KLINGER 15-5800VT User Manual

5.8GHz WIRELESS A/V/ALARM TRANSMITTER USER MANUAL
MODEL: 15-5800VT

1. Panel View

○ ○ ○
1 2 3
1. DC+12V IN: Power input DC+12V/1.5A.
2. DC+12V OUT: DC+12V/750mA for box camera only, and with a over current protector.
(Note: If you don't use this port for cameras, you can use the DC+12V/500mA adaptor.)
3. ALARM IN: Once triggered, the built-in buzzer rings on for a 20-sec time. This port could be connected to
alarm sensor, e.g.: PIR Detector, Magnetic Reed Switch Detector.
4. AUDIO IN: RCA female for input video signal.
5. VIDEO IN: BNC female for input audio signal.
6 . POWER/State LED: Indicated to power on and ARM status.
7. DISARM: DISARM at 15-5800VT/15-5800VH t nsmitter's side only.
8. CH SELECT (A B C D): 5.8GHz transmission channel selecti
9. ID AND ALARM MUTE: ID address setting is use for paring with 15-5800VR receivers. It must be make the
same code setting to link transmitter and receiver each other. The alarm mute function is use for muting
built-in buzzer at 15-5800VT/15-5800VH side only.
10. ANT: RP-SMA conne
REMARK: When the frequ
transmitter and don't close
(Note: Please keep 3 ~ 5 meter a
○ ○
4 5
Indications
Power On
ARM
Bit 1 Bit 2 Bit 3
(Pairing with RX)
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
(1 = S W O N, 0 = SW OFF)
cto r for connec ted to 5.8 GHz a
ency chan nels have the inte
to 802 .11 a/b/ g A P router a
wa y)
○ ○ ○
6 7 8
Power/State LED
On
High speed Flashing
ra
on.
ID Address Bit 4
0 0
1 1
2
3
4
5
6
7
ntenna.
rfe rence, adjust antenna or change the channel of
nd other 5.8GHz devices.
○
○
9
10
Alarm
Mute
ON
OFF
