- Page 1 User Manual Spray Gun Probes for Helium Leak Detection P1012177 P1011211 P105182 P104871 HESP-02072023 - V1.01...
-
Page 2: Warranty
Ideal Vacuum warrants to the original purchaser this product to be free from defects in workmanship and materials for a period of one year from the original delivery date. The liability of Ideal Vacuum under this warranty is limited to servicing, adjusting, repairing or replacing any unit or component part which, at Ideal Vacuum’s sole discretion, is determined to have failed during normal, intended use. -
Page 3: Important Safety Information
SaFetY inForMation Thank you for purchasing this equipment from Ideal Vacuum Products. We want you to operate it safely. h read this manual and all associated equipment manuals before installing or operating this equipment. Failure to follow the warnings and instructions may result in serious injury or equipment damage. - Page 4 This manual provides general information and set up information about each of Ideal Vacuum’s spray gun probe models. It also outlines spraying techniques for achieving optimal leak detection results. Last, step-by-step detailed instructions are presented for safely refilling the small helium gas cylinder in our premium helium spray gun probe kit (P1012177).
- Page 5 5. Make sure the probe tip does not get plugged. 6. To change tips, unscrew the Swagelok nut at the gun and replace with the other tip (7/16” wrench). Tighten the nut slightly past hand tight. 2022 © Ideal Vacuum Products, LLC | (505) 872-0037 info@idealvac.com www.idealvac.com...
- Page 6 HoW to reFiLL SMaLL CYLinDerS In the following pages, step-by-step, detailed instructions are provided for safely refilling the small helium gas cylinder in our premium helium spray gun probe kit (P1012177). h The cylinder is shipped empty and must be filled before it can be used.
- Page 7 Once the tank and outlet pressure gauges are zero, close the outlet valve completely. SteP 3 Apply teflon tape to the NPT threads of the refill adapter. 2022 © Ideal Vacuum Products, LLC | (505) 872-0037 info@idealvac.com www.idealvac.com HESP-0207023 - V 1.01...
- Page 8 Connect the refill adapter to the supply tank hose. Use a 7/8 and 13/16”, or two adjustable wrenches. SteP 5 Decrease the tank regulator valve until it feels loose (turn counterclockwise). 2022 © Ideal Vacuum Products, LLC | (505) 872-0037 info@idealvac.com www.idealvac.com HESP-0207023 - V 1.01...
- Page 9 The cylinder does not need to be empty - the cylinder has an internal valve. SteP 7 Spin the cylinder onto the helium supply hose, hand-tight. Note: Do not use tools to tighten. 2022 © Ideal Vacuum Products, LLC | (505) 872-0037 info@idealvac.com www.idealvac.com HESP-0207023 - V 1.01...
- Page 10 The tank pressure gauge will increase (to the pressure in the supply tank). SteP 9 SteP 18 SLOWLY open the regulator valve to increase outlet gauge pressure to 50psi (turn clockwise). 2022 © Ideal Vacuum Products, LLC | (505) 872-0037 info@idealvac.com www.idealvac.com HESP-0207023 - V 1.01...
- Page 11 1800psi, it is recommended to fill to a more conservative pressure. Wait for one minute (1:00) to allow the cylinder to fill. You may not hear the transfer of gas. 2022 © Ideal Vacuum Products, LLC | (505) 872-0037 info@idealvac.com www.idealvac.com HESP-0207023 - V 1.01...
- Page 12 Decrease the tank regulator valve until it feels loose (turn counterclockwise). Note: The gauges will continue to show pressure until the regulator is bled off later. 2022 © Ideal Vacuum Products, LLC | (505) 872-0037 info@idealvac.com www.idealvac.com HESP-0207023 - V 1.01...
- Page 13 Wait until the hissing stops (several minutes) before completely unscrewing the cylinder. 2022 © Ideal Vacuum Products, LLC | (505) 872-0037 info@idealvac.com www.idealvac.com HESP-0207023 - V 1.01...
- Page 14 Spin the cylinder onto the assembly. The pressure gauge on the cylinder shows the fill pressure. Here it is 500 psi. The cylinder refill procedure is complete. 2022 © Ideal Vacuum Products, LLC | (505) 872-0037 info@idealvac.com www.idealvac.com HESP-0207023 - V 1.01...
- Page 15 Products, LLC. 5910 Midway Park Blvd ne albuquerque, nM 87109 Phone: (505) 872-0037 Fax: (505) 872-9001 Web: idealvac.com 2022 © Ideal Vacuum Products, LLC | (505) 872-0037 info@idealvac.com www.idealvac.com HESP-0207023 - V 1.01...
