Models 4430BF3, 4430BF2 & 4430BF1
Floor Mounted Tri-Level Bottle Filling Tubular Fountain
MODEL
4430BF1L
INSTALLER
4430BF Fountains are among the easiest to install Fountains on the market today.
To assure you install these models easily and correctly, PLEASE READ THESE
SIMPLE INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK
YOUR INSTALLATION FOR COMPLIANCE WITH PLUMBING, ELECTRICAL, AND
OTHER APPLICABLE CODES. After installation, leave these instructions with the
Fountain for future reference.
ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON
THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC. TO WATER LINES
IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY OCCUR AWAY FROM THE
BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTO A FOUNTAIN, CREATING AN ELEC-
TROLYSIS WHICH CAUSES A METALLIC TASTE OR AN INCREASE IN THE METAL CONTENT OF THE WATER.
THIS CONDITION IS AVOIDABLE BY USING THE PROPER MATERIALS AS INDICATED. ANY DRAIN FITTINGS
PROVIDED BY THE INSTALLER SHOULD BE MADE OF PLASTIC TO ELECTRICALLY ISOLATE THE FOUNTAIN
FROM THE BUILDING PLUMBING SYSTEM.
4430BF FOUNTAIN
Owners Manual
MODEL
4430BF2UM
IMPORTANT
IMPORTANT! INSTALLER PLEASE NOTE.
PAGE 1
MODEL
4430BF3
98646C (Rev. C - 12/12)
Advertisement
Table of Contents
Summary of Contents for Pittsburgh Water Cooler 4430BF3
- Page 1 4430BF FOUNTAIN Owners Manual Models 4430BF3, 4430BF2 & 4430BF1 Floor Mounted Tri-Level Bottle Filling Tubular Fountain MODEL 4430BF1L MODEL MODEL 4430BF2UM 4430BF3 INSTALLER 4430BF Fountains are among the easiest to install Fountains on the market today. To assure you install these models easily and correctly, PLEASE READ THESE SIMPLE INSTRUCTIONS BEFORE STARTING THE INSTALLATION.
- Page 2 4430BF FOUNTAIN 98646C (Rev. C - 12/12) PAGE 2...
- Page 3 4430BF FOUNTAIN PAGE 3 98646C (Rev. C - 12/12)
- Page 4 4430BF FOUNTAIN 98646C (Rev. C - 12/12) PAGE 4...
- Page 5 4430BF FOUNTAIN 1. This fountain is to be mounted on a smooth, flat, finished surface with adequate support structure. NOTE: Mounting structure must be capable of supporting 300 lb. load on fountain. 2. Refer to rough-in for plumbing. 3. Install shut-off valve on water supply. (Valve not furnished) 4.
- Page 6 4430BF FOUNTAIN 14 & 24 15 & 24 19 & 23 18 & 25 13 or 16 13 or 16 13 or 16 98646C (Rev. C - 12/12) PAGE 6...
- Page 7 4430BF FOUNTAIN ITEMIZED PARTS LIST ITEM NO. PART NO. DESCRIPTION Basin 28467C Cover - Round Plate 28955C Tailpipe 40551C Drain Plug 1-1/2" 45464C Access Panel 45832C Bottom Cover 45833C Drain Tube 45734C In - Line Strainer 55996C Drain Tube 66346C Tube - Drain 66815C Tube - Drain (Arm Only)
- Page 8 4430BF FOUNTAIN THIS PAGE WAS LEFT INTENTIONALLY BLANK 98646C (Rev. C - 12/12) PAGE 8...
