.
  • Page 9: Standard Terms & Conditions Of Sale

    1. General charges any such system to so perform, which system is found to the The Standard Terms and Conditions of Sale of Carotron, Inc. (hereinafter Company’s satisfaction to have failed to so perform, or refund to the called “Company”) are set forth as follows in order to give the Company Purchaser the purchase price paid by the Purchaser to the Company in and the Purchaser a clear understanding thereof.
  • Page 10 3204 Rocky River Road Heath Springs, SC 29058 Phone: 803.286.8614 Fax: 803.286.6063 Email: saleserv@carotron.com Web: www.carotron.com MAN1066-00 Rev. B Issued 02-14-2023...
