Summary of Contents for Magic Chef MCCM21ST
- Page 1 Magic Chef 2.1 & 3.1 Cu. Ft. Commercial Countertop Merchandiser User’s Manual Models: MCCM21ST / MCCM31ST PLEASE READ THIS MANUAL CAREFULLY BEFORE USING YOUR COMPACT DRYER AND KEEP IT FOR FUTURE REFERENCE.
-
Page 2: Product Registration
PRODUCT REGISTRATION hank you for purchasing a Magic Chef ® product. The first step to protect your new product is to complete the product registration on our website: www.mcappliance.com/ register. The benefits of registering your product include the following: Registering your product will allow us to contact you regarding a safety notification or product update. -
Page 3: Table Of Contents
CONTENTS PRODUCT REGISTRATION..............2 PRECAUTIONS..................4 IMPORTANT SAFETY INSTRUCTIONS........... 5 SPECIFICATIONS ..................7 PARTS AND FEATURES................8 INSTALLATION INSTRUCTIONS..............9 OPERATION INSTRUCTIONS ..............11 CARE AND MAINTENANCE................ 13 TROUBLESHOOTING.................. 14 WARRANTY....................15... -
Page 4: Precautions
PRECAUTIONS WARNING: To reduce the risk of fire, electrical shock, or injury when using your merchandiser, follow these basic precautions • Read all instructions before using the merchandiser. • CAUTION, WARNING, or DANGER symbol: Risk of damage to product or surroundings, or risk of personal harm or injury. -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electrical shock, or injury follow these basic precautions when using your merchandiser. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction WARNING: DO NOT use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. - Page 6 CAUTION: Risk of fire. WARNING: It is hazardous for anyone other than authorized service personnel to carry out services or repairs involving the removal of covers. DANGER: Risk of fire or explosion. Flammable refrigerant used. To be repaired only by trained service personnel.
-
Page 7: Specifications
SPECIFICATIONS Figure 1 25 2” MCCM31ST MCCM21ST 33 5” Model MCCM21ST MCCM31ST Width 18.9" 18.9” Height 25 2” 33.5” Depth 16.9” 16.9” Net Weight 50 7 lbs 61 lbs Capacity 2.1 Cu Ft 3.1 Cu Ft Power Consumption 0.64 kW h/24h 0.74 kW h/24h Refrigerant R600a... -
Page 8: Parts And Features
PARTS IDENTIFICATION Figure 2 Interior Light Leveling Legs Door Security Lock Shelves Control Panel Door Handle Figure 3 Interior Light Leveling Legs Door Security Lock Shelves Control Panel Door Handle... -
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS BEFORE USING YOUR MERCHANDISER • Remove the exterior and interior packaging. • Before connecting the merchandiser to the power source, let it stand upright for approximately 4 hours. This will reduce the possibility of a malfunction in the cooling system from improper handling during transportation. - Page 10 • DO NOT use an extension cord with this appliance. If the power cord is too short, have a qualified electrician or service technician install an outlet near the appliance Use of an extension cord can negatively affect the performance of the unit. •...
-
Page 11: Operation Instructions
OPERATION INSTRUCTIONS CONTROL PANEL OPERATION Figure 5 a. Power Button d. Temperature Increase Button Temperature Decrease Button e. Control Panel Lock °C/ °F Select Button b. Light Button c. LED Display It is recommended you install the appliance in a place where the ambient temperature is between 72º and 78ºF (23º-26ºC). - Page 12 DEFROSTING This appliance requires no manual defrosting. During the operation of the compressor, ice will build up on the evaporator plate which is at the back of inner cabinet. During the compressor’s off-cycle, the ice will melt, drip down, and collect in a tray above the compressor, where the compressor’s heat evaporates the water.
-
Page 13: Care And Maintenance
CARE AND MAINTENANCE CLEANING YOUR MERCHANDISER • Turn off the power, unplug the appliance, and remove all items, including shelves. • Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of baking soda to a quart of water). Wash the shelves with a mild detergent solution. •... -
Page 14: Troubleshooting
TROUBLESHOOTING You can solve many common merchandiser problems easily, saving you the cost of a possible service call Try the suggestions below to see if you can solve the problem before calling for service. PROBLEM POSSIBLE CAUSE/SOLUTION Appliance is not •... -
Page 15: Warranty
Some states prohibit the exclusion or limitation of incidental or consequential damages, or limitations on implied warranties. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Model Parts &Labor Compressor (Part Only) Type of Service MCCM21ST One-Year Five Years Carry In MCCM31ST One-Year... - Page 16 Magic Chef CNA International, Inc. d/b/a MC Appliance Corporation. All rights reserved. Magic Chef® is a registered trademark of CNA International, Inc. www.mcappliance.com Printed in China...
